Gigaset pro

Maxwell 3

Version February 2018

Quick start guide

Gigaset pro Maxwell 3 Quick start guide

Introduction

This quick start guide demonstrates key features of

the Gigaset Maxwell 3 combined with the Broadsoft

platform and is designed to help you learn the basics

quickly.

Please note that most of the functions described here

depend on the features assigned to the account to be

used with the telephone. Some of the features can be

configured and enabled by you and/or by your admini-

strator.

Basic Call Features

Call Transfer Attended

Call Transfer Un-Attended

Blind Transfer

Call swapping

Conference Call

Call forward always

Call forward busy

Call forward No Answer

Busy Lamp Field (BLF)

Call Center (ACD)

Remote Office

Additional Information

Additional information is available and can be found: http://wiki.gigasetpro.com

!This quick start guide is based on the software dd: February 2018,

Maxwell 2.22 and the then available Broadsoft release.

Basic Call Features

The following basic call features are supported.

Feature Action

Make Call >Enter the number and lift the handset.

> Enter the number and press the centre key.

>For handsfree enter the number and press

>For headset enter the number and press

You can switch between handsfree, headset or

handset at any time during the call.

End active call >Hang up the call.

>In handsfree mode press

> In headset mode press

Answer incoming call >Lift the handset.

>Or press

Reject incoming call >Press the Left Soft key “Reject”

Gigaset pro Maxwell 3 Quick start guide

Feature Action

Alert tone >Press and hold the Star key.

>Press the Left Soft key „Beep“ within 3 seconds.

Do not Disturb >Press the DND key.

The DND is enabled on the platform you can enable /

disable this also using the web-interface of the platform.

Muting >During the call press the Mute key.

Microphone is switched off when illuminated.

Hold >During the call press the Hold key to put the

call on hold.

>To resume, press the Hold key again.

>Or press the Left Soft key “End”.

If you Hangup the call when on hold, the call on hold is

disconnected.

Message waiting >New messages are signalled via flashing MWI key

Message Centre >Press the MWI key to open the message Centre.

>Select between Voicemail or Missed calls.

>Press the centre of the Control key.

>The Voicemail is played via the speaker.

>Lift the handset to listen via the handset.

Feature Action

Call lists >Press the Call list key

>Scroll left & right to select the required Call list.

- All

- Accepted

- Missed

-Outgoing

>Scroll up & down to select the number.

> Lift the handset.

> Or press

>Or press

Speed Dial >Press the Function key to dial the number.

Redial >Press the Left Soft key “Redial”

>Scroll up & down to select the number.

>Lift the handset.

>Or press

Volume >During the call press

Activate / Deactivate >Press and hold the Star key

Ring tone

Gigaset pro Maxwell 3 Quick start guide

Call Transfer Attended

When using attended transfer, you first make sure that the contact where you

want to transfer the call, is available and willing to answer this call. There is first a 2

way conversation before you transfer the call.

1. You have an active call.

2. During the call press the Hold key to put the call on hold.

3. Enter the phone number.

4. Press the Right Soft key “Dial”

5. Or the phone starts dialing automatic, 5 seconds after the last digit.

6. Wait until the call is answered and you announced the call.

7. Hang up to transfer the call.

8. Or press the Right Soft key “Transfer” to transfer the call.

9. Or press the Hold key to swap between the calls.

10. To disconnect the active call and go back to the party on hold,

press the Left Soft key “End”

Call Transfer Un-Attended

When using un-attended transfer, you transfer the call without announcing it to

the other party.

1. You have an active call.

2. During the call press the Hold key to put the call on hold.

3. Enter the phone number.

4. Press the Right Soft key “Dial”

5. Or the phone starts dialing automatic, 5 seconds after the last digit.

6. Hang up to transfer the call.

7. Or press the Right Soft key “Transfer” to transfer the call.

Gigaset pro Maxwell 3 Quick start guide

Blind Transfer

When using Blind transfer, you transfer the call without announcing it to the

other party. The call is transferred with one key press.

1. You have an active call.

2. During the call press Left Soft Key „Blind Transfer“ key to put

the call on hold.

3. Enter the phone number.

4. Press the Right Soft key “Dial”

5. Or the phone starts dialing automatic, 5 seconds after the last digit.

6. The call is transferred.

Call Swapping

1. You have an active call.

2. Press the Hold key to swap between the calls.

Conference Call

You can set-up a conference call to talk to two participants at the same time.

You have an active call.

Option 1.

1. Press the Conference key to start the conference.

2. Enter the phone number.

3. Press the Right Soft key„Dial“

4. Or the phone starts dialing automatic, 5 seconds after the last digit.

5. The conference is established as soon as the call is accepted.

Option 2.

1. During the call press the Hold key to put the call on hold.

2. Enter the phone number.

3. Press the Right Soft key„Dial“

4. Or the phone starts dialing automatic, 5 seconds after the last digit.

5. Wait until the call is answered.

6. Press the Conference key to start the conference.

Gigaset pro Maxwell 3 Quick start guide

Call forward always

All incoming calls are forwarded to another telephone number. Your phone will

not ring except you have Ring Splash activated on the platform. Then your phone

will play one ringtone and show “Ring Splash”on your display.

1. To activate Press the centre of the Control key to enter the phone

menu.

2. Scroll down to select the menu„Select Services“.

3. Select the menu “Call Divert”.

4. Select the account.

5. Select„All Calls“.

6. You can divert to:

a. Phone Number - enter the number.

b. Voicemail.

c. Off

The Call forward is enabled on the platform you can enable/disable this also

using the web-interface of the platform. If enabled, you see this on the Maxwell

Display. Users: Incoming Calls – Call Forwarding Always.

Via Feature code - Enable: <Phone number>

Via Feature code - Disable:

Call forward busy

Incoming calls are forwarded to another telephone number if your line is busy.

1. To activate Press the centre of the Control key to enter the phone

menu.

2. Scroll down to select the menu„Select Services“.

3. Select the menu “Call Divert”.

4. Select the account.

5. Select„When Busy“.

6. You can divert to:

a. Phone Number - enter the number.

b. Off

The Call forward Busy is enabled on the platform you can enable/disable this also

using the web-interface of the platform.

Users: Incoming Calls – Call Forwarding Busy

Via Feature code - Enable: <Phone number>

Via Feature code - Disable:

Gigaset pro Maxwell 3 Quick start guide

Call forward No Answer

Incoming calls are forwarded to another telephone number if you do not answer

the call within the defined time.

1. To activate Press the centre of the Control key to enter the phone

menu.

2. Scroll down to select the menu„Select Services“.

3. Select the menu “Call Divert”.

4. Select the account.

5. Select„No Answer.

6. You can divert to:

a. Phone Number - enter the number.

b. Off

The Call forward No Answer is enabled on the platform you can enable/disable

this also using the web-interface of the platform.

Users: Incoming Calls – Call Forwarding No Answer

Via Feature code - Enable: <Phone number>

Via Feature code - Disable:

Busy Lamp Field (BLF)

You can configure the function keys as BLF keys which tells you whether another

extension is free, busy or is receiving an incoming call.

1. The administrator or user has configured on the Broadsoft platform the BLF

keys. Users: Client Applications – Busy Lamp Field.

2. Every “empty”function key on your Maxwell is automatic configured as BLF

key.

The phone is using the BLF key configuration of the platform, there you can

change the monitored users and also the sorting. When you change this on the

platform, it will automatic be changed on the Maxwell.

1. Press the BLF key to call the user.

2. When the user is on the phone, the LED will be illuminated“RED“.

3. When the user receives an incoming call, the LED will flash.

4. To pick-up the incoming call, press the flashing BLF key.

Gigaset pro Maxwell 3 Quick start guide

Call Center (ACD)

The user can be an Agent of one of the configured Call Centers. The Agent can

change the status:

• Login / Logout

• Available

• Unavailable

The ACD status is shown on the display of the Maxwell.

1. To login Press the Right Soft key “Login”.

2. 2.The ACD status is automatic set to “Available”.

3. The agent can change the status to Unavailable via the Left Soft key

“Unavailable”.

4. Or switch back to„Available“.

5. to logout Press the Right Soft key „Logout“.

The automatic wrap-up time is set by the Call Center supervisor and is shown on

the display when activated. The Agent can change the status to Available using

the Left Soft key.

When the user is also using flexseating, the logout will also logout the user as

ACD agent and flexseating.

Remote Office

Remote Office allows you to use your home phone, your cell phone or even a

hotel phone as your business phone. This service directs all calls coming to your

business phone to ring the remote office phone.

1. To activate Press the centre of the Control key to enter the phone

menu.

2. Scroll down to select the menu „Select Services“.

3. Select the menu “Remote Office”.

4. You can change the status between On and Off.

5. Enter the Phone Number.

Gigaset pro Maxwell 3 Quick start guide

Phonebook

Broadsoft supports the following phone books: Personal, Group, Group Common,

Enterprise and Enterprise Common. Which are available for you depends on the

administrator of the platform.

Short press phonebook (Directory) key , you will get direct access to the

configured phonebook.

1. Scroll up and down to select the contact.

2. Lift the handset to dial.

Long press phonebook (Directory) key , you will see all available phone-

books.

1. Scroll up and down to select the phonebook.

2. Scroll up and down to select the contact.

3. Lift the handset to dial.

Autres manuels pour Maxwell 3

Table des matières

Autres manuels Gigaset Téléphone

Gigaset

Gigaset DA210 Manuel utilisateur

Gigaset

Gigaset A510H Manuel utilisateur

Gigaset

Gigaset N510 Manuel utilisateur

Gigaset

Gigaset C570A Manuel utilisateur

Gigaset

Gigaset DL580 Manuel utilisateur

Gigaset

Gigaset E295 Manuel utilisateur

Gigaset

Gigaset E290A Manuel utilisateur

Gigaset

Gigaset Gigaset 5020 Manuel utilisateur

Gigaset

Gigaset Gigaset DA610 Manuel utilisateur

Gigaset

Gigaset E370 Manuel utilisateur

Gigaset

Gigaset CL660A Manuel utilisateur

Gigaset

Gigaset Gigaset M49AM Manuel utilisateur

Gigaset

Gigaset A730 Manuel utilisateur

Gigaset

Gigaset DE700 IP PRO Manuel utilisateur

Gigaset

Gigaset C530 IP Manuel utilisateur

Gigaset

Gigaset DL500a Manuel utilisateur

Gigaset

Gigaset DESK 400 Manuel utilisateur

Gigaset

Gigaset E630 Manuel utilisateur

Gigaset

Gigaset DL500a Manuel utilisateur

Gigaset

Gigaset E630 A Manuel utilisateur

Gigaset

Gigaset 5040 Manuel utilisateur

Gigaset

Gigaset E560HX Manuel utilisateur

Gigaset

Gigaset Gigaset 5020 Manuel utilisateur

Gigaset

Gigaset 1054isdn Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
