Operating Instructions

2000W Convector Heater

Model: GCV290B

CAUTION: In order to avoid a hazard due to inadvertent resetting of the

thermal cut-out, this appliance must not be supplied through an external

switching device, such as a timer, or connected to a circuit that is regularly

switched on and off by the utility.

•This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities or lack of experience and

knowledge, unless they are supervised or have been given instruction

concerning the use of the appliance by a person responsible for their safety.

•Children should be supervised to ensure that they do not play with the

appliance.

•If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid a hazard.

WARNING: You must not cover this appliance. Covering this appliance

presents fire risk and will activate the safety fuse; permanently disabling the

unit.

WARNING: Do not use this appliance in small rooms when they are

occupied by persons not capable of leaving the room on their own, unless

constant supervision is provided.

WARNING: To reduce the risk of fire, keep textiles, curtains, or any

flammable material a minimum distance of 1 metre from the air outlet.

General Care and Safety Guide

•Use only the voltage specified on the rating label of the appliance.

•Keep all objects at least 1 metre from the front, sides and rear of the

appliance.

•This appliance is intended for household use only and not for commercial or

industrial use.

•Indoor use only.

•Use this appliance only as described in this manual. Any other use is not

recommended by the manufacturer and may cause fire, electric shock or

injury.

•Do not use the appliance if it has been dropped or damaged.

•The common cause of overheating is deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly by unplugging the appliance and

vacuum cleaning the air vents and grills.

YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE

INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.

•Always unplug appliance when not in use.

•When the appliance has been unpacked, check it for transport damage and

ensure all parts have been delivered. If parts are missing or the appliance has

been damaged, contact the Customer Services Team.

•Do not use if there are visible signs of damage to the appliance.

•Do not connect the appliance to mains supply until completely assembled and

adjusted.

•Ensure hands are dry before handling the plug or main unit.

•Ensure appliance is on a flat, stable, heat-resistant surface.

•Do not operate with cord set coiled up as a heat build up is likely, which could

be sufficient to become a hazard.

•Carry out regular checks of the supply cord to ensure no damage is evident

•Do not operate this appliance with a damaged cord, plug or after the appliance

malfunctions or has been dropped or damaged in any manner. Take to a

qualified electrical person for examination, electrical service or repair.

•Do not twist, kink or wrap the cord around the appliance, as this may cause the

insulation to weaken and split. Always ensure that all cord has been removed

from any cord storage area and is unrolled before use.

•It is recommended that this appliance is plugged directly into the wall socket.

Power boards are not rated to supply power to high wattage appliances.

•A correctly specified, undamaged extension cord may be used with this

appliance provided it is used in a safe manner.

•Do not remove plug from power socket until the appliance has been switched

off.

•Do not remove plug from power socket by pulling cord; always grip plug.

•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord

so it cannot be tripped over.

•Don’t place appliance on bedding or on thick & long carpet where the openings

may get blocked.

•Switch off and use handle provided when moving

•Do not place appliance close to radiant heat source.

•Do not insert or allow foreign objects to enter any ventilation or exhaust

opening, as this may cause an electric shock, fire or damage to the appliance.

•Do not sit on the appliance.

•Do not use abrasive cleaning products on this appliance. Clean with a damp

cloth (not wet) rinsed in hot soapy water only. Always remove plug from the

mains supply before cleaning.

•Do not operate in areas where petrol, paint or other flammable liquids are used

or stored.

•Do not use this appliance in the immediate surrounds of a bath, a shower, or a

swimming pool or other liquids.

General Care and Safety Guide

•The appliance must not be immersed in any liquids.

•There are no user serviceable parts installed in the unit.

•Do not place the unit in wardrobes or other enclosed spaces as this may cause

fire hazards.

•This unit is not supposed to be used in or around locations where foodstuffs,

works of art or delicate articles of science, etc. are stored.

•If your appliance does not work, or is not working properly, contact the place of

purchase or the Customer Services Team.

General Care and Safety Guide

Main body x 1

Feet x 2 Assembly screws x 4

Components

Before using this appliance, it must have the supplied feet fitted. The screw pack to

attach the feet to your appliance will be taped to either one of the feet for your

appliance, or taped to the plug.

ASSEMBLY OF THE HEATER

Carefully turn the Main Body upside-down on a scratch-free and stable surface. Be

careful to prevent damage to the cosmetic finish or your floor surfacing.

Attach the feet to the base of the heater using the screws provided, taking care to

ensure that they are located correctly in the bottom of the heater.

WARNING: Operate the appliance in normal upright position only with feet

assemblies attached to the bottom. Any other position could create a

hazardous situation.

WARNING: Heater must not be used without the feet fitted.

This appliance has been supplied with ‘1 way screws’ for permanent installation of the

feet. This is a safety requirement for the New Zealand and Australian market.

Assembly

Operating Your Heater

Always choose a safe location for the heater, keeping in mind the safety precautions

outlined. Ensure all packaging has been removed from the unit before use. Please

follow the below instructions.

WARNING: In order to avoid overheating or fire, do not cover the heater.

WARNING: Keep all objects at least 1 metre from the front, sides and rear

of the appliance.

WARNING: Do not use this heater with a programmer, separate timer,

remote-control system or any other device that switches the heater on

automatically, since a fire risk exists if the heater is covered or positioned

incorrectly.

WARNING:Never leave this heater unattended when in use.

Ensure heater is on a flat, stable, heat-resistant surface.

Once the heater is in a safe operating position and all switches are in the off

position, insert the power plug into the mains outlet and switch on.

CAUTION: Ensure the power cord is not tight because if pulled it may

partially pull the plug from the socket. A partially inserted plug will overheat

the plug and socket and could result in fire.

Note: When the appliance is turned on for the first time, it may release a

slight odour or smoke. This odour or smoke is a normal occurrence caused by

the initial heating of the internal heating elements and should not occur

again.

HEAT CONTROL SWITCHES

“750W” - Low heat

“1250W” - Medium heat

“2000W” - High Heat (750W & 1250W switches together)

THERMOSTATIC CONTROL

1. Rotate thermostat knob clockwise until you reach

the maximum position.

2. When the room reaches a temperature that is

comfortable for you, slowly turn the knob anti-clockwise

until the heater just turns off (you will hear a click).

3. The heater will now cycle on and off to maintain the

comfort level you have set.

4. Take note of this setting position for future use.

FAN FUNCTION

In addition to the three heat settings, there is afan with a

separate On/Off switch located on the control panel.

The Fan function is for distributing heat into the room at a faster rate.

Operating Your Heater

Mode switch positions

OFF

TIMER ON

OVERRIDE

Indicates actual time

Riders pushed to the

outside rim to turn ON

TIMER

The appliance will always be on when the slide switch is in the “I” position.

The appliance will always be off when the slide switch is in the “O” position.

To set the Timer;set the MODE switch to the Timer position.

(This function can only be used once a heat level has been selected ; see thermostat

section).

You must set the time prior to programming the Timer.To do this; turn the outer dial

of the timer in a clockwise direction until the time of the day (24-hour clock)

corresponds with the triangular marking. Example if it is 2pm (1400 hours) then set

the triangular mark in line with 14. One complete turn of the dial corresponds to 24

hours.

There are 96 “riders”, positioned around the dial, each rider represents 15 minutes.

Where all the “riders” are pushed to the outside of the timer the appliance will be ON

continuously.

To set a specific time for example:

If you want the appliance to be on from 6pm to 10pm, then set all the riders from 18

to 22 (1800 hours to 2200 hours) to the outside of the rim and all other riders to the

inside of the timer. The unit will then turn on automatically at 6pm and off again at

10pm.

Operating Your Heater

SAFETY DEVICES

This appliance has two protection devices:

•Resettable Thermal Link - this will automatically disconnect the power to the

appliance at a pre-set overheat temperature. After cooling down it will reset and

power on again. If this occurs, investigate what is causing the appliance to

overheat.

•Thermal Fuse - this disconnects the appliance permanently in case of overheating.

(It is non resettable).

CAUTION: The heater generates heat during use. Precautions must be

taken to prevent the risk of burns, scalds, fires or other damage to persons.

CARE AND CLEANING

•The heater requires regular cleaning to ensure trouble free operation:

•Unplug the heater from the mains supply before cleaning.

•Ensure that the heater has been allowed to cool down completely before cleaning.

•The common cause of overheating is deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly by unplugging the appliance and

vacuum cleaning the air vents and grills.

•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and

dirt.

•Never use solutions such as petrol, thinners or polishing agents.

•Ensure the heater is dry before plugging back into the mains supply.

•Do not attempt to dismantle the appliance.

•There are no user serviceable parts. For service or repair, contact an authorised

electrical service technician

SUPPORT AND TECHNICAL ADVICE

Goldair –New Zealand

Monday –Friday 8am-5pm

Phone +64 (0)9 917 4000

Phone 0800 232 633

[email protected]

Goldair –Australia

Monday –Friday 8am-5pm

Phone +61 (0)3 9365 5100

Phone 1300 465 324

[email protected]

PROOF OF PURCHASE

To receive warranty retain receipt as proof of purchase.

Table des matières

Autres manuels Goldair Chauffage

Goldair

Goldair GCT330 Manuel utilisateur

Goldair

Goldair FFH220 Manuel utilisateur

Goldair

Goldair PLATINUM GPCV330 Manuel utilisateur

Goldair

Goldair GPPH500 Manuel utilisateur

Goldair

Goldair GFH230 Manuel utilisateur

Goldair

Goldair GFH150 Manuel utilisateur

Goldair

Goldair GMH240 Manuel utilisateur

Goldair

Goldair GCT340 Manuel utilisateur

Goldair

Goldair GCH500 Manuel utilisateur

Goldair

Goldair GCT270 Manuel utilisateur

Goldair

Goldair Platinum GPPH610 Manuel utilisateur

Goldair

Goldair GSFH210 Manuel utilisateur

Goldair

Goldair GCV120 Manuel utilisateur

Goldair

Goldair GCW300 Manuel utilisateur

Goldair

Goldair GFH267 Manuel utilisateur

Goldair

Goldair PLATINUM GPCW100 Manuel utilisateur

Goldair

Goldair GMH220 Manuel utilisateur

Goldair

Goldair GCH210 Manuel utilisateur

Goldair

Goldair GFE320 Manuel utilisateur

Goldair

Goldair GOC215 Manuel utilisateur

Goldair

Goldair GCH220 Manuel utilisateur

Goldair

Goldair GCV440 Manuel utilisateur

Goldair

Goldair Platinum GPPH620 Manuel utilisateur

Goldair

Goldair GECO200 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
