Operating Instructions

2000W Convector Heater with Turbo Fan

Model: GCV325

This page has intentionally been left blank.

CAUTION: In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through an external

switching device, such as a timer, or connected to a circuit that is regularly

switched on and off by the utility.

•This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities or lack of experience and

knowledge, unless they are supervised or have been given instruction

concerning the use of the appliance by a person responsible for their safety.

•Children should be supervised to ensure that they do not play with the

appliance.

•If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid a hazard.

WARNING: You must not cover this heater. Covering this heater presents

fire risk and will activate the safety fuse; permanently disabling the unit.

WARNING: Do not use this heater in small rooms when they are occupied

by persons not capable of leaving the room on their own, unless constant

supervision is provided.

WARNING: To reduce the risk of fire, keep textiles, curtains, or any

flammable material a minimum distance of 1 metre from the air outlet.

General Care and Safety Guide

•Use only the voltage specified on the rating label of the appliance.

•The heater must not be located immediately below a socket outlet.

•Keep all objects at least 1 metre from the front, sides and rear of the appliance.

•This appliance is intended for household use only and not for commercial or industrial use.

•Indoor use only.

•Use this appliance only as described in this manual. Any other use is not recommended by

the manufacturer and may cause fire, electric shock or injury.

•Do not use the heater if it has been dropped or damaged.

•The common cause of overheating is deposits of dust or fluff in the appliance. Ensure these

deposits are removed regularly by unplugging the appliance and vacuum cleaning the air

vents and grills.

•Always unplug appliance when not in use.

•When the appliance has been unpacked, check it for transport damage and ensure all parts

have been delivered. If parts are missing or the appliance has been damaged, contact the

Customer Services Team.

•Do not use if there are visible signs of damage to the heater.

YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE

INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.

•Do not connect the appliance to mains supply until completely assembled and adjusted.

•Ensure hands are dry before handling the plug or main unit.

•Ensure heater is on a flat, stable, heat-resistant surface.

•Do not operate with cord set coiled up as a heat build up is likely, which could be sufficient to

become a hazard.

•Carry out regular checks of the supply cord to ensure no damage is evident

•Do not operate this appliance with a damaged cord, plug or after the appliance malfunctions

or has been dropped or damaged in any manner. Return to a qualified electrical person for

examination, electrical service or repair.

•Do not twist, kink or wrap the cord around the appliance, as this may cause the insulation to

weaken and split. Always ensure that all cord has been removed from any cord storage area

and is unrolled before use.

•It is recommended that this heater is plugged directly into the wall socket. Power boards are

not rated to supply power to high wattage appliances.

•A correctly specified, undamaged extension cord may be used with this heater provided it is

used in a safe manner.

•Do not remove plug from power socket until the appliance has been switched off.

•Do not remove plug from power socket by pulling cord; always grip plug.

•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord so it cannot

be tripped over.

•Don’t place appliance on bedding or on thick & long carpet where the openings may get

blocked.

•Switch off and use handle provided when moving

•Do not place appliance close to radiant heat source.

•Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may

cause an electric shock, fire or damage to the appliance.

•Do not sit on the appliance.

•Do not use abrasive cleaning products on this appliance. Clean with a damp cloth (not wet)

rinsed in hot soapy water only. Always remove plug from the mains supply before cleaning.

•Do not operate in areas where petrol, paint or other flammable liquids are used or stored.

•Do not use this appliance in the immediate surrounds of a bath, a shower, or a swimming

pool or other liquids.

•The appliance must not be immersed in any liquids.

•There are no user serviceable parts installed in the unit.

•Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.

•This unit is not supposed to be used in or around locations where foodstuffs, works of art or

delicate articles of science, etc. are stored.

•If your appliance does not work, or is not working properly, contact the place of purchase or

the Customer Services Team.

General Care and Safety Guide

Assembling your Convector Heater

Main Body x 1 Screw Pack x 1

Feet x 2

Before using the heater, the feet (supplied separately in the carton), must be fitted

to the unit.

1. Carefully turn the Main Body upside-down on a scratch-free and stable surface. Be

careful to prevent damage to the cosmetic finish or your floor surfacing.

2. Attach the feet to the base of the heater by aligning the built-in position pins with

the position holes on the base of the heater and fixing a screw into the hole

between the two position holes. Use two screws for each foot.

WARNING: Heater must not be used without the feet fitted.

This appliance has been supplied with ‘1 way screws’ for permanent

installation of the feet. This is a safety requirement for the New Zealand and

Australian market.

WARNING:In order to avoid overheating or fire, do not cover the heater.

WARNING: Keep all objects at least 1 metre from the front, sides and rear

of the appliance.

WARNING: Do not use this heater with a programmer, separate timer,

remote-control system or any other device that switches the heater on

automatically, since a fire risk exists if the heater is covered or positioned

incorrectly.

WARNING:Never leave this heater unattended.

Ensure heater is on a flat, stable, heat-resistant surface.

Once the heater is in a safe operating position and all switches are in the off

position, insert the power plug into the mains outlet.

CAUTION: Ensure the power cord is not tight because if pulled it may

partially pull the plug from the socket. A partially inserted plug will overheat

the plug and socket and could result in fire.

Note: When the appliance is turned on for the first time, it may release a slight

odour or smoke. This odour or smoke is a normal occurrence caused by the

initial heating of the heating elements and should not occur again.

Operating your Convector Heater

Always choose a safe location for the heater, keeping in mind the safety precautions

outlined. Ensure all packaging has been removed from the unit before use. This

appliance requires no installation, it should be used solely as a portable appliance.

HEATER CONTROL SWITCH

O OFF

I1250W

II 2000W

I1250W with Turbo Fan

II 2000W with Turbo Fan

Check that the heat control switch is set to Off position before plugging the appliance

into the mains supply.

For greater economy, use the High Heat setting initially and then switch to the Low

Heat setting.

For the Low and High Heat settings the fan remains at the same speed; only the

wattage changes to create the greater/lesser heat output.

THERMOSTATIC CONTROL

1. Rotate thermostat knob clockwise until you reach

the maximum position.

2. When the room reaches a temperature that is

comfortable for you, slowly turn the knob anti-

clockwise until the heater just turns off (you will

hear a click).

3. The heater will now cycle on and off to maintain the

comfort level you have set.

4. Take note of this setting position for future use.

Note: When the thermostat activates you may see a small flash of light (may look like a

spark) from inside the heater. This is normal and there is no cause for concern.

Operating your Convector Heater

SAFETY DEVICES

This appliance has two protection devices:

•Tilt Switch - this will automatically turn the appliance off if the appliance is not in

the correct operating position.

•Resettable Thermal Link - this will automatically disconnect the power to the

appliance at a pre-set overheat temperature. After cooling down it will reset and

power on again. If this occurs, investigate what is causing the appliance to

overheat.

•Thermal Fuse - this disconnects the appliance permanently in case of overheating.

(It is non resettable).

CAUTION: The heater generates heat during use. Proper precautions

must be taken to prevent the risk of burns, scalds, fires or other damage to

persons.

CARE AND CLEANING

•The heater requires regular cleaning to ensure trouble free operation:

•Unplug the heater from the mains supply before cleaning.

•Ensure that the heater has been allowed to cool down completely before cleaning.

•The common cause of overheating is deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly by unplugging the appliance and

vacuum cleaning the air vents and grills.

•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and

dirt.

•Never use solutions such as petrol, thinners or polishing agents.

•Ensure the heater is dry before plugging back into the mains supply.

•Do not attempt to dismantle the appliance.

•There are no user serviceable parts. For service or repair, contact an authorised

electrical service technician

SUPPORT AND TECHNICAL ADVICE

Goldair –New Zealand

Monday –Friday 8am-5pm

Phone +64 (0)9 917 4000

Phone 0800 232 633

[email protected]o.nz

Goldair –Australia

Monday –Friday 8am-5pm

Phone +61 (0)3 9365 5100

Phone 1300 465 324

info@cdbgoldair.com.au

PROOF OF PURCHASE

To receive warranty retain receipt as proof of purchase.

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal

domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three months.

Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the

warranty period.

This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone

other than a qualified electrical service technician.

PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.

The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the

goods or services to which this warranty relates.

In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a

replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a

major failure.

In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).

Two Year Warranty

Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)

Name

Address

Place Of Purchase Date Of Purchase

Name Of Product Model Number

Attach a copy of the purchase receipt to this warranty card

Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.

Goldair –New Zealand

CDB Goldair

PO Box 100-707

N.S.M.C

Auckland

Phone +64 (0)9 917 4000

Phone 0800 232 633

www.goldair.co.nz

Goldair –Australia

CDB Goldair Australia Pty

PO Box 574

South Morang

Victoria, 3752

Phone +61 (0)3 9365 5100

Phone 1300 GOLDAIR (1300 465 324)

www.goldair.com.au

This page has intentionally been left blank.

Table des matières

Autres manuels Goldair Chauffage

Goldair

Goldair GECO255 Manuel utilisateur

Goldair

Goldair GBH100 Manuel utilisateur

Goldair

Goldair SELECT GSFH150 Manuel utilisateur

Goldair

Goldair Select GSCH215 Manuel utilisateur

Goldair

Goldair FFH222 Manuel utilisateur

Goldair

Goldair GPCT440 Manuel utilisateur

Goldair

Goldair GECO200 Manuel utilisateur

Goldair

Goldair GMH240 Manuel utilisateur

Goldair

Goldair GOC155 Manuel utilisateur

Goldair

Goldair Select GSFH110 Manuel utilisateur

Goldair

Goldair GCT325R Manuel utilisateur

Goldair

Goldair GCV100 Manuel utilisateur

Goldair

Goldair GFH260 Manuel utilisateur

Goldair

Goldair GCT340 Manuel utilisateur

Goldair

Goldair GPCV360B Manuel utilisateur

Goldair

Goldair GFH135 Manuel utilisateur

Goldair

Goldair FFH220 Manuel utilisateur

Goldair

Goldair GEOH400 Manuel utilisateur

Goldair

Goldair GSCH230 Manuel utilisateur

Goldair

Goldair GCW220 Manuel utilisateur

Goldair

Goldair GCH320 Manuel utilisateur

Goldair

Goldair GFH225 Manuel utilisateur

Goldair

Goldair GFH220 Manuel utilisateur

Goldair

Goldair Platinum GPPH620 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
