Giantec 2000 Manuel utilisateur
Tracer 2000 Digital Video Recorder
User’s Manual
Tracer 2000 DVR user manual
Version 3.0 Page 2of 36
Contents
CHAPTER I INTRODUCTION...............................................................................................................5
LIMITED WARRANTY ...............................................................................................................................5
FUNCTION INTRODUCTION....................................................................................................................5
FEATURE......................................................................................................................................................6
CHAPTER II PACKAGE...........................................................................................................................7
PACKING LIST .................................................................................................................................................7
CHAPTER III INSTALLATION ............................................................................................................8
FRONT PANEL VIEW..................................................................................................................................8
REAR PANEL VIEW....................................................................................................................................8
1 INDICATOR...............................................................................................................................................9
2 CABLE CONNECTION ............................................................................................................................9
2.1. Connect VGA Monitor ........................................................................................................................9
2.2. Connect Camera Cable to BNC connector.......................................................................................10
2.3. Connect to LAN connector: Plug RJ-45 connector to LAN Port......................................................10
3. POWER CONNECTOR..........................................................................................................................12
3.1. Connect power cord (110V~240V auto switch) into the power socket.............................................12
CHAPTER IV PIN ASSIGNMENT......................................................................................................13
INTERNAL JUMPERS AND CONNECTORS.........................................................................................................13
EXTERNAL CONNECTOR................................................................................................................................19
CRT DISPLAY CONNECTOR (VGA)...............................................................................................................19
Audio Input connector:............................................................................................................................19
GPIO CONNECTOR:.......................................................................................................................................19
USB connector:........................................................................................................................................19
COM 1 CONNECTOR.....................................................................................................................................20
RS-232 Connector (COM1) .....................................................................................................................20
COM2 Connector.....................................................................................................................................20
Connectors...............................................................................................................................................21
P/T/Z Setting ............................................................................................................................................22
CHAPTER V CMOS SETTING..............................................................................................................23
INTRODUCTION .............................................................................................................................................23
SETUP PAGES.................................................................................................................................................23
Tracer 2000 DVR user manual
Version 3.0 Page 3of 36
1. Standard CMOS Features....................................................................................................................24
2. Advanced BIOS Features.....................................................................................................................25
3. Advanced Chipset Features..................................................................................................................26
4. Integrated Peripherals.........................................................................................................................27
5. Power Management Setup ...................................................................................................................28
6. PnP / PCI Configuration .....................................................................................................................29
7. PC Health Status..................................................................................................................................30
8. Frequency/Voltage Control..................................................................................................................30
9. Load Optimized Defaults .....................................................................................................................31
10. Supervisor / User Password...............................................................................................................31
11. Save & Exit Setup...............................................................................................................................31
12. Exit Without Save...............................................................................................................................31
CHAPTER VI SYSTEM HDD INSTALLATION GUIDE.................................................................32
FOLLOW THE STEP TO SETUP HDD DRAWING BOX.........................................................................................32
1. Remove the screws on the case. (marked in while circles)..................................................................32
2. Take off the upper cover and remove the screws..................................................................................33
3. Remove HDD Tray, and install HDD properly....................................................................................34
4. Insert the assembled HDD tray into TRACER2000, and connect both Power and HDD cables........35
5. Assemble the upper cover and the screws............................................................................................36
Tracer 2000 DVR user manual
Version 3.0 Page 4of 36
Copyright Notice
Copyright 2004. All Rights Reserved
This document may not, in whole or in part, be reproduced or transmitted in
any form or by means, electronic, mechanical, or optical, including
photocopying, recording, or storing in a retrieval system, or translated into
any language in any form without the prior written content of us.
Warranties
We make no warranties with respect to this documentation and disclaim any
implied warranties of merchantability and fitness for a particular purpose. We
shall not be liable for any error or for incidental or consequential damages in
connection with the furnishing, performance, or use of this documentation or
the examples herein.
The information in this documentation is subject to change without notice.
Trademarks
All other product namesmentioned in this documentation are for identification
purposes only and remain the sole property of their respective owners.
All Rights Reserved
Tracer 2000 DVR user manual
Version 3.0 Page 5of 36
CHAPTER I INTRODUCTION
Thank you for purchasing Tracer 2000 DVR; this manual will guide you through the setup,
installation, and use of all our DVR systems.
Before proceeding, please read this manual thoroughly!
If you have any questions or concerns that cannot be solved by following this manual, please
visit our web site at http://www.giantec.net
LIMITED WARRANTY
Giantec Inc. warrants this product to be in compliance with its own plans and specifications.
Moreover, to be free from defects in materials and workmanship under normal use and service
for all parts (1) one year after the original purchase date. During this period Giantec Inc. will
replace parts at no charge, however, labor cost will be laid after one (1) year. Please contact
your dealer/distributor for details.
This warranty excludes damages due to misuse or neglect.Also this warranty does not cover
damages beyond DVR’s control. In no event shall Giantec Inc. be liable for any direct, indirect
or consequential damages; loss of anticipated profits, loss of time or any other losses incurred
by the buyer in connection with the purchase, installation, operation or failure of this product.
For more details on the limitation of this warranty, contact your distributor.
FUNCTION INTRODUCTION
Thank you for using TRACER 2000 video surveillance system. TRACER can be used to
transfer captured video signal from analog to digital using the compression format for record
and play. They can also capture videos of up to 4 / 8 /16 cameras for model TRACER-2404,
TRACER-2408, and TRACER-2416(4 /8/16 BNC inputs) with 4 audio sources at the same time.
The built-in video player makes it easy to play back captured video files. The system also
provides several control modes like motion detection, schedule record, P/T/Z control and
remote surveillance applications.
Tracer 2000 DVR user manual
Version 3.0 Page 6of 36
FEATURE
The TRACER2000 comes with the following hardware devices:
Control panel with IR receiver
One10/100Mbps RJ-45 Ethernet Port
One RS 232 and one RS232/422/485 selectable interface
One VGA Connector
One speaker out
Two USB Ports
Two 3.5” HDD Supported
Four Audio-in Ports
Eight GPIO Ports
Remote Commander
Working temperature: 0 ~ 45 °C
Storage temperature: -10 ~ 65 °C
Relative humidity: Maximum 85%, non-condensing
Power requirement: AC 100 ~ 240V, 50 / 60 Hz, 150W maximum
Dimension: 265 mm (D) x 321mm (W) x 103mm (H)
Weight: 5Kg
Tracer 2000 DVR user manual
Version 3.0 Page 7of 36
CHAPTER II PACKAGE
Packing List
Check the accessories accompany with the system you purchase as listed below.
With newer package release, the accessories are compacted into an accessory box.
Please check the items and Contact to your dealer you bought from if any of them is
missing
TRACER2000 System
Power Cord
Screws Pack
Remote Commander
Battery (AAA) X 2
User’s Manual
Installation CD-ROM
Please keep the packaging materials. You may need them for the use of further service.
Tracer 2000 DVR user manual
Version 3.0 Page 8of 36
CHAPTER III INSTALLATION
FRONT PANEL VIEW
REAR PANEL VIEW
12
CH2
CH1 CH7
CH3 CH4 CH5 CH6 CH8
CH16
CH15
CH14CH13CH12
CH11
CH10
CH9
1
ALARM IN
34
2
ALARM OUT4231
MIC4
MIC2 MIC3
MIC1
Power supply Parallel port BNC connectorGPIO
VGA USB Ports x 2 10/100 Ethernet
MIC and Speaker
Alarm Menu Display Playback Confirm
Removable Air
Filter Bracket
Removable Air
Filter Bracket
※Remove and clean up Air Filters monthly is essential.
IR
UP
LEFT RIGHT
DOWN
COM1 COM2
Audio
Tracer 2000 DVR user manual
Version 3.0 Page 9of 36
1 INDICATOR
Power LED: Green light shows power is on.
Status LED: Green light continuous on means
working properly.
Green light blinking shows status of recording
Red light continuous on means no signal (This
may implies HDD damaged, No Power, or Access
Error.)
Red light blinking shows status of recycling. (HDD
space less than 1 Gigabyte)
2 CABLE CONNECTION
Following is the basic device must be prepared before to start installation complete system.
1. Tracer 2000
2. CCD cameras
3. VGA monitor
Please follow the procedure to connect the cable.
2.1. Connect VGA Monitor
Power LED
Status LED
Tracer 2000 DVR user manual
Version 3.0 Page 10 of 36
2.2. Connect Camera Cable to BNC connector
2.3. Connect to LAN connector: Plug RJ-45 connector to LAN Port
2.5.1 Insert RJ-45 cable to network LAN socket on the rear.
2.5.2 Connect Serial port modem to serial connector (COM1) and through
Dial-in function to connect to Internet.
