GeoVision 84-SD2301S-2011 Manuel utilisateur

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use. ISD-QG-I

Quick Start Guide

GV-IP Speed Dome

Under the copyright laws, this manual may not be copied, in whole or in

part, without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any

kind and assumes no responsibility for errors or omissions. No liability is

assumed for incidental or consequential damages arising from the use of

the information or products contained herein. Features and specifications

are subject to change without notice. Note that memory card slot (local

storage) is not supported for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows

XP are registered trademarks of Microsoft Corporation.

July 2015

Contents

Note for Recording ........................................................... iv

Note for Installing Camera Outdoor................................. v

Note for Water Resistant Coating on Camera Cover..... vi

Options ............................................................................. vii

1. Introduction .................................................................... 1

2. GV-SD220 / GV-SD220-S / GV-SD2300 / GV-SD2301 ... 2

2.1 Packing List................................................................................. 2

2.1.1 Indoor GV-IP Speed Dome (GV-SD220)........................... 2

2.1.2 Outdoor GV-IP Speed Dome (GV-SD220-S / GV-2300) ... 3

2.1.3 Outdoor GV-IP Speed Dome (GV-SD2301) ...................... 4

2.2 Overview ..................................................................................... 5

2.2.1 GV-SD220 / GV-SD220-S / GV-SD2300........................... 5

2.2.2 GV-SD2301...................................................................... 6

2.3 Installation ................................................................................... 7

2.3.1 Indoor GV-IP Speed Dome: Hard-Ceiling Mount

(GV-SD220)................................................................................ 7

2.3.2 Outdoor GV-IP Speed Dome: Wall Pendant Mount

(GV-SD220-S / GV-SD2300) ...................................................... 9

2.3.3 Outdoor GV-IP Speed Dome: Wall Pendant Mount

(GV-SD2301).............................................................................11

2.4 Connecting the Camera............................................................. 16

2.5 Accessing the Camera .............................................................. 19

2.5.1 System Requirements .................................................... 19

2.5.2 Looking Up the IP Address and Logging In..................... 20

2.6 The Web Interface..................................................................... 22

2.7 The PTZ Control Panel.............................................................. 24

2.8 Configuring a Preset Position .................................................... 26

2.9 Configuring a Sequence Route.................................................. 28

2.10 Configuring a Cruise................................................................ 31

2.11 Configuring an Auto Pan.......................................................... 32

2.12 Configuring a Tour ................................................................... 34

2.13 Upgrading System Firmware ................................................... 36

2.14 Restoring to Default Settings ................................................... 38

2.14.1 Restoring System Settings............................................ 38

2.14.2 Restoring PTZ Configuration Settings........................... 39

3. GV-SD200 / SD200-S .................................................... 40

3.1 Packing List............................................................................... 40

3.1.1 Indoor GV-IP Speed Dome............................................. 40

3.1.2 Outdoor GV-IP Speed Dome .......................................... 41

3.2 Overview ................................................................................... 42

3.3 Installation ................................................................................. 43

3.3.1 Indoor Speed Dome Mount: Surface Mount .................... 43

3.3.2 Outdoor Speed Dome Mount: Mini Pendent Mount......... 46

iii

3.4 Connecting the Cables .............................................................. 48

3.5 Accessing the Camera .............................................................. 50

3.5.1 System Requirements .................................................... 50

3.5.2 Looking up the IP Address and Logging in...................... 51

3.6 The Web Interface..................................................................... 53

3.7 The PTZ Control Panel.............................................................. 54

3.8 Configuring a Preset Position .................................................... 56

3.9 Configuring a Sequence Route.................................................. 58

3.10 Configuring a Cruise................................................................ 61

3.11 Configuring an Auto Pan.......................................................... 63

3.12 Configuring a Tour ................................................................... 65

3.13 Upgrading System Firmware ................................................... 68

3.14 Restoring to Default Settings ................................................... 70

Note for Recording

1. By default, the images are recorded to the memory card inserted in the

GV-IP Speed Dome camera.

2. Mind the following when using a memory card for recording:

Recorded data on the memory card can be damaged or lost if the

data are accessed while the camera is under physical shock,

power interruption, memory card detachment or when the

memory card reaches the end of its lifespan. No guarantee is

provided for such causes.

To avoid power outage, it is highly suggested to apply a battery

backup (UPS).

For better performance, it is highly suggested to use Micro SD

card or SD card of MLC NAND flash, Class 10.

Replace the memory card when its read/write speed is lower than

6 MB/s or when the memory card is frequently undetected by the

camera.

Note for Installing Camera Outdoor

When installing the GV-IP Speed Dome, be sure that any PoE, power, audio

and I/O cables are waterproofed using waterproof silicon rubber or the like.

Note for Water Resistant Coating

on Camera Cover

The camera cover of GV-SD2301 is treated with a water resistant coating

that prevents droplets from forming on the surface. The water resistant

coating will slowly wear off after approximately one year depending on the

operating environment.

Proper care and precautions can prolong the life of the water resistant

coating. Store the camera in a dry area before installation. Once you

remove the protective film on the camera cover, avoid touching the camera

cover.

Rinsing the Camera Cover

You can clean the camera cover using one of the methods below:

Rinse with water

Use an ultrasonic cleaner

Rinse with pH-neutral cleaning solution (5% diluted)

If there are grease or fingerprints on the camera cover that cannot be

removed by rinsing, you can gently wipe the cover with clean cotton cloth.

Only wipe the camera cover after it’s dried.

Make sure the surface is free of dust or debris before wiping to avoid

scratching the cover.

IMPORTANT:

1. Do not wipe the camera cover while it’s wet. Wiping a wet camera

cover will damage the hydrophilic water resistant coating.

2. Do not clean the camera cover with cleaning agent containing

organic solvent.

vii

Options

Optional devices can expand the capabilities and versatility of your camera.

Contact your dealer for more information.

Name Details

GV-Mount Accessories The GV-Mount Accessories provide a

comprehensive lineup of accessories for

installation on ceiling, wall corner and pole. For

details, see GV-Mount Accessories Installation

Guide on the software CD.

In-Ceiling Installation

Package

The in-ceiling package is used to install the

indoor GV-IP Speed Dome by embedding the

camera to the ceiling.

Power Adapter The power adapter is designed to convert AC

100 ~ 240V 2.5A to DC 24V 3.75A and supply

the power to indoor and outdoor GV-IP

Speed Dome. The power adapter is available

in the regions: US, AU, AR, EU, JU and UK.

GV-PA901 PoE Adapter The GV-PA901 is a Power over Ethernet (PoE)

adapter designed to provide power and

network connection through a single Ethernet

cable to outdoor GV-IP Speed Dome.

GV-PoE Switch The GV-PoE Switch is designed to provide

power along with network connection for IP

devices. The GV-PoE Switch is available in

various models with different numbers and

types of ports.
