Push ”units” button shortly and choose the units in “scale parameters setup”. To
choose certain unit, must ensure this unit has been opened. Refer to “units setup” in
“scale parameters setup”
B. Counting
1）.Push and hold “Count” until it displays “COU”. It blinks with counting number.
Push “count” and choose the number to be set up between 10.20.50.100.200.500, then
add corresponding qty of objects on the tray. Push ”CAL” to confirm and it displays
“------”. When scale is stable, counting setup is done. When the unit weight of object
for counting is less than 2d, it displays “Err-3”and counting setup can not be carried
out.
Need to take more objects as one collectively for re-setup. Push “Tare” to return
to weighing status.
2）.During “counting” setup, can push “Tare” button to stop setup and return to
weighing status.
3）.After “counting” setup is done, push ”Count” button to switch between counting
and weighing status.
C. Percentage
1）.Hold “Count” button until it displays “100%”. Let the button go and it blinks with
“100”. Put on the object to be setup as 100% and push “CAL” to confirm Scale
displays “------“. When it is stable, it displays “100%”. Take the object down and put
on other object and it displays the percentage of this object to the object setup. When
the object set up is less than 20d, it displays “Err-4” meaning the setup object is too
small and need to increase the weight of the setup object. Push “Tare” button to return
to weighing status.
2）. During percentage setup, can push “Tare” to return to weighing status.
3）.After setup is done, push “count” button to switch between percentage and
weighing status.
D. Printing
1）.One time printing: Set up as manual printing mode in “scale parameters setup”.
Push “Print” button once for one time data output.
2）.Continuous printing: Set up as continuous output in “scale parameters setup”.
Scale outputs data continuously.
3）.Timing output: Set up as timing output in “scale parameters setup”. Scale outputs
data at the time setup.
4）Printing mode setup refers to “printing mode setup” in “scale parameters setup”
F. Baud rate
Scale has 4 baud rates to choose: 1200.2400.4800.9600. Refer to “Baud rate setup” in
“scale parameters setup”
G. RS232 communication
Scale uses RS232 UART communication. Data format is 10 digits:
One digit as start position, 8 digits as data and one digit stop position. No verification.
Data frame format:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
K, */space, +/-, data, data, data, data, decimal point, data, data, data, unit, unit,
