GLOBALSATTECHNOLOGYCORPORATION

16F., No.186, Jian Yi Road, Chung Ho City ,Taipei Hsien,Taiwan

T:886-2-82263799 F:886-2-82263899

Page1of2

BT-359 Bluetooth GPS Receiver Specification

ELECTRICAL CHARACTERISTICS

GPS standard SiRF StarⅢ

GPS Antenna Built-in ceramic patch antenna

Bluetooth standard Bluetooth V2.0

Operation range 10 meters (33 feet)

Bluetooth Default PIN 0000

Operation time > 10 hrs

Charge time < 5 hrs

Automatic Shut-Off After 10 minutes of no active Bluetooth connection

Charge Connector Mini USB

ON-OFF button

Turn ON Press the ON-OFF button for approximately 1 second to turn the

Turn OFF Press the ON-OFF button for approximately 1 second to turn the

Perform Reset Press the ON-OFF button for approximately 5 seconds will

LEDs

GPS Status Flashing – GPS position is not fixed

Power Status Solid Red – Battery voltage is low

Bluetooth Status Flashing (Slow) – Not connected to a Bluetooth device

Temperature

Operating -10°C ~ 60°C

Storage -20°C ~ 70°C

Humidity Operational up to 95% non-condensing

Power

DC Power Input 4.5V~5.5V / 0.5A

Battery

Battery Type Lithium –ion Rechargeable Battery

Battery Capacity 1200mAh

Mechanical

Dimension 82.0 mm x 41.0 mm x 13.4 mm

GLOBALSATTECHNOLOGYCORPORATION

16F., No.186, Jian Yi Road, Chung Ho City ,Taipei Hsien,Taiwan

T:886-2-82263799 F:886-2-82263899

Page2of2

GPS Specifications

Electrical Characteristics

GPS Chipset SiRF Star III

Frequency L1, 1575.42 MHz

C/A Code 1.023 MHz chip rate

Channels 20 channel all-in-view tracking

Accuracy

Position Horizontal 10 meters, 2D RMS

Velocity 0.1m/sec

Time 1 micro-second synchronized to GPS time

WAAS WAAS enabled only for North America sales

Datum

Datum Default: WGS-84

Acquisition Rate

Hot start 1 sec., average

Warm start 38 sec., average

Cold start 42 sec., average

Reacquisition 0.1 sec. average

Protocol

GPS Protocol Default: NMEA 0183 (Secondary: SiRF binary)

GPS Output format GGA(1sec), GSA(1sec), GSV(5sec), RMC(1sec), GLL,

Dynamic Condition

Acceleration Limit Less than 4g

Altitude Limit 18,000 meters (60,000 feet) max.

Velocity Limit 515 meters/sec. (1,000 knots) max.

Jerk Limit 20 m/sec**3

Bluetooth Specification

Electrical Characteristics

Bluetooth Chipset CSR BC4

Frequency 2402MHz to 2480MHz

Standard Bluetooth V2.0

Bluetooth Profile SPP (Serial Port Profile)

Operation Range 10 meters (33 feet)

Output Power 0 dBm (class II)

NORTH AMERICAN SALES & SERVICE

1308 John Reed Court, City of Industry, CA 91745 USA

(626) 968-4145 ▪[email protected] ▪www.usglobalsat.com
