User’s Manual
D39
PHOENIX
INTRODUCTION
Thank you for choosing the D39 Power Wheelchair for your portable wheelchair trans-
portation needs. It is important to read through this manual before operating your D39
Power Wheelchair to become familiar with its features as well as its limitations and safety
information.
You will find the operation and care of your D39 Power Wheelchair simple and easy.
Disclaimer:
As part of our ongoing product improvement initiative, we reserve the right to change
specifications and design without notice. As a result, there may be minor differences be-
tween your D39 Power wheelchair and accessories and the photos, illustration and instruc-
tion in this manual.
Dear Users,
JBH and partners cannot be held responsible for personal injury or property
damage resulting from the unsafe or improper operation or maintenance of
D39 Power wheelchair.
We strongly believe that the wheelchair would bring you more convenient and reach the
goal of free life to you. If you discover a problem, contact your authorized local Dealer or
Distributor for assistance, alternatively direct contact with manufacturer with the following
Contact Information.
Recommendation
Please pay attention to “Warning” in the manual is to protect you from any injury.
Unable to follow “Notification” in this manual may result in damage the wheelchair.
www.jbhmedical.com
www.jbhmedical.com
We
CONTENTS
.........................................................................................
Specification Diagram
Specifications
....................................................................
Product Related Explanation
Product Features
................................................................................................
Install Setup .............................................................................................................
Controller
...........................................................................................................
.......................................................................................
Charging Batteries
..................................................................................................................
Free Wheel Mode
Transporting D39
...............................................................................................
Trouble Shooting And Maintenance
Electrical Wiring Diagram
Electromagnetic Interference & Compatibility
...................................................................................................
Diagnostics
...................................................................................................
.....................................................................................................................
............................................................
..............................................................................................................
.................................................................................
Warranty
.......................................
Warranty Card........................................................................................................
5
.......................................................................................
6
...............................................................................................
.................................................................................
7
8
3-4
9-17
18-20
21
22
23-26
27-31
31
32
43-47
48
......................................................................................... 1-2
Security Guidance
Safe Use Guideline
Battery Setup
Folding And Unfolding
Symbol Definition
34-38
33
42
39-41
www.jbhmedical.com
1
SYMBOL DEFINITION
Warning
Beware of potential hazard
Type B applied part
Refer to instructions for
use - Mandatory
Failure to read the instruc-
tions for use could intro-
duce a hazard
Refer to instructions for
use - Recommended
Failure to read the instruc-
tions for use could intro-
duce a hazard
IPX
IP Water proof grade
Type BF applied part
Medical device
Importer
Distributor
Country of Manufacture
=Radio frequency fields
beyond this point may
exceed FCC general
public exposure limit
Name and Address of
European Union
Representative
Unique Device
Identification
Model Number
Attention, see
instruction for use
Date of manufacture
Manufacturer Product fulfill
WEEE directive
Serial number
Batch number
CE mark
Use until year &
month (Expiration date)
Don’t use when packing
damaged
EC REP
UKCA mark
www.jbhmedical.com
2
Type 2 device
Protect from heat and ra-
dioactive sources
Store in clean & dry place
protected from rain, snow,
ice, salt and water.
Humidity limitation Temperature limitation
Avoid contacting with rain,
snow, ice, salt and keep-
ing in water, keep under
clean and dry ambience.
Do not adapt battery which
is with different capacity
and wrong model number.
With potential explosion
100～240VAC, 50～60 Hz
Never combine use long
time used battery with new
battery at the same time,
always change batteries in
brand new condition.
Disposal and recycling only
authorized recycling com-
panies can recycle parts of
this mobility wheelchair
Package Number
Foot Switch
Power
500VA
Frequency
DC output +29.4V 2.0 A
Danger of explosion
Keep dry
CF application part
Volume control
Fuse
Equipotential
Switch
PCTB
Do use cel phone, remote
speakers, note book com-
puter or other wireless
ejecting device while op-
erating the unit.
Easy to be crashed, crash-
ing spot
Keep away other metal re-
lated items or tools away
from the negative and posi-
tive terminal end to avoid
any short cut or electricity
shock from happening.
The product has passed
electromagnetic test of
20 V/M.
Implication of flammable
material. Do not expose
under fire, fire sparkles
and other heat sources
conditions. Never trans-
port batteries along with
torch easy explosive
items or flammable mate-
rials.
Battery contains an-
ti-corossion chemical
substance.
www.jbhmedical.com
SECURITY GUIDANCE
3
Weight limitations
The user must perform all of the procedures in this manual.
This product is suitable for users with age between 18 to 75 years old.
Do not drive on public highway.
No over cross any gap which is over 100 mm (3.94") in width.
Never try to overpass obstacle which is over 40 mm (1.57") in height.
Wheelchair is suitable for both outdoor and indoor use, hospital, senior center,
family or similar circumstances use only.
The suitable environment of using electric wheelchair:
Temperature -10 ～+50℃, Atmospheric Pressure 860 ～1060hPa, Humidity
10% ～93%.
Power Source Condition:
Charging Voltage AC (100-240)V ± 10%, 50 ± 1Hz, Battery Voltage DC 24V
(+5%, -10%), Power of Motor ≥250W environmental conditions that might be
harmful to the wheelchair (e.g. inclines greater than 12 degrees, rain, snow,
ice, etc.), such as temperature and humidity.
Operate wheelchair after it is under unfolded condition and only allow one
person on wheelchair all time.
1.
2.
3.
4.
5.
6.
7.
8.
9.
WARNING ！
WARNING ！
WARNING ！
We are not responsible for any damage and inquiry cause due to
over weight.
Not to drive on dangerous slopes.
Not to drive backwards when going up and down a hill. Max grad
ability is uphill 8°.
The wheelchair is tested with simulation of human model at 300kgs (661.4 lb)
load capacity.
Your wheelchair is rated for a maximum weight capacity. Please refer to the
product specifications table for this limit. Keep in mind that the maximum
weight capacity includes the combined weight of the user and any accessories
mounted to the wheelchair. Stay within the specified weight capacity of your
wheelchair. Exceeding the weight capacity voids your warranty. We will not be
held responsible for injuries and/or property damage resulting from failure to
observe weight limitations.
1.
2.
www.jbhmedical.com
4
Statement
Instructions
The wheelchair (Model D39) has a base with alumini-
um alloy frame, two front wheels, two rear wheels, a
seat, an adjustable steering column, a tiller console, an
electric motor, an electromagnetic brake, 2 recharge-
able Lithium-Ion Batteries with an off-board charger.
The movement of the wheelchair is controlled by the
rider who operates the throttle lever, speed control dial
and handle on the tiller console. The device is installed
with an electromagnetic brake that will engage auto-
matically when the wheelchair is not in use and the
brake cannot be used manually. The wheelchair only
can be operated on the flat road.
Indications for use:
It is a motor driven, indoor and outdoor transportation vehicle with the intend-
ed use to provide mobility to a disabled or elderly person limited to a seated
position.
Please read the following statement.
Please read this manual carefully and understand everything clearly before
using the electric wheelchair for the first time.
1.
2.
Improper use will cause death or serious injury.
Improper use will cause damage of wheelchair.
Comply with the manual to keep wheelchair in good condition.
DO NOT make sharp turns at high speed or on inclines or reverse direction
abruptly.
DO NOT utilize brake release / freewheeling option on any incline without as-
sistance to control motion.
To avoid danger of suffocation, keep all the plastic bag in the package away
from babies and children. Do not use the plastic bag in cribs, beds, carriages
or playpens. The plastic bag is not a toy.
1.
2.
3.
4.
5.
6.
Please do not use the wheelchair in any unclear cases, otherwise, the product
may be damaged or people may get hurt. If you have questions, please con-
tact us.
Please pay attention to the warning and cautions in this manual. We are not
responsible for any injury and damage caused by wrong use of this product
and neglect of the warnings and cautions.
1.
2.
www.jbhmedical.com
5
PRODUCT FEATURES
Based on Electric Shock Proof Classification: Classified as internal power type
device during operation, it is type 2 device while it comes to charging.
Based on classification of Electric Shock Proof: It belongs to B type applicable
section.
Based on classification of liquidity proof: IPX 4
Based on the the safety classification of using combustible anesthetic gas mixed
with air, Oxigen, or flammable anesthetic gas mixed with nitrous oxide: Not
AP/APG type.
Classification of running mode: Continuously-running mode.
Rated Voltage and Frequency: Internal power DC 24, Charger AC 220 V / 50 Hz.
There is no applicable protection of defibrillation discharge effect.
There is no signal input .
The product is not belong to eternal installation.
For electrical insulation diagram, please refer to photo 1.
1.
2.
3.
4.
5.
6.
7.
8.
9.
AC 220 Charger
Battery
Product features
Controller
Motor
Driving Device
AP
Photo 1
10.
www.jbhmedical.com
6
PRODUCT RELATED EXPLANATION
Intended user, with visual weakness, intellectual impairment or
neck disease, who is unable to observe environment on the back,
should be operated by others. Anyone with paraplegia below the
chest, osteoporosis or hypochondriasis is prohibited to use the
product.
Model no.
Year
Month
Serial No.
Please refer to QR code on frame
【Frame No.】 D39-2018-05-001
【Contraindications】
【Eternal Identification Mark】
xxxxxxxxxxxx
【 Label of the Wheelchair 】
The product is for people with inconvenience of having ability to walk fully or
having or with disabilities (excluding obesity).
【Intend Use】
www.jbhmedical.com
SPECIFICATIONS
7
Seat back/
Push handle
Backrest cushion
with storage bag
Storage bag
Rear wheel
Fender
Armrest
Controller
Controller knob
Seat cushion
Footrest
Battery
Front wheel Anti-till wheel
Gross Weight (With Export Packing)
Model D39
Aluminum Alloy
Rear Drive
Intelligent Electromagnetic Brake
Material
Loading Capacity
Motor
Driving Range
Front Wheels
Rear Wheels
Climbing Slope
Charging Time
Width Between Armrest
Seat Width
Seat Depth
Seat Height
Turning Radius
Drive Model
Braking System
Max Speed
Battery
6~8 hours
Max 8°
Fold Size (L * W * H) (mm/inch)
250W × 2 pcs brushless motors
24V 10AH × 2 pcs lithium battery
6 km/h (3.7mph)
35 km (21.7 miles)
12.5" PU solid wheels
900 mm (35.4")
Unfold Size (L * W * H) (mm/inch)
Net Weight (Without Battery)
Net Weight (Finished Product)
8.5" PU solid wheels
500 mm (19.7")
500 mm (19.7")
560 mm (22")
600 mm (23.6")
40 kgs (88.2 lbs)
44 kgs (97 lbs)
51 kgs (112.4 lbs)
1200 × 660 × 1100 mm (47.2"×26"×43.3")
660 × 360 × 890 mm (26"×14.2"×35")
300 kgs (661.4 lbs)
www.jbhmedical.com
Table des matières
Autres manuels GILANI ENGINEERING Fauteuil roulant
GILANI ENGINEERING
GILANI ENGINEERING TEW121LF1 Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING JRWD1003 Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING FALCON Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING GED09 Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING GED09 Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING DY01112 Manuel utilisateur
GILANI ENGINEERING
GILANI ENGINEERING Air Hawk Manuel utilisateur
