Genius G12PS Manuel utilisateur
Product : Gamepad
Model Name : Max Fire G12PS
Model Number : G12PS
Version Number : 01
Service Guide
----------------------------------------------------------------- KYE SYSTEMS CORP.
2
Service Guide
Contents
1. Revision record --------------------------------------------------3
2. Maintain Guide --------------------------------------------------4
2.1 Introduction --------------------------------------------------4
2.2 Necessary tools ----------------------------------------------4
2.3 Safety attention ----------------------------------------------4
3. How to handle defective returns -----------------------------5
3.1 Procedure -----------------------------------------------------5
3.2 Problem description -----------------------------------------6
3.3 Problem solve ------------------------------------------------7
4. Assemble & Disassemble -------------------------------------10
4.1 How to Assemble and Disassemble the pad surface
-------------------------------------------------------------------10
4.2 How to Assemble and Disassemble the PSB ------------11
4.3 How to Assemble and disassemble the Ministick
-----------------------------------------------------------------12
4.4 How to Assemble and Disassemble the Motors ----------13
4.5 How to Assemble and Disassemble the LED -------------14
5. Appendix 1. Part list ------------------------------------------15
6. Appendix 2. Disassemble drawing -------------------------16
----------------------------------------------------------------- KYE SYSTEMS CORP.
3
Service Guide
1. Revision Record
Date Version Name Approve
2003/5/15 1.0 Bam Niky
----------------------------------------------------------------- KYE SYSTEMS CORP.
4
Service Guide
2. Maintain Guide
2.1 Introduction
Please pay attention to this guide, and follow the information to
prevent resulting damage.
This maintain-guide is against hardware problems of this pad.
2.2 Necessary tools
2.3 Safety attention
When staying for long time, please check electric and power circuit.
Place it in flat surface and prevent it from vibration.
Don’t drop and jolt this pad.
Don’t remove this pad from your PS when it is using.
Keep this pad away wet and high temperature.
Screwdriver
Tweezers
Solder
Solder torch
Tin-Sucker
----------------------------------------------------------------- KYE SYSTEMS CORP.
5
Service Guide
3. How to handle defective returns
3.1 Procedure
Analyze possible
malfunction causes
Frame the solutions
and methods
Replace necessary
defective parts
Test all function to
check the pad is ok.
Return the pad to
customers
Received
Defective Pad
Test &Check
problem
Function NG
Function OK
Function OK
Function NG
----------------------------------------------------------------- KYE SYSTEMS CORP.
6
Service Guide
3.2 Problem Description
Item Problem Description
3.2.1 Ministick’s
function wrong
1) Can’t control ministick correctly and
completely.
2) Ministick is no work.
3.2.2 Motors are
incorrect
1) One or both of two motors is no work.
2) Any Motors’ rotation is incorrect.
3.2.3 LED 1) LED isn’t bright
2) LED is twinkling
----------------------------------------------------------------- KYE SYSTEMS CORP.
7
Service Guide
3.3 Problem solve
3.3.1 Ministick’s function wrong
Problem
Analyze the
problem
Judge the problem
causes
Solution
Ministick wrong
Mechanics Electronics
1. Incorrect using causes
the mechanics of
ministick broken.
2. Out of life
1. Using for too long
time causes the value of
VR instable.
2. Out of life
Replace the
Ministick
Replace the
Ministick
----------------------------------------------------------------- KYE SYSTEMS CORP.
8
Service Guide
3.3.2 Motors are incorrect
Problem
Analyze the
problem
Judge the problem
causes
Solution
Any motor is no rotation
Motor’s Mechanics Electronics
1. Out of life 1. The cord between
Motor and PCB is fall
off.
Replace the
Motor
Re-solder the
Cord
----------------------------------------------------------------- KYE SYSTEMS CORP.
9
Service Guide
3.3.3 LED
Problem
Analyze the
problem
Judge the problem
causes
Solution
LED isn’t bright
Mechanics Electronics
1. Out of life
1. The cord between LED
and PCB is fall off.
Replace the LED Re-solder the
cord
----------------------------------------------------------------- KYE SYSTEMS CORP.
10
Service Guide
4. Assemble & Disassemble
4.1 How to Assemble and Disassemble the pad surface
Procedure Graphics
1. Disassemble
1) Turn over the pad
2) Put the pad on a flat
3) Rotate screws
4) Separate pad’s covers
2. Assemble
1) Compose all parts according to
disassemble drawing
2) Lock all screws firmly
Attention:
When assembling the pad
surface, please put a cloth to
prevent it from rub.
