Gigabyte GS-SR101T Guide de l'utilisateur
System Installation Guide
1-i
GS-SR101T
1U Rack Mount Server
SYSTEM INSTALLATION
GUIDE
System Installation Guide
1-ii
INDEX
1. INTRODUCTION 1-1
1.1. PREFACE 1-1
1.2. FEATURES 1-1
2. HARDWARE INVENTORY 2-1
3. SYSTEM INSTALLATION 3-1
3.1. CHASSIS COVER REMOVAL 3-1
3.2. PROCESSOR INSTALLATION 3-2
3.3. FAN+HEATSINK INSTALLATION 3-4
3.4. SYSTEM RAM INSTALLATION 3-6
3.5. INSTALLING HANDLE 3-7
3.6. REINSTALL TOP COVER 3-8
3.7. HARD DISK DRIVE INSTALLATION 3-9
3.8. FRONT SIDE 3-14
3.9. LED INDICATORS 3-14
3.10. BACK SIDE 3-15
3.11. CONNECTOR ICONS 3-16
System Installation Guide
1-1
1. INTRODUCTION
1.1. Preface
Using this manual will help you get the most from your
Rack Mount Server. Keeping the manual with your Rack
Mount Server to refer when you want information and
help.
In order to get the optimal usage out of your Rack Mount
Server and you should remember the following:
Read through all the instruction for your Rack
Mount Server .
Keep the area free of static electricity and magnetic
fields. These can damage the Server .
When cleaning the server or its components, apply
the proper cleaning solution or sprays only on the
cloth ,not to the server or its components .
1.2. Features
Our Rack Mount Server use 1U Chassis and support the
following features:
Processor Support
Dual Socket 370 for Intel FC-PGA Coppermine and
Tualatin processor Up to 1 GHz and above
Optimal CPU Keep Out Zone for Type C Heat-sink
100/133MHz FSB
AUTO detect CPU voltage
BIOS
AMI BIOS on 4M bit flash ROM
System Installation Guide
1-2
Auto configure IDE HDD type
Multiple boot options
User setting for hardware monitoring
DMI 2.0 compliant
Chipset
VIA Apollo Pro Family AGP set
( VT82C694T ,VT82C686B ) Chipset
ATI Rage XL 2X VGA Chip with 8MB Video
Memory
PROMISE PDC20265R with RAID 0 or 1 support
Dual Intel 82559 LAN chip
Memory Support
Four 25 degree angled 168 Pin DIMM sockets for
SDRAM modules
Supports up to 2GB PC-100/PC-133 Error
Checking and Correction (ECC) either un-buffered
or registered memory and VCM SDRAM
Supports only 3.3V SDRAM DIMM
Storage Controller
Max 4 IDE ATA channels ( 2 x ATA-66 and 2 x
ATA-100 for IDE RAID 0 or 1 )
Support front-accessible 2 hot-swap drives featuring
IDE ATA-100 transferring rate
44MB Floppy Disk Drive ( Slim type )
High Speed IDE CD-ROM Drive ( Slim type)
Networking
On board dual LAN, Ethernet 10/100 WOL (Wake
System Installation Guide
1-3
On LAN)
Adaptive fail over feature
Load balance feature
I/O Expansion Slot
PCI raisers , 1 slot ,support 33MHz & PCI 2.2
compliant
Build-in I/O ports
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x COM port
1 x VGA port
1 x LPT port
2 x RJ-45 ports
2 x USB ports
Power
Total output power 250 W
Input : Rating switch full range 90V~250V 47~63
Hz
Operating Temperature
5 to 40 degree C
Thermal Solution
Special-designed Heat-sink and hi-efficiency
chassis fans for dual 1 GHz plus processor thermal
solution
System Installation Guide
1-4
Other Features
Support Wake On LAN ( WOL )
Support External Modem Ring On
Optional DOC solution for embedded
Internet/Networking Applications
O/S Support
Windows NT ,Windows 2000 ,Linux ( RED HAT
7.0 , Netware 5.0
Chassis Dimensions
Height 44.45 mm ( 1.75 In. )
Width 482.6 mm ( 19.0 In. )
Depth 609.6 mm ( 24.0 In. )
System weight 11.8 Kg ( 26 lbs )
System Installation Guide
2-1
2. Hardware Inventory
When you unpack your GS-SR101 Rack Mount Server,
Check that all the items that you ordered are present in
good condition. Review the inventory checklist below to
be sure that the components and optional components
that you ordered are included. If anything is miss or
damage, contact your retailer as soon as possible.
Chassis
Power Supply ( Installed )
Motherboard GA-6VTXDR ( Installed )
Manuals (M/B user’s Manual & System
Installation)
Hard Disk Drive Tray x 2
Flat Screw # 6-32 * 5L x 12 ( For HDDs)
Fan + Heat sink x 2
Case Handle x 2
Flat Screw M4*10L x 4 ( For Handle )
Support CD x1
Support Floppy Disk x 2
System Installation Guide
3-1
3. System Installation
Note: Please remove the protection plastic cover from
top and bottom side first. If not, the system heat could
not spread from top and bottom side.
3.1. Chassis Cover Removal
Use screwdriver to remove the two screws on the chassis
top cover . ( Fig 1 ) And then slide the top cover out of
the system .( Fig 2 )
Fig-1
Fig-2
System Installation Guide
3-2
3.2. Processor Installation
To install Socket 370 CPU, lifts up bar located next to
the Socket.
And then insert Socket 370 CPU inside Socket, and push
the lever bar back into original position. (Fig-3 & Fig-4 )
CPU-1 CPU-2
Fig-3
