Gentech GP6500I Manuel utilisateur
POWER WHEN YOU NEED IT
TO KEEP YOUR GENERATOR LASTING
LONGER REMEMBER TO SERVICE IT!
Generator Operators Manual GP6500I
17 HRS @ 50% LOAD
8.5 HRS @ 100% LOAD
5500
MAXIMUM RATED OUTPUT
W
Now Supplied
with Gentech
Engine Oil
SAE 15W-40 Engine Oil
1000ml
1000ml
SAE
15W-40 Engine Oil
YEAR
WARRANTY
1
RECOIL / ELECTRIC
STARTING METHOD
•
DANGER
This indicates a hazardous situation, which, if not avoided, will result in death or serious
injury.
•
WARNING:
This indicates a hazardous situation, which, if not avoided, could result in death or serious
injury.
•
CAUTION:
This indicates a hazardous situation, which, if not avoided, could result in injury.
DANGER
WARNING
CAUTION
IMPORTANT:
Thank you for purchasing a Gentech Gasoline Generating Set (hereinafter referred to as the
"generator").
This manual will assist you in operating and maintaining your generator. This manual is the latest
version. With the continuous improvement and upgrading of this product, the manufacturer reserves the
right to modify this manual without notice. The manufacturer shall assume no liability for incorrect
information contained in this manual.
This manual is an integral part of the generator. When the generator is transferred to others, this
manual should be handed over to the new owner.
Some important information in this manual will be indicated in the following way, please see below). The
users should pay special attention to these instructions.
The range of GENTECH GENERATORS POWERED BY HONDA is safe and reliable, but incorrect use
of these products may cause personal injury and or damage to your machine. Please read this manual
thoroughly before operation as this product is required to operate strictly in accordance with this
manual.
IMPORTANT:
PLEASE PAY SPECIAL ATTENTION TO STATEMENTS PRECEDED BY THE FOLLOWING
WORDS:
1
DANGER WARNING CAUTION
GENERAL SAFETY PRECAUTIONS:
A “LAYMAN" and or "CHILDREN" may
not recognize the possible dangers of
operating a generator. We recommend that
only competent persons should operate the
generator.
Fuel is combustible and easily ignited. Do
not refuel during operation.
Do not refuel whilst smoking or near naked
flames. Do not overfill or spill fuel. If this
happens clean the fuel on and around the
generator properly before operating.
Only use the specified fuel when operating
the generator
Some parts of the internal-combustion
engine are hot and might cause burns. Pay
attention to the warning signs on the
generating set.
Engine exhaust gases are toxic. Do not
operate the generator in an unventilated
room. When installed in a ventilated room,
additional requirements for fire and
explosion protection must be observed.
Regularly check that the bolts and nuts are
properly tightened as they may become lose
due to vibration of the generator whilst in
use.
Before using the generator ensure that you
have checked the periodic maintenance
schedule in the operator's manual.
Pay attention to the wiring or extension
cords from the generator to the connected
device. If the wire is under the generator or
in contact with a vibrating part, it may break
and possibly cause a fire, generator burnout,
or electric shock hazard. Replace damaged
or worn cords immediately.
Do not operate in rain wet or damp
conditions, or with wet hands. The operator
may suffer severe electric shock if the
generator is wet.
1.1.
1.2.
1.3.
1.4.
1.5.
1.6.
1.7.
1.8.
1.9.
1.10.
1.
1.11.
1.12.
1.13.
1.14.
1.15.
1.16.
1.17.
1.18.
If wet, wipe and dry it well before starting.
Do not pour water directly over the
generator, nor was hit with water.
Be extremely careful that all necessary
electrical grounding procedures are followed
during each and every use. Failure to do so
can be fatal.
Do not connect the generator to commercial
power line. Connecting to a commercial
power line may short circuit the generator.
We strongly recommend the use of a
Transfer Switch for connecting to a domestic
circuit.
Do not smoke when handling the battery.
The battery emits flammable hydrogen gas,
which can explode if exposed to cigarettes
and or naked flames. Keep the area well-
ventilated and keep naked flames/ sparks
away when handling the battery.
Keep children and all bystanders at a safe
distance from the generator whilst in use.
It is essential that you know and understand
the safe and proper use of the power tool or
appliance that you intend to connect to the
generator. All operators must read,
understand, and follow the tool/ appliance
operator's manual. The tool and appliance
applications and limitations must be
understood. Keep all instruction manuals
and in a safe place for future reference.
Always switch off the circuit breaker on the
generator when not in use.
Do note store the generator inside a house
or office. Do not store the generator where it
will be exposed to rain or water.
2
ELECTRICAL SAFETY INFORMATION:
Electrical equipment including cable, cords and plug connection must not be defective. Please check
before using.
Do not plug the generator directly into a wall socket-outlet.
The generator should not be connected to other sources such as the power company supply mains.
In special cases where stand-by connection to existing electrical systems or integration therewith is
intended, note that it is a legal requirement that such connections. or integration may only be
performed by a competent person.
Protection against electrical shock depends on circuit-breakers that are specially matched to the
generator. If a circuit breaker requires replacement, it shall be replaced by a circuit breaker that has
identical ratings and performance characteristics.
Due to high mechanical stresses only tough rubber-sheathed flexible cable should be used.
If the generator is of CLASS II construction, then earthing of the generator is not required.
Cord Extension Sets:
A 1.0 mm² flexible cable can draw a maximum of 10 A provided that the cable is no longer than 25 m.
A 1.5 mm² flexible cable can draw a maximum of 10 A provided that the cable is no longer than 35 m.
A 1.5 mm² flexible cable can draw a maximum of 16 A provided that the cable is no longer than 20 m.
A 2.5 mm² flexible cable can draw a maximum of 10 A provided the cable is no longer than 65 m.
A 2.5 mm² flexible cable can draw a maximum of 16 A provided that the cable is no longer than 45 m.
A 4 mm² flexible cable can draw a maximum of 10 A provided that the cable is no longer than 100 m.
A4 mm² flexible cable can draw a maximum of 16 A provided that the cable is no longer than 65 m.
DROP IN ELECTRIC EXTENSION CORDS:
When a long electric extension cord is used to connect an appliance or tool to the generator, a
certain amount of voltage drops or loss occurs in the extension cord which reduces the effective
voltage available for the appliance or tool.
The chart below has been prepared to illustrate the approximate voltage loss when an extension
cord of 300 feet (approx.100 meters) is used to connect an appliance or tool to the generator.
2.
2.1.
2.2.
2.3.
2.4.
2.5.
2.6.
2.7.
2.7.1
2.7.2.
2.7.3.
2.7.4.
2.7.5.
2.7.6.
2.7.7.
2.8.
3
SAFETY STICKERS AND EXPLANATIONS:
3.
4
Specifications are subject to change without notice.
SPECIFICATIONS:4.
5
(1) FRAME
(2) FUEL TANK
(3) AIR CLEANER
(4) TROLLEY WHEEL
(5) RECOIL STARTER
(6) HANDLE
(7) CONTROL PANEL
COMPONENTS:
WHEELS AND HANDLES INSTALLATION:
INSTALLATION STEPS:
Insert 7 into 8 and put 9 on 7. Then install into the mounting holes of 6 and tighten using 10.
Fix 4 onto 6 using 3 & 2.
Mount 5 and 1 onto 4.
Install 13 and 11 using 12. Then tighten them onto 6 using 14.
4
1. BLOCK STOPPER PROTECT
2. HANDLE LINING,
3. BOLT M8 x 16
4. HANDLE
5. HANDLE GRIP
6. FRAME
7. WHEEL AXLE
8. WHEELS
9. FLAT WASHERS - Ø10
10. NYLOC NUT M10
11. RUBBER SUPPORT
12. BOLT M8 X 90
13. RUBBER FOOT
14. NUT M8
5.2.
5.2.1.
5.2.2.
5.2.3
5.2.4.
5.
5.1.
6
WARNING
6.
6.1.
6.1.1.
6.1.2.
6.1.3.
6.1.4.
6.2.
6.2.1.
6.3.
6.3.1.
6.4.1
6.4.2.
6.4.3.
6.4.
PRE-OPERATION CHECKS:
CHECKING THE ENGINE OIL
Ensure that the generator is on a flat and level surface before
adding oil.
Remove the oil cap and check the level of the oil.(Fig. A)
Add oil to the generator if the oil is below the indicator line.
Always ensure that your engine oil is clean. (Fig. B)
OIL CAPACITY FOR THE GP6500I GENERATOR:
GP6500I - 1.0L
RECOMMENDED ENGINE OIL:
Only use 4-stroke automotive oil (API or SE) alternatively you can use a higher grade (SG, SH or
SJ). is recommended for general all-temperature use. For extreme temperatures SAE 15W-40
please use . If single viscosity oil is used, select the appropriate viscosity for the SAE 10W-50
average temperature in your area.
Use the fuel gauge to check the fuel level.
If the fuel level is too low, only refuel with unleaded fuel.
Ensure that you use the fuel filter screen on the fuel filter.
CHECKING THE ENGINE FUEL:
Do not refuel while smoking or near an open flame or other potential fire hazards.
7
6.5.
6.5.1
FUEL CAPACITY FOR THE GP6500I GENERATOR:
LITHIUM BATTERY OPERATION FOR THE GP6500I:
Installation:
ŸCheck the battery voltage with a voltmeter before fitting. If the voltage is less than
12.8 Volts, do a refresh charge (see charging section).
The recommended battery capacity is a 4 Amp Hour.
GP6500I - 25L
Make sure you review each warning in order to prevent fire hazards. Do not refill the fuel tank
whilst the engine is running or hot. Please ensure that the fuel cock is closed before refueling.
Be careful not to contaminate the fuel with any dust, dirt, water, or other foreign liquids/objects.
Please lean all spilt fuel thoroughly before starting the generator. Ensure that the generator is
clear from any open flames. Do not smoke whist refueling the generator.
CHECKING COMPONENT PARTS:
Before starting the generator, please check the following:
Check for any fuel leaking from any part of the generator.
Check that all the nuts and bolts are securely tightened on the generator.
Check for any visible damaged components on the generator.
Check that the generator is not resting on or adjacent to any electrical wiring.
CHECK THE GENERATOR SURROUNDINGS:
6.6.
6.7.
6.8.
6.6.2.
6.6.3.
6.6.4.
6.6.5.
WARNING
Make sure you review each warning in order to prevent fire hazards. Keep the surrounding
area clear of flammables or other hazardous materials. Keep the generator at least 3 feet
(1 meter) away from all buildings and or other structures. Only operate the generator in a dry,
well-ventilated area. Keep the exhaust pipe clear of all foreign objects. Keep the generator
away from open flames. Do not smoke near the generator. Keep the generator on a flat and
level surface. Do not attempt to block the generator air vents with any paper or other
material/objects
Health Warning:
The electrolyte inside the battery is harmful to skin and eyes. If the battery leaks and the
electrolyte get into your eyes, do not rub them. Instead, rinse them with clean running water
and immediately seek medical attention. If left untreated, electrolyte can cause permanent
injury to your eyes.
