Goclever TAB A972BK Manuel utilisateur

TAB A972BK

OWNER’S MANUAL

TAB A972BK

INSTRUKCJA OBSŁUGI

VISIT OUR WEBSITE

WWW.GOCLEVER.COM

TO SEE MORE PRODUCTS TAB, NAVIO, DVR, DVB-T

Read this manual before installation and use.

Spis treści / Contents

English

Polski

Product Interface

Interface using instruction

Product Specification

Unlocking the Device

Camera

Home

Main Menu

Wi-Fi Setting

Web Browser

Browsing Picture and Video Files

File Manager

Music Player

Application Software Installation

Bluetooth connect

English

Product Interface

1. Connect keyboard

2. Power ON/OFF keyboard

3. miniUSB charge keyboard

4. Camera back 2Mpix

5. Power ON/OFF

6. Volume +

7. Volume -

8. Reset

9. DC-in port 5V

10. miniUSB OTG 2.0

11. miniHDMI 1.3

12. Audio out 3.5mm

13. microSD HC

14. Microphone

15. Speaker

Interface Using Instruction

Earphone jack: 3.5mm high durability, for using earphones.

Charging indicator: green icon will increase when charging.

Front Camera: for video chatting.

Power Key: to turn on or turn off your tab, press and hold it for 2 seconds; sleep your tab

by quickly pressing it and press it again to wake up the touch screen; press and hold it

for 4 seconds, the tab will be forced to close.

Microphone: for recording or internet phone.

Power (DC) Input: charge your tab with the matched adapter.

Micro 5 PIN USB Port: connect to PC to copy data or install applications.

Touch screen.

Speaker. By default is turned on. While using earphones the speaker will turn off

automatically

Micro SD Slot: support Max. 32GB Micro SD card

HDMI Port: connect it to a compatible TV or monitor for a clearer and even more

engaging experience.

Rear Camera: take photo or video recording.

Volume Key-: reduce the volume for video and music playing.

Volume Key+: increase the volume for video and music playing.

Product Specification

Operation System

Android 4.0

Processor (CPU)

ARM Cortex-A8 1GHz

RAM

1GB DDR3

ROM

Nand Flash 4GB/8GB/16GB (Optional)

LCD

9.7`1024*768 ,TFT Display

Touch panel

Capacitive Touch panel

2D/3D

ARM Mali400

Graphic

OpenGL ES2.0

Wi-Fi

Supports 802.11b/g/n standard, supports local WAPI wireless protocol

standard

3GExternal

CDMA2000 EVDO/ WCDMA and TD-

SCDMA .For optional 3G module to realize 3G communication.

microSD

expansion External MICRO SD slot, max. 32GB card.

USB

USB high speed 2.0 .Can be connected to the computer to copy files.

VPU

Maximum support hardware decoding 2160p.

Gravity

Built-in 3D gravity sensor, 360 degree rotation. Supports gravity sense

games.

Audio

AC'97 full-duplex codec, support AAC\ AMR\ MP3\ WMA \WAV \MIDI and

so on.

Video

WMV/ASF/MP4/3GP/AVI/MKV/VC-1/DIVX/MPEG-2/MPEG-4/H.263/ H.264

720P HD1080i

Game

Support several of entertainment games based on Android platform.

Web

Support many internet applications like web, social, video, chatting and so

on.

E-book

Assemble e-book tool to read based on Android platform.


Frame Built-in photo player, and take it as a photo frame or calendar.

Office

Support various of office software based on Android platform, to realize

office functions such as Word\Excel\PPT\PDF.

Unlocking the Device

Point the unlock key, slide the lock icon to the edge of the circle to unlock the device and

enter into main interface. You can change lock screen in the settings.

Camera

Point the unlock key, slide the lock icon to the edge of the camera icon to activate camera

mode. You can also access camera mode in the main interface.

Home

A. Back button.

B. Desktop button.

C. Last open.

D. Volume -

E. Volume +

F. Task notification bar.

G. USB connected. Select to transfer files with computer.

H. USB debugging connected. Select to disable USB

debugging.

I. Clock.

J. Wi-Fi signal.

K. Bluetooth state.

L. Battery state.

M. Search.

N. Desktop.

O. Menu (all applications).

To remove application shortcut from your desktop, simply touch and drag the icon to the

recycle bin (as picture shows)

Main Menu

Click Settings icon to enter settings menu (as picture shows)
