Giant Alarm System ESP-M1 Manuel utilisateur

1

ESP-M1/M2

product manual

Ver V1.0

Fentures

■ SOC characteristics Peripheral for Module

●Built-in Tensilica L106 ultra-low power ●2*UART

Consumption 32-bit cpu, the main frequency ●1*En;

Can be 80MHz and 160MHz, also support ●1*ADC;

RTOS; ●1*wakeup pin;

●Built-in TCP/IP protocol stack; ●1*HSPI;

●Built-in 1 channel 10-bit high precision ADC; ●1*I2C;

●The outeide interfaces have HSPI, UART,I2C, ●1*I2S;

I2S,IR Remote Control, PWM, GPIO; ●MAX 10* GPIOs;

●The deep-sleep current is about 10uA, and the ■Working temperature:-40℃-125℃

Cut-off current is smaller than 5uA; ■Module size:

●Can be wake-up within 2 ms, and connect to 12.3*mm*15mm;(M1 version)

Transmit data package; 12.3*mm*20mm;(M2 version)

●the consume power is smaller than 1.0mW Application

(DTIM3) when at standby status; ●Serial Transparent transmission;

●Built-in 1M byte for SPI Flash. ●WiFi prober;

●Smart power piug/Smart LED light;

■ Wi-FI characteristics ● Mesh networks;

●Sensor networks;

●Support 802.11 b/g/n/e/i ●Wearable electronics;

●Support three modes: Station, SoftAP, and ●Securit ID label;

SoftAP+STA; ●Wireless location recognition;

●Support Wi-Fi Direct(P2P); ●Wireless location system beacon;

●Support hardware acceleration for CCMP ●Industrial wireless control;

(CBC-MAC,computation mode),TKIP(MIC, Module Type

RC4), WAPI(SMS4), WEP(RC4), CRC;

●P2P find, P2P GO mode/GC mode and P2P Module Structure

Power management;

2

●WPA/PA2 PSK and WPS;

●Support 80211 i security: pre-certification

And TSN;

●Support 802.11n (2.4GHz);

●802.1h/RFC1042 frame encapsulation;

●Support seamless roam;

●Support AT remote updation and cloud OTA

Updation;

●Support SmartConfig function for Android

And iOS device SmartConfig.

3

4

5

6

7

8

9

10
