Operating Instructions

Outdoor Radiant Heater

Model: GHOR100RS

CAUTION: In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through an external

switching device, such as a timer, or connected to a circuit that is regularly

switched on and off by the utility.

•This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities or lack of experience and

knowledge, unless they are supervised or have been given instruction

concerning the use of the appliance by a person responsible for their safety.

•Children should be supervised to ensure that they do not play with the

appliance.

•If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid a hazard.

WARNING: You must not cover this appliance. Covering this appliance

presents fire risk and will activate the safety fuse; permanently disabling the

unit.

WARNING: Do not use this appliance in small rooms when they are

occupied by persons not capable of leaving the room on their own, unless

constant supervision is provided.

WARNING: To reduce the risk of fire, keep textiles, curtains, or any

flammable material a minimum distance of 1 metre from the air outlet.

General Care and Safety Guide

•Use only the voltage specified on the rating label of the appliance.

•Keep all objects at least 1 metre from the front, sides and rear of the

appliance.

•This appliance is intended for household use only and not for commercial or

industrial use.

•Use this appliance only as described in this manual. Any other use is not

recommended by the manufacturer and may cause fire, electric shock or

injury.

•Do not use the appliance if it has been dropped or damaged.

•The common cause of overheating is deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly by unplugging the appliance and

vacuum cleaning the air vents and grills.

YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE

INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.

•Always unplug appliance when not in use.

•When the appliance has been unpacked, check it for transport damage and

ensure all parts have been delivered. If parts are missing or the appliance has

been damaged, contact the Customer Services Team.

•Do not use if there are visible signs of damage to the appliance.

•Do not connect the appliance to mains supply until completely assembled and

adjusted.

•Ensure hands are dry before handling the plug or main unit.

•Ensure appliance is on a flat, stable, heat-resistant surface.

•Do not operate with cord set coiled up as a heat build up is likely, which could

be sufficient to become a hazard.

•Carry out regular checks of the supply cord to ensure no damage is evident

•Do not operate this appliance with a damaged cord, plug or after the appliance

malfunctions or has been dropped or damaged in any manner. Take to a

qualified electrical person for examination, electrical service or repair.

•Do not twist, kink or wrap the cord around the appliance, as this may cause the

insulation to weaken and split. Always ensure that all cord has been removed

from any cord storage area and is unrolled before use.

•It is recommended that this appliance is plugged directly into the wall socket.

Power boards are not rated to supply power to high wattage appliances.

•A correctly specified, undamaged extension cord may be used with this

appliance provided it is used in a safe manner.

•Do not remove plug from power socket until the appliance has been switched

off.

•Do not remove plug from power socket by pulling cord; always grip plug.

•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord

so it cannot be tripped over.

•Don’t place appliance on bedding or on thick & long carpet where the openings

may get blocked.

•Switch off and use handle provided when moving

•Do not place appliance close to radiant heat source.

•Do not insert or allow foreign objects to enter any ventilation or exhaust

opening, as this may cause an electric shock, fire or damage to the appliance.

•Do not sit on the appliance.

•Do not use abrasive cleaning products on this appliance. Clean with a damp

cloth (not wet) rinsed in hot soapy water only. Always remove plug from the

mains supply before cleaning.

•Do not operate in areas where petrol, paint or other flammable liquids are used

or stored.

•Do not use this appliance in the immediate surrounds of a bath, a shower, or a

swimming pool or other liquids.

General Care and Safety Guide

•The appliance must not be immersed in any liquids.

•There are no user serviceable parts installed in the unit.

•Do not place the unit in wardrobes or other enclosed spaces as this may cause

fire hazards.

•This unit is not supposed to be used in or around locations where foodstuffs,

works of art or delicate articles of science, etc. are stored.

•If your appliance does not work, or is not working properly, contact the place of

purchase or the Customer Services Team.

General Care and Safety Guide

WARNING: In order to avoid overheating or fire, do not cover the heater.

WARNING: Keep all objects at least 1 metre from the front, sides and rear of

the appliance.

WARNING: Do not use this heater with a programmer, separate timer, remote-

control system or any other device that switches the heater on automatically, since

a fire risk exists if the heater is covered or positioned incorrectly.

WARNING: Never leave this heater unattended when in use.

WARNING: This heater is not equipped with a device to control the room

temperature. Do not use this heater in small rooms when they are occupied by

persons not capable of leaving the room on their own, unless constant supervision

is provided.

Ensure heater is on a flat, stable, heat-resistant surface.

Once the heater is in a safe operating position and all switches are in the off

position, insert the power plug into the mains outlet and switch on.

CAUTION: Ensure the power cord is not tight because if pulled it may partially

pull the plug from the socket. A partially inserted plug will overheat the plug and

socket and could result in fire.

WARNING: This heater is not equipped with a device to control the room

temperature. Do not use this heater in small rooms when they are occupied by

persons not capable of leaving the room on their own, unless constant supervision

is provided.

Operating Your Heater

Always choose a safe location for the heater, keeping in mind the safety

precautions outlined. Ensure all packaging has been removed from the unit

before use. Please follow the below instructions.

Components

1. Grille

2. Power Setting button

3. Timer Setting button

4. Power Switch

5. Mounting Screw

6. Base

7. Lower PostAssembly

8. Middle PostAssembly

9. Top PostAssembly

10. Adjustable Post Section

11. Remote Control

Not illustrated –3 x bolts; 3 x screws

Assembly

Before using this appliance, remove all packing. Check to ensure that all parts of this

heater, cord and plug are not damaged. Confirm all parts before disposing of carton.

Do not leave packaging materials like bags and staples within reach of children or

animals.

Portable Operation:

1. Place the lower post assembly on the base in such a way that the screw holes are

aligned.

2. Insert the 3 x bolts through the double holes and tighten them firmly. Place the

protective cover over the screw connection and remove the cable holder for a

moment.

3. Push the middle post assembly section over the lower post assembly and fasten it

in place with one of the screws.

4. Attach the top post assembly to the middle post assembly in the same manner

with a screw.

5. Insert the adjustable post section as far as you wish into the compression coupling

on top of the stand. Slide the locking ring down over the adjustable post section

and screw it firmly with the compression coupling.

6. Unscrew the mounting screw almost completely out of the mounting bracket.

Place the head of the heater over the top of the adjustable stand section in such a

way that the screw falls precisely into the hole in the stand. Now tighten the screw

firmly (the screw must disappear into the adjustable post section and must not

protrude). The adjustable post section can rotate 360°, enabling the head of the

heater to point in any direction.

7. The cable holder can now be placed back onto the stand and the cable can be

secured in the holders.

8. Check that all connections are secure and that the heater is securely in position

before using it.

9. The heater must be placed at a distance of at least 1m from the nearest wall. The

top of the heater must be at least 30cm from the ceiling and at least 1.8m above

the floor.

Operating Your Heater

SAFETY DEVICE

•Tilt Switch - this will automatically turn the appliance off if the appliance is not in

the correct operating position.

CAUTION: The heater generates heat during use. Proper precautions

must be taken to prevent the risk of burns, scalds, fires or other damage to

persons.

Your heater can be controlled by the Remote Control (included) or via

the unit itself. For both types of operation, ensure the power switch

on the side of the heater is switched on. The indicator light will turn

red.

Remote Control Settings

ON/OFF POWER TIMER

•The heater has 3 heat settings. Pressing the “P” button on either the remote or

control box once will select low heat; pressing again will select mid heat and

pressing a third time will select high heat. This selected heat settings will be

indicated on the control panel.

•The heater has a countdown/auto-off timer, which can be adjusted up to 7 hours

by pressing the “T” button on either the remote or control box. Pressing the button

once will add 1 hour, up to a total of 7 hours, and this will be indicated on the

control panel.

Care & Cleaning

SUPPORT AND TECHNICAL ADVICE

Goldair –New Zealand

Monday –Friday 8am-5pm

Phone +64 (0)9 917 4000

Phone 0800 232 633

[email protected]

Goldair –Australia

Monday –Friday 8am-5pm

Phone +61 (0)3 9365 5100

Phone 1300 465 324

[email protected]

TECHNICAL SPECIFICATION

Model No:GHOR100RS

Supply: 240VAC 50Hz

Wattage: 2400W

PROOF OF PURCHASE

To receive warranty retain receipt as proof of purchase.

SAFETY DEVICES

This appliance has one protection device:

•Tilt Switch - this will automatically turn the appliance off if the appliance is not in

the correct operating position.

CAUTION: The appliance generates heat during use. Precautions must be

taken to prevent the risk of burns, scalds, fires or other damage to persons.

CARE AND CLEANING

The heater requires regular cleaning to ensure trouble free operation:

•Unplug the heater from the mains supply before cleaning.

•Ensure that the heater has been allowed to cool down completely before cleaning.

•The common cause of overheating is deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly by unplugging the appliance and

vacuum cleaning the air vents and grills.

•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and

dirt.

•Never use solutions such as petrol, thinners or polishing agents.

•Ensure the heater is dry before plugging back into the mains supply.

•Do not attempt to dismantle the heater.

•There are no user serviceable parts. For service or repair, contact an authorised

electrical service technician.

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal

domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three months.

Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the

warranty period.

This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone

other than a qualified electrical service technician.

PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.

The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the

goods or services to which this warranty relates.

In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a

replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a

major failure.

In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).

Two Year Warranty

Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)

Name

Address

Place Of Purchase Date Of Purchase

Name Of Product Model Number

Attach a copy of the purchase receipt to this warranty card

Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.

Goldair –New Zealand

CDB Goldair

PO Box 100-707

N.S.M.C

Auckland

Phone +64 (0)9 917 4000

Phone 0800 232 633

www.goldair.co.nz

Goldair –Australia

CDB Goldair Australia Pty

PO Box 574

South Morang

Victoria, 3752

Phone +61 (0)3 9365 5100

Phone 1300 GOLDAIR (1300 465 324)

www.goldair.com.au

Table des matières

Autres manuels Goldair Chauffage

Goldair

Goldair Platinum GPPH610 Manuel utilisateur

Goldair

Goldair GCH500 Manuel utilisateur

Goldair

Goldair GFH225 Manuel utilisateur

Goldair

Goldair GCV280 Manuel utilisateur

Goldair

Goldair PLATINUM GPCW100 Manuel utilisateur

Goldair

Goldair GCV340 Manuel utilisateur

Goldair

Goldair SELECT GSFH150 Manuel utilisateur

Goldair

Goldair PLATINUM GPCV330 Manuel utilisateur

Goldair

Goldair GCT270 Manuel utilisateur

Goldair

Goldair GFH240 Manuel utilisateur

Goldair

Goldair GSCV280 Manuel utilisateur

Goldair

Goldair GCH210 Manuel utilisateur

Goldair

Goldair 3514TC Manuel utilisateur

Goldair

Goldair GCV100 Manuel utilisateur

Goldair

Goldair GCT360 Manuel utilisateur

Goldair

Goldair GCW220 Manuel utilisateur

Goldair

Goldair GCV120 Manuel utilisateur

Goldair

Goldair GPH110 Manuel utilisateur

Goldair

Goldair GMH225 Manuel utilisateur

Goldair

Goldair GMH230 Manuel utilisateur

Goldair

Goldair GCT260 Manuel utilisateur

Goldair

Goldair ecopanel GEPH215 Manuel utilisateur

Goldair

Goldair GSOC125 Manuel utilisateur

Goldair

Goldair GCT255 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
