Gigabyte SB93 Manuel utilisateur

FCC Complicance Statement / FCC 聲明

For Users in the USA

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of FCC Rules. These

rules are designed to provide reasonable protection against harmful

interference when the equipment is operated in a residential

installation. This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in accordance with the

installation, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined

by turning the equipment off and on, you are encouraged to try to

correct the interference by one or more of the following measures:

Reorient the receiving antenna

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for

help.

Notes:

Unauthorized changes or modifications may void the user's right to operate the

equipment.

Only equipment certified to comply with Class B (computer input/output devices,

terminals, printers, etc.) should be attached to this equipment and all such

equipment must be connected with shielded interface cable.

Preface / 前言

Thank you for purchasing and adopting the SB Series as your favorite computer

product. To assure the safe application of this product, please carefully read the

following:

感謝您採購與愛用 SB 系列電腦產品。為確保您能安全地使用本產品，請您仔細閱讀以下說明：

Please strictly follow the labeled warnings and instructions given.

請務必遵守產品中的標示警告及指示。

Before disassembling or cleaning this product, make sure the power connector

is unplugged.

拆卸及清理本產品前，切記拔掉電源插頭。

Never wipe the interior of the system with water or dip the system in water.

在任何情況下，請勿用水擦拭機器內部或浸濕機體。

Before connecting to any peripheral, please turn off the power of the system.

連接或組裝任何週邊設備前，請先關閉電源。

Ensure that the voltage select switch is in the correct position for the type of

voltage you use (115V/230V). If you are not sure which kind of voltage you are

using, please contact your dealer.

本產品須使用標示上所指定的電源種類，如果您不確定使用何種電源，請與您的經銷商聯

絡。 Nov / 2004

Features / 特色介紹

SB Series adopts the motherboard customized designed and developed, which allow

you to work seamlessly with the Windows operating system.

SB 系列產品是專為客戶量身設計的主機板，讓您在 Windows 操作環境中得心應手。

The nimble design of the Small Form Factor casing not only gives convenient

assembling and maintenance but also allows you to easily upgrade in the future!

採用靈活的精簡型機殼設計，不但方便組裝與維護，更讓您日後的升級格外容易！

WARNING / 警告

If the battery is not properly handled, there may be a risk of

explosion; make sure you are using the same or equivalent

battery. Please dispose the used battery according to the

instructions given by the manufacturer.

電池若處理不當，可能有爆炸的危險。替換時請務必使用相同或同等的電

池。請依據製造商指示處理廢棄電池。

*CPU cooler (Option)

/ CPU 散熱風扇（選購）

PC / 主機

*Keyboard

(Option) / 鍵盤

（選購）

Items included in the package / 系統包裝說明圖

,Specification with “Option” are subject to change without notice.

以”*”所標示的規格與實際產品有差異時，以實際出貨產品為準。

Other Product Specifications / 其他產品規格

-Small Form Factor Chassis / 精簡型電腦機殼

-Small Form factor motherboard / Small Form Factor 主機板

-Power Supply / 電源供應器

-DVD-ROM / CD-ROM / CD-RW / FDD (Option) / Card Reader (Option) / DVD-ROM

/ CD-ROM / CD-RW / 軟碟機（選購） / 讀卡機（選購）

-Assembly Box Content /（附件盒）

①Cable Tie / 束線帶 ②Screw bag / 螺絲包

Power Cord

/ 電源線

Software & Manual /

程式光碟與使用手冊

*Foot Stand

/ 腳座

*Mouse (Option) /

滑鼠（選購）

I. Chassis / 電腦機殼

Dimensions= 284(D) mm x 88(W) mm x 359(H) mm

外觀尺寸= 284(D) mm x 88(W) mm x 359(H) mm

This chassis is made with material complied with UL specification and designed

for space saving, and it can be opened easily with thumbscrew. There are one

5.25” and two 3.5” drive bays. This chassis complies with corresponding EMC

and safety regulations.

本電腦機殼採用通過 UL 規格之材料，並依節省空間與螺絲開啟之便利性為設計基礎，可裝

置一個 5.25”及兩個 3.5”的存取設備。本電腦機殼的設計兼具電磁波防制及電腦安全規格之

需求。

II. Motherboard / 主機板

This Motherboard is Standard Product, it will be setup ready before ship out, so

you don’t need to change its setting.

本系統配備之主機板已於工廠設定完成，所以您不需重新設定。

III. Power Supply / 電源供應器

This computer adopts a S.F.X. power supply and supports the function of turning

off the system by software. The factory default voltage is 230V.

本產品採用 S.F.X 電源供應器，支援軟體關機功能。出廠電壓預設值為 230V。

,Note: Please confirm the default voltage of the country before turning on the

computer.

注意：開機前請先確認各國的電壓預設值。

IV. Front and Rear Panel Components / 前後面板的裝置

Front & Rear Panel Components / 前後面板圖

1. Floppy Disc (Option) / 軟碟機（選購）

2. DVD-ROM (Option) / 光碟機（選購）

3. Power Button / 電源按鈕

4. AC Inlet / 電源接頭

5. Voltage Switch / 電壓開關

6. Foot Stand / 腳座

I/O Ports / 輸出入埠

MIC In / 麥克風

COM Port / 串列埠

Line Out (Audio Out or

Earphone) /音源輸出 (耳機)

VGA Port / VGA 埠

Line In (Audio In) /音源輸入

LPT Port / 並列埠

Keyboard Port (PS/2) /

鍵盤孔(PS/2）LAN Port / 網路埠

Mouse Port (PS/2)

/ 滑鼠埠（PS/2）USB Port / USB 埠

①

②

③

⑥

⑤

④

VB3VB2

②

③

Voltage Selection Switch / 電壓設定開關

Select the correct voltage setting for your local area voltage before the computer

system is plug to the power source.

請在接上電源前先確定是否已將電壓開關設定為 110V。

WARNING: Select incorrect setting will cause

the Power supply failure!

警告：若開關設定錯誤，可能導致電源供應器毀損！

V. Installing the System / 系統設備安裝

1. Unscrew the rear casing and push the upper casing toward the front panel, then

loose the hook to remove the front panel.

卸下機殼後方的 3顆螺絲，將上蓋朝箭頭方向推出，拉起箭頭處即可拆除面板。

For Model VB3 only / VB3 機種適用：

Unscrew the black bar and remove

it either.

將黑色護桿上的螺絲卸下，並移除護桿。

2. After loosening the 3 front screws, pull out the Device disk Bay.

卸下前面板的 3顆螺絲後，即可抽出光碟及軟碟機支架。

3A. For Model VB2 / VB2 機種：

Put the hard disk drive & DVD-ROM into the rack, and align the screws at the screw

holes.

將硬碟機及光碟機放入支架中，並對準螺絲孔位鎖上螺絲。

3B. For Model VB3 / VB3 機種：

Put the floppy disk drive & DVD-ROM into the rack, and align the screws at the

screw holes.

將軟碟機及光碟機放入支架中，並對準螺絲孔位鎖上螺絲。

Lift the transversal lever / 拉起橫桿

CPU Pin

Evenly spread the heat dispersion paste

on the CPU / 將散熱膏均勻塗抹於 CPU 上

4. CPU / 中央處理器

4-1. Evenly spread the heat dispersion paste on the CPU and make sure it totally

cover the CPU. Insert the CPU on the CPU socket. Make sure that you have lifted

the transversal lever and aligned the aslant side of the CPU along the aslant side

of the CPU socket. After CPU is secured tightly onto the CPU socket, release the

transversal lever and attach it to the CPU socket.

將散熱膏均勻塗抹在 CPU 上，並確保完全覆蓋住 CPU。將 CPU 置於主機板上的 CPU 插座。

請務必將橫桿拉起，並將 CPU 斜邊處與 CPU 插座的斜邊處對齊。當 CPU 與CPU 插座已完

全密合後，請將橫桿放下並勾緊 CPU 插座。
