Gevi GECME020DE-U Instructions d'utilisation et d'entretien

GECME020DE-UOperation Tips and MaintenanceInstructions

CONTENTSThe lack of maintenance of the machine would not only aﬀect your coﬀee taste but also lower the perf-ormance or even shorten the lifespan of your mac-hine. For you to better maintain your machine, we’ve prepared some helpful tips for you as follows.The 3-in-1 smart coﬀee machine is mainly composed of a grinder, a brewer and a steam wand.Grinder0101-10PARTBrewer0211-31PARTMilk-Frothing0332-39PARTCONTENTS

01Grinder0101

02Make Every Sip Count

D. Do not ﬁll the bean hopper with frozen or coated beans, moisture will seep into the burr and ground channels. Over time this will cause the same problem as that in point A.E. Do not add any liquid ﬂavorings or syrups to the beans, otherwise it will cause the same result as point A.1. Before UseA. The grind settings 0-15 are suitable for medium or dark roasted beans, 15 and above can be used for light, medium, and dark roasted beans, but very dark beans are not suitable for very ﬁne grind settings, and 8 and above are more suitable, otherwise, your grinder will be easily blocked. So the deeper the roast level, the more oily the beans would be, and the more frequent deep cleaning is required.B. If you maintain and clean the grinder properly, as those beans can leave some greasy residue in the burrs and feeder channels. The oil residue can cause the ground coﬀee to stick in the feeder passages and clog. Over time, this slows down the ﬂow of ground coﬀee. The amount of ground coﬀee beans is controlled by the selection of coﬀee cups or grinding time. Therefore, you will ﬁnd that fewer and fewer coﬀee grinds would be produced by grinding with the same cup setting or time setting.C. Do not use light roasted beans with the grind settings below 15, because the lightly roasted beans are of high density and hard to grind, if you grind them with a ﬁne setting, fewer coﬀee grinds will come out and they would be sticky, which can cause the ground coﬀee to stick in the feeder passages and clog. Over time, this slows down the ﬂow of ground coﬀee. The amount of ground coﬀee beans is controlled by the selection of coﬀee cups or grinding time. Therefore, you will ﬁnd that fewer and fewer coﬀee grinds would be produced by grinding with the same cup setting or time setting.

03Make Every Sip Count

A. Use the correct method to adjust the grind size settings.If you want to adjust the grind size setting, there are some notes listed below you need to be aware of:B. To properly dose the portaﬁlter with coﬀee grounds, place it on the cradle instead of holding it.Situation 1: When you want to adjust a ﬁne setting to a coarser setting, just rotate the Grind Regulator directly before grinding.Situation 2: When you want to adjust a coarse setting to a ﬁner setting.- But if there are coﬀee beans inside the grinder, you cannot rotate the Grind Regulator forcibly, otherwise, grinder damage may occur. In this case, you can either grind all the coﬀee beans inside the grinder and then adjust the grind setting directly, or grind beans and rotate the Grind Regulator simultaneously to achieve your ﬁne setting. - If there are no coﬀee beans inside the grinder, you can rotate the Grind Regulator directly to achieve your setting;2. In Use

Make Every Sip Count 04Please strictly follow the instructions and requirements below to clean the coﬀee-grinding part and its accessories, otherwise, the ﬂavors of your coﬀee will be aﬀected or the lifespan of the brewer will be shortened.Rotate the Bean Hopper counterclockwise to the end,align the lock mark with the convex point, and take out the Bean Hopper;Open the Hopper lid of the Bean Hopper, empty the coﬀee beans in the bean hopper into an empty jar, and install the Hopper lid of the Bean Hopper;12Insert bean hopper into the grinder collar, lightly pushing down, turn the bean hopper in a clockwise direction to select the coarsest setting. Align the hopper guide with the red grinder interlock.34

3. After UseA. After Each Use

Make Every Sip Count

9Tap the top 3-5 times, then remove the plate and discard the ground coﬀee.Use a straw cleaning brush to poke in and out of the powder channel from above, clean the channel, and poke 30-50 times.Put a dish under the powder outlet.Press the Grind button 3 times, wait for 2 seconds the grinder will start grinding automatically.65When you hear the sound of the machine idling, press the Grind button to stop working. Unplug the power after turning oﬀ the machine.81071211Wipe the surface of the Drip Tray with a clean cloth.Wipe the powder outlet.05

04Make Every Sip Count 06B. After 15 Days or After 100 UsesOpen the Hopper lid of the Bean Hopper.Rotate the Bean Hopper counterclockwise to the end, align the lock mark with the convex point, and take out the Bean Hopper;12Empty the coﬀee beans in the bean hopper into an air tight Container.Install the Hopper lid of the Bean Hopper.436Align the hopper guide with the red grinder interlock. Insert bean hopper into the grinder collar, lightly pushing down,turn the bean hopper in a clockwise direction to select the coarsest setting. 5

Make Every Sip Count

07Press the Grind button 3 times,wait for 2 seconds the grinder will start grinding automatically.Put a dish under the powder outlet.Unplug the power after turning oﬀ the machine.When you hear the sound of the machine idling, press the Grind button to stop working.Rotate the Bean Hopper counterclockwise to the end, align the lock mark with the convex point,and take out the Bean Hopper.Rotate the Upper Conical Burr counterclockwise to unlock, take out the Upper Conical Burr.TurnRemoveTurnRemoveTake out the cleaning brush and straw cleaning brush.Remove the drip tray from machine.7891011121413

Make Every Sip Count

Insert bean hopper into the grinder collar, lightly pushing down,turn the bean hopper in a clockwise direction to select the thickest gear. Insert the Power Plug into a 120V AC power outlet & switch the power on.Clean the Upper Conical Burr with a cleaning brush.Clean the surrounding area with a cleaning brush.Use a straw cleaning brush to poke in and out of the powder channel from above, clean the channel, poke 30-50 times.Tap the machine 3-5 times. Remove the dish and discard the ground coﬀee.Align the hopper guide with the red grinder interlock.Install the Upper Conical Burr and lock it clockwise.TurnRemove151617181920222108
