Global Sat LT-200 Series Manuel utilisateur

GlobalSat LT-200 Series

User Manual

Version: 1.1

GlobalSat WorldCom Corporation

16F., No. 186, Jian 1st Rd, Zhonghe Dist.,

New Taipei City 23553, Taiwan

Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899

service@globalsat.com.tw

www.globalsat.com.tw

USGlobalSat Incorporated

14740 Yorba Court Chino, CA 91710

Tel: 888.323.8720 / Fax: 909.597.8532

sales@usglobalsat.com

www.usglobalsat.com

TABLE OF CONTENTS

1. Warning ................................................................................................................................................. 3

2. Welcome................................................................................................................................................ 4

3. Introduction and Features...................................................................................................................5

3.1 Introduction.....................................................................................................................5

3.2 LED Indicators................................................................................................................6

4. Device Operation.................................................................................................................................. 7

4.1 Device charging ..............................................................................................................7

4.2 Power ..............................................................................................................................8

4.3 Geo-fence button.............................................................................................................9

5. Contact Information ...........................................................................................................................10

6. Safety Information..............................................................................................................................10

7. Limited Warranty ................................................................................................................................ 11

1. Warning

USE RESPONSIBLY. READ ALL INSTRUCTIONS AND

SAFETY INFORMATION BEFORE USE.

Globalsat Worldcom Corporation / USGlobalsat, Inc., will not accept any responsibility

whatsoever for accidents or violations of local Laws resulting from failure to observe

common sense precautions and local laws. Your personal judgment, traffic regulations,

and common sense must always take precedence over any directions produced by GPS

receiver or the mapping software.

Indemnification:

User agrees to defend, indemnify and hold harmless GlobalSat WorldCom Corp. and USGlobalsat,

Inc., its officers, directors, employees and agents against and from any third party claims, actions,

damages or demands, including but not limited to, reasonable legal and accounting fees, resulting from

user's use or misuse of this product, violation of these Terms, or any activities related to this product, or

from user's violations of the rights of any other user of this product. Use of this Product is at user's own

risk.

2. Welcome

Thank you for purchasing the GlobalSat LT-200. The LT-200 is a sleek, compact and

feature rich asset monitoring tracking device. The LT-200 unit incorporates a wide array of

custom feature, functions and configurations for unique client requirements. We

appreciate your purchase of a GlobalSat Worldcom Product!

3. Introduction and Features

3.1 Introduction

LT-200 is a LoRa tracking device with fast GPS acquisition time. It is compact, portable

and stylish in design capable to connect LoRa wireless networks. Users can easily and

remotely configure LT-200 and display GPS locations on remote monitoring / tracking

platforms. LT-200 is set to work with Moving Object Security & Tracking Solution.

(M.O.S.T.)

1 Geo-fence Button

2 Power LED

3 LoRa LED

4 GPS LED

5 Power Button

6 Battery Charging Contacts

7 Lanyard Holes

3. Introduction and Features (Continued)

3.2 LED Indicators

Power Status LED

LED

Orange

Constantly Lit

Orange

Blinking Red

Constantly Lit

Red Blinking

Quickly

State LT-200 is fully

charged. LT-200 is being

charged. Battery power is

low USB

configuration

mode

LoRa LED

LED

Blinking Quickly

State Data transmitting.

GPS LED

LED

Blinking Quickly

(Once per second)

Blinking Slowly

(Once every 3 seconds)

State LT-200 is searching for GPS fix

LT-200 receives GPS fix

4. Device Operation

4.1 Device charging

Using the device for the first time, rechargeable battery will require a complete 100%

charge before LT-200 is operable. To maximize your device’s battery life, proceed by

performing the steps listed below.

1. Connect the charging clip to LT-200's battery charging contacts and connect the

USB side to AC adaptor.

2. Allow at least 4 hours of battery charging time.

4.2 Power

1. To turn the device “ON”, press and hold the power button for 3 second.

2. To turn the device “OFF”, press and hold the power button for 3 seconds until the

device vibrates.

3. To perform a hard reset, press and hold the power button for 8 to 10 seconds.

4.3 Geo-fence button

Activate geo-fence function:

While pressing and holding the geo-fence button for 2 seconds, LT-200 would beep and

start to get GPS fix. It would keep beeping till device gets GPS fix. After getting GPS fix, it

would beep for 1.5 seconds, vibrate, and make itself as the center of the circular

geo-fence area whose radius is 200 meters (default value).

If device moves out the geo-fence area, device would trigger the alarm action of beeping 3

times and then turn silent for 1.5 seconds and repeat the alarm action till device return the

geo-fence area or pressing and holding the geo-fence button for 2 seconds.

Deactivate geo-fence function:

Pressing and holding the geo-fence button for 2 seconds would make device beep twice

and vibrate. Then the geo-fence function is deactivated.

5. Contact Information

GlobalSat WorldCom Corporation

Address: 16F., No.186, Jian 1st Rd., Jhonghe Dist., New Taipei City ,

Taiwan TEL: +886-2-82263799 FAX: +886-2-82263899

6. Safety Information

•Please consult your airline prior to the operation of this product in the aircraft. . Operating this

product in environments emitting intensive radio waves or radiation can affect the operation and

functionality of this product.

•Avoid use in humid or rainy environment. Water ingress can disable or destroy this product beyond

repair.

•Avoid using this product in a dusty environment. Dust ingress can compromise the products ability

to function.

•Avoid situations that include Over-voltage, over charging, power cable damage may cause

overheating or potential fire disaster.

•Never use any chemical or detergent to clean the Personal Tracker to prevent erosion of the surface

or paintwork.

•In order to eliminate the risk of electric shock, make certain the charging cable is completely

inserted / seated, do not touch the power cable plug / connectors with wet or damp hands.

•Do not charge the Device in any extreme cold or hot temperatures, which may cause damage to the

device.

•Keep out of the reach of children during charging.

•Avoid direct prolonged exposure to sunlight and high temperatures to avoid the potential

over-heating of the battery of this product, which may cause damage.

•Please do not attempt to repair this device yourself, contact Globalsat or USGlobalSat for Technical

Support.

•Keep all the wires tidy in order to prevent damage or tangling.
