Goldair GCTF180 Manuel utilisateur
Operating Instructions
82cm Electronic Tower Fan with WiFi
Model: GCTF180
WiFi –Downloading and Setting up APP
This APP is supported only on 2.4GHz Wi-Fi channels.
The Goldair app and device pairing process require your 2.4ghz connection to
be separated from your 5ghz connection. For instructions on how to do this
please contact your internet provider.
•Tap REGISTER near the bottom of the screen.
•Read and agree to the Privacy Policy.
•Add your email address.
•Tap 'Obtain verification code'
You will then receive an email with a verification
code.
Download Goldair mobile APP
•Open the APP Store or Google Play on your mobile phone.
•Open 'Search' and enter 'Goldair'
•Click 'GET' and begin to download and install.
Once downloaded to your phone open the APP
•Enter the verification code from your email.
•Create a password.
•Then tap confirm.
If you haven't received a verification code via
email, tap the resend button and when the
verification code is received follow above steps.
Your APP is now registered and ready for pairing
to your device.
Pairing APP to Device
Connect with 2.4ghz Wifi Network
On the Home screen,
tap ‘Add Device’ or
the ‘+’ icon.
Using the categories on
the left, navigate to
your device and tap on
the image.
Confirm you are connected
to a 2.4ghz network. If your
2.4ghz and 5ghz networks
are dual banded, click
‘Common router setting
method’ on how to split, or
contact your internet
provider.
Pairing APP to Device
Connect with 2.4ghz Wifi Network: EZ Mode
The app will default to EZ Mode in the
right hand corner.
Ensure your device’s Wifi LED is flashing
rapidly.
If it is not, hold down the
“OSCILLATION” button for 5 seconds or
until the Wifi icon begins to flash.
Click ‘Confirm indicator rapidly blink’
and ‘Next’
See instructions below to finalise your device pairing via EZ mode.
Your device will now pair with the app.
Please ensure your device, modem and
phone are as close together as possible
and that your 2.4ghz Wifi signal is strong.
Once the device has paired, choose
to rename it by tapping the Pen icon
Choose the most suitable room type and
click ‘Done’ in the top right hand corner.
Pairing APP to Device
Change ‘EZ Mode’ to ‘AP Mode’ by
clicking in the top right hand corner
Ensure your device’s Wifi LED is
flashing slowly.
If it is not, hold down the
“OSCILLATION” button for 5
seconds or until the Wifi icon
begins to flash.
Click ‘Confirm indicator slowly
blink’ and ‘Next’
Click ‘Go Connect’ to
connect to the device’s
Hotspot by selecting the
network highlighted on the
screen in your app, e.g.
‘SmartLife- XXXX’
Select the device’s Hotspot
network and you will be returned
to the app. If not, navigate back to
the Goldair app.
Note- if you get a notification
saying ‘Internet may not be
available’ press Dismiss.
Your device will now pair
with the app.
Please ensure your
device, modem and
phone are as close
together as possible.
Connect with 2.4ghz Wifi Network: AP Mode
See instructions below to finalise your device pairing via AP Mode.
Once the device has paired,
choose to rename it by
tapping the Pen icon
Choose the most suitable
room type and click ‘Done’
in the top right hand
corner.
Pairing APP to Device
Connect with Bluetooth
On the Home screen, tap ‘Add
Device’ or the ‘+’ icon.
Ensure your device’s Wifi LED is
flashing rapidly.
If it is not, hold down the
“OSCILLATION” button for 5
seconds or until the Wifi icon
begins to flash.
On the top right, click ‘Auto
Scan’
The app will now scan for
Bluetooth devices.
When your device appears, click
on the image.
As an alternative way of connecting your device, you can pair via Bluetooth. Please
ensure you have Bluetooth switched on on your mobile phone.
Choose your 2.4ghz Wifi
network and add in the
password. Click ‘Next’
Your device will now pair
with the app.
Please ensure your
device, modem and
phone are as close
together as possible.
Once the device has paired,
choose to rename it by
tapping the Pen icon
Choose the most suitable
room type and click ‘Done’
in the top right hand
corner.
Operating your Fan from the APP
Device settings
Current room
temperature Current mode
setting
Power ON/OFF
button
Wind Speed
button
Mode button
Countdown
timer button
Oscillation/Swing
button
Anion button
Operating your Fan from the APP
POWER
Click the Power Icon to turn the Fan ON/OFF
WIND SPEED
When the fan is turned on, it will default to Speed
Level 1. Move the slider to the middle to activate
Speed Level 2, or to the right to activate Speed
Level 3.
MODE
When the fan is turned on, it will default to Normal mode.
Click the relevant icon to move to Natural and Sleep mode.
Normal: The fan will operate a consistent wind at the speed
of your choice
Natural: the speed changes every 5 seconds in a cycle from
low to medium to high to medium to low to medium to high
to medium to low etc.
Sleep: the sleep function first runs at high speed for half an
hour, then at the medium speed for half an hour, then at low
speed until the fan is switched off.
Operating your Fan from the APP
OSCILLATION
Click the Left and Right Swing icon to turn on
oscillation.
ANION
Click the Anion icon to turn on Anion.
COUNTDOWN TIMER
Move the countdown slider to the hour off choice
to set a timer to turn the fan OFF. Choose between
1-12 hours in 1 hr increments.
Set up Tap-To-Run & Create Smart Scenes
Store your favourite settings or set up automated
functions based on conditions in the ‘Smart’ part
of your Goldair app.
Warning- you must remember to turn off any
Smart functions prior to leaving the house or
going away. We recommend you only operate
your Goldair devices when someone is on the
premises.
•Tap ‘Smart’ on the bottom of your mobile phone.
•Tap ‘Create Scene’ or the ‘+’ icon on the top
right.
Click ‘Launch Tap-to-Run’ to save your preferred settings
on your devices to launch at the click of a button. Click
‘Run the device’ and choose a device. Preset your desired
functions such as Power ON/OFF, temperature, mode and
timer as per on the device’s functions. Click ‘Next’
Review your conditions and tasks on this screen, or
choose to add another device or task by clicking the ‘+’
icon.
Click Save to store your settings and your new task will
appear on the Smart homepage. Click it to operate your
desired task.
