Genius SLIM MATE 3000 Manuel utilisateur

Hardware Installation

1. Install two AAA batteries in the mouse and two AAA batteries in the keyboard.

2. You can connect the receiver to a USB port of a PC.

3. Turn on your computer.

Software Installation

1. Make sure the mouse and keyboard is connected to the computer.

2. Put the Setup disk (or CD) into the disk drive.

3. Follow the instructions on the screen to finish the software installation.

Replace Batteries

If you feel the mouse does not move smooth as usual or the keyboard does not work

when typing, then the batteries have lost their charge, so please replace them.

Furthermore, do not mix or use different types of batteries at the same time.

ID channel setting

The channel buttons are factory preset. The green LED, the data transmission indica-

tor, on the receiver will be lit when the keyboard or mouse is in normal operation. If

your keyboard/mouse does not work, then you have to set the ID channel setting.

Please press the button on the receiver first (RB) and press the button under the

mouse (MB) and the keyboard (KB) within twenty seconds. So you press RB, MB

and KB to set the channel setting.

ENGLISH

Warning: (Troubleshooting)

1. Please do not use the wireless optical mouse on a desk that is made of glass,

mirror, iron, or black velvet. Also a desk that is made of metal will reduce the

receiving distance of the keyboard and mouse.

2. Before the first installation is completed (channel setting ready), the keyboard

will not work in DOS. If your USB keyboard does not work in BIOS, DOS or

Windows, then use another PS2 keyboard to make the USB controller (USB

function) and USB legacy (USB keyboard) “On” in the BIOS setup. This may

occur with older BIOS versions. Then unplug the PS/2 keyboard and plug in

your USB keyboard and everything should be working properly.

3. The SlimMate 3000 channel provides 256 ID-codes, and it automatically selects

the ID # for your keyboard and mouse. You can only set up one SlimMate 3000

at a time. But if you have additional SlimMate 3000 sets in an area of 10 square

meters, more interference may occur between the receiver and your keyboard

and mouse.

4. The SlimMate 3000 with radio frequency gives you free movement and an en-

joyable experience. For optimal performance, place the receiver at least 8 inches

(about 20 cm) away from the mouse and other electrical devices, such as the

computer, monitor, and etc.

Factory Setting

1. Mouse:

Button Assignments

The Button Assignment feature lets you work in a more efficient way because you

can assign the most frequently used commands in Windows to the mouse buttons.

Magic-Roller Press the “Magic-Roller” to surf the Internet and Windows docu-

ments

Left Button Provides traditional mouse functions such as click, double click and

drag.

Right Button You can assign this button frequently used keyboard and mouse func-

tions in addition to features like EasyJump, Auto-Panning, Zoom, etc.

Roller ButtonYou can assign this button frequently used keyboard and mouse func-

tions in addition to features like EasyJump, Auto-Panning, Zoom, etc.

2. Keyboard:

1. Volume: Vol. Down

2. Volume: Vol. Up

3. Stop: Stop play of audio or video CD’s

4. Play/Pause: Play and pause of audio or video

CD’s

5. Media: Media player program

6. WWW: Open browser in Netscape or IE

7. E-mail: Open mail folder

8. Refresh: Refresh the page

9. Back: See last page when viewing the Internet

10. Forward: Go to next page when viewing the Inter-

net

11. My favorite: Open my favorite folder

12. Sleep: Turn system into sleep mode

’’EasyJump for Windows

“EasyJump” now has two working modes: Office

EasyJump mode and Traditional EasyJump mode.

“Office EasyJump” lets you use eight commonly

used applications and 16 Cyber functions more easily

and quickly.

Once you press the button you assigned, “Office

EasyJump” will be displayed on a Frisbee. Note that

the functions are only available in the applications

they belong to.

Click this application button to show the mouse control panel. You can check

or modify the mouse properties.

Click this function and the pan icon appears. You can move the mouse

in any direction in a document or a spreadsheet. The farther you move

the pointer from the pan icon, the faster you can pan in that direction.

Click this function and Office EasyJump Frisbee will always be on the

screen and the button will change to . Click it again to cancel this

effect.

This is a programmable application button. Press the right button on this icon

and a dialog box will display for you to select an executable program. Click

on this button to launch your specific application.

Click this function to implement the “replace” function in the current ap-

plication.

ENGLISH

Click on this application to launch Microsoft Word.

Click this function to perform the “cut” function in Word.

Click this function to implement the “paste” function in Word.

Click on this application to launch Microsoft Excel.

Click this function to implement the “select all” function in Excel.

Click this function to perform the “undo” function in Excel.

Click on this application to launch Microsoft PowerPoint.

Click this function to implement the “zoom in” function in PowerPoint.

Click this function to implement the “zoom out” function in Power-

Point.

Click on this application to launch Outlook Express or any other email client

application installed in your system.

Click this function to open a new email.

Click this function to forward a selected email in your mailbox.

Click on this application to open Microsoft Internet Explore or any other

Internet browser installed in your system.

Click this function to return to the previous web page in your open

Internet browser.

Click this function to more forward to the next web page in your open

Internet browser.

Click on this application to launch Windows media player or any other multi-

media player installed in your system.

Click this function to play/pause the current running media player.

Click this function to stop the current running media player.

Note: All the functions related to Office applications

are programmable. Place the cursor on the function

icon you want to change, and click the right button

to select or reset the unit from the popup menu.

From the dialog box, you can choose another func-

tion to use in the EasyJump Frisbee.

To change from Office EasyJump mode to Tradi-

tional EasyJump mode, just click the right button on

the Genius logo in the center of the EasyJump Fris-

bee.

The “Traditional EasyJump” lets you use eight Cyber functions more easily and

quickly.

Once you press the button you assigned, the “EasyJump” Frisbee will pop up and

eight functions will be displayed on Frisbee.

Click this button to close the current window.

Click this button and the cursor will jump to the horizontal scrollbar. When

you move your mouse, the open document or spreadsheet will scroll horizon-

tally.

Click this button and the cursor will jump to the vertical scrollbar. When you

move your mouse, the open document or spreadsheet will scroll vertically.

Click this button to open the Start Menu.

Click this button to open the Help button.

Click this button to open the Genius Mouse Control Panel.

Click the button and you can move the mouse in any direction in a document

or a spreadsheet. The farther you move the pointer from the pan icon, the

faster you can pan in that direction.

The buttons in “EasyJump Options” are especially used for the Internet. The default

function is “Open Browser” (button like ). You can select other functions from

“EasyJump Options” in the “Settings” folder of the Genius Mouse Control

Panel. The functions in “EasyJump Options” are:

“Add to Favorite [IE] ” “Organize Favorite [IE] ”

“Add Bookmark [NetScape] ” “Edit Bookmark [NetScape] ”

“Go Next [Forward] ” “Go Previous [Back] ”

“Run Application”

ENGLISH

Switch Applications

When the right-button or Magic-Roller is set to “Switch AP”, you can quickly switch

from one open application to another without moving the mouse. To switch to a spe-

cific application, press the right button or the Magic-Roller to select the application.

Zoom function for Value and IE Applications

Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the

Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right

button to be the “Ctrl” function, press the right button and move the “Magic-Roller”

forward (or backward) to enlarge (or decrease) the document window.

Auto-Panning

You can set this function in the Button Assignment menu. Move the mouse, and the

document moves in the direction you just moved.

Uninstall the Software

Follow these instructions to remove the software from your hard disk. In Windows,

click on the Start button, select Programs and move to the mouse software. Then click

on Uninstall software.

Customize the Software

This section shows you how to customize the software. To open the software control

panel, you can double-click on the icon in the task bar or select the “Software” icon

from the program group.

Close the Software

Click the right button on the taskbar, and select “Close Software” to close the soft-

ware.
