Gold Note CD-1000 MKII Manuel utilisateur

USER
MANUAL
CD-1000
EN
DE
IT


Thank you for purchasing one of our units
and welcome into the Gold Note world,
where we turn High-End audio and music
into a new experience.
Maurizio Aterini,
founder of Gold Note
EN
DE
IT

|
IMPORTANT SAFETY
| INFORMATION
the third prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet. or
pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
|Only use attachments/accessories specied
by the manufacturer.
|Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
|Unplug this apparatus during lightning
storms or when unused for long periods
of time. Refer all servicing to qualied
service personnel only. Servicing is required
when the apparatus has been damaged in
any way (such as when the power cord or
plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture) and in any case when the
apparatus does not operate normally or
has been dropped.
PLEASE NOTE
1 Do not disassemble any part of the
product.
2 Do not use any part of the product for
other purposes.
3 For service and problems of any kind,
contact qualified Gold Note personnel.
4 Protect the product from rain, humidity
and keep away from heat sources, electric
and electronic motors etc. The power
cord supplied must be used only on this
unit.
5 Gold Note does not have responsibility
for any improper use of this unit.
GENERIC INFORMATION
|Read these instructions and store them.
|Heed all warnings.
|Follow the instructions.
|Do not use this apparatus near water.
|Clean only with a dry cloth.
|Do not block the ventilation openings
and install in accordance with the
manufacturer’s instructions.
|Do not install near heat sources such as
radiators, heat registers, stoves or other
apparatus (including ampliers) that
produce heat.
|Do not defeat the safety purpose of
the polarised or grounding-type plug: a
polarised plug hastwo blades with one
wider than the other.
|A grounding type plug has two blades and
a third grounding prong. The wide blade or

EN
DE
IT
This appliance has a serial number located on the rear panel.
Please record the model and serial number and retain them for your records.
MODEL
SERIAL NUMBER
CAUTION!
To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable
parts inside. Refer only to qualified Gold
Note service personnel for service.
WARNING!
To prevent fire or shock hazard, do not
expose this appliance to rain or moisture.
GOLD NOTE - Information on the correct management of waste from
household Equipment pursuant to the European Directive 2012/19/EU
The crossed-out wheelie bin symbol shown on the equipment or its packaging indicates
that the product, at the end of its useful life, must be collected separately from other waste
to allow its proper treatment and recycling. The user must therefore deliver, free of charge,
the end-of-life equipment to the centres for the separate collection of waste electrical and
electronic equipment, or return it to the dealer in accordance with the procedures established
by the legislation.
The appropriate separate collection of discarded equipment allows for proper recycling,
treatment and environmentally compatible disposal, helping to avoid the possible dispersion
of hazardous substances and negative effects on the environment and health, favouring
the reuse and/or recycling of the materials of which the equipment is composed of. Illegal
dumping of the product by the user involves the application of administrative sanction
provided for by the legislation in force. We invite you consult the current legislation and the
measures adopted by the public service operating in your country or territory.


| INDEX
| PACKAGE CONTENT
INTRODUCTION AND FEATURES 1
TECHNICAL SPECIFICATIONS 2
FRONT PANEL 3
REAR PANEL 4
DISPLAY 5
REMOTE CONTROL 6
PRODUCT REGISTRATION 7
TROUBLESHOOTING 8
RELATED PRODUCTS 11
1x
CD-1000
1x
POWER
CABLE
1x
USER
MANUAL
1x
REMOTE
CONTROL
EN
DE
IT

| INTRODUCTION AND FEATURES
POWER SUPPLY
The CD-1000 is powered by a proprietary
Dual-Mono power supply. The power supply
provides an extremely stable voltage,
reducing speed fluctuations and enhancing
audio performance. The power supply stage
is designed to reduce the background noise
and RFI/EMI interferences.
PLEASE NOTE
The mechanism features a recessed disc-
loading area so it’s important to align the
disc at the center before closing the tray to
avoid the risk of jamming.
CD-1000
Looks amazing, sounds even better:
introducing CD-1000, the most musical
High End CD Player we have ever designed.
Integrating digital and analogue stages into
one, versatile source. The CD-1000 features
a top-class 24bit 192kHz high-resolution
D/A converter with S/PDif coaxial and TOS
optical digital inputs to deliver extraordinary
performance.
TRANSPORT MECHANISM
The transport mechanism, the acclaimed
JPL2800 drawer type by the Austrian
Stream-Unlimited, guarantees top audiophile
performance. Made of aluminium, its design
enables the smoothest rotational stability
and minimises speed fluctuation.
OUTPUT STAGE
The CD-1000 output stage is a fully
balanced, solid-state design centred on
the high-quality Dual-Mono PCM1796 and
PCM1792A D/A chipset by Burr-Brown.
Optionally, the CD-1000 can be enhanced
with our exclusive tube output stage - a
discrete external unit designed with Class-A
components, double triode tubes, and an
ultra-low distortion power supply with low
impedance output. The result is a warm,
exceptionally analogue presentation of the
sound.
MODULAR PHILOSOPHY
The CD-1000 may be equipped with
dedicated external devices to enhance the
performance of the CD player to top audio
performance, such as the external Tube
Output Stage and the dedicated Power
Supplies.
1

2
MAIN FEATURES
|D/A Converter:
24bit/192kHz DAC PCM1792A
|Frequency response:
20Hz-20kHz @ ± 0.3dB
|THD – Total Harmonic Distortion:
0.001% max
|Signal to noise ratio:
128dB
|Dynamic response:
127dB
|Output impedance:
50Ω
|Mechanism:
Aluminium JPL-2800 Stream-Unlimited
|Speed uctuation:
0.0001%
|Volume control:
Digital partializer, switchable ON/OFF
(off by default)
DIGITAL INPUTS
RCA S/PDIF coaxial
TOS-Link asynchronous 24bit/192kHz
ANALOGUE OUTPUTS
RCA unbalanced @ 2V
XLR balanced @ 2V
Tube Stage
| TECHNICAL SPECIFICATIONS
DIGITAL OUTPUTS
Coax S/PDIF 75Ω
FORMATS
|CD formats:
Red Book
|Disc compatibility:
CD, CD-R, CD-RW, MP3
POWER
|Dual-Mono Power supply:
100-120V or 220-240V, 50/60Hz
|Power consumption:
30W
|Fuse
220/240V 1A F/T
100/120V 2A F/T
DIMENSIONS AND WEIGHT
Dimensions:
430mm W | 135mm H | 375mm D
Weight:
Kg. 12
Kg. 16 - boxed
EN
DE
IT
1x
1x
1x
1x
1x
1x

| FRONT PANEL
LED status light
1
1
Display
4
Skip & Search forward
8
IR
2
2
Eject
5
Stop
9
CD Tray
3
3
45 6 7 8 9 10
Skip & Search reverse
7
Play & Pause
6
Standby
10
3
FRONT PANEL OVERVIEW
