GENERAL MOBILE DST13 Manuel utilisateur

Table of Contents

1.For your Safety .................................................................................................................................3

2.Mobile Phone Profile ........................................................................................................................3

3.Preparation before Use ......................................................................................................................4

4.General Instructions for Mobile Phone..............................................................................................9

5.Basic operation ............................................................................................................................... 15

6.Use Menu Functions ....................................................................................................................... 18

7.English Editor Operation................................................................................................................. 49

8.Use USB ......................................................................................................................................... 50

9.Appendix 1...................................................................................................................................... 50

10.Appendix 2.................................................................................................................................... 52

11. Appendix 3 ................................................................................................................................... 53

1.For your Safety

For your safety and for proper use of the mobile phone, please read the following guidelines carefully:

 Do not switch the mobile phone on when close to chemicals, gas stations or other explosive materials.

 During driving, please use the headset for safety purpose; otherwise in cases of emergency, always

stop the car by the roadside to have a call conversation.

 Because the use of the mobile phone can cause interference in the aircraft, never use the mobile phone

in aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone

before boarding.

 Pay special attention to the use of the mobile phone near heart pacemakers, deaf-aids and other

medical equipments, because the mobile phone can cause interference with them.

 Use of uncertified accessories and parts will void the guaranty

 Do not dismantle the mobile phone without permission. In case of failure, please contact the supplier

as soon as possible.

 Do not plug the charger into the mobile phone and charge without battery. Always power off the

mobile phone when taking out the battery; otherwise the memory of the phone may be damaged.

 When charging the mobile phone, always keep it in the place with good ventilation, heat sink and

away from flammable and explosive objects.

 In order to avoid demagnetization, always keep the mobile phone away from magnetic objects such as

CDs, credit cards etc.

 Ensure that the mobile phone does not come in contact with any liquid; if it does occur, remove the

battery and contact the supplier immediately.

 Do not use the mobile phone in the environments with extreme temperatures, never expose the mobile

phone to strong sunlight or a wet environment. The suitable temperature for the phone and accessories

is 0℃-40℃. The height to use the phone shall be less than 2,000m.

 Do not use liquid or wet cloth with strong cleanser to clean the mobile phone.

 This mobile phone has Bluetooth, Image viewer, Audio player, FM radio, Schedule FM record and

Melody composer functions, which shall be used as per the related laws and regulations.

 Always keep the mobile phone out of children’s reach. Do not throw or vibrate the mobile phone

because violent treatment to the mobile phone may damage the inner circuits and precise structures.

 Please do not discard the waste battery into general household garbage. Please deal with the waste

battery according to provisions where they are definitely made.

Warning: We will not be bear any responsibility for any incompliance with the above guidelines or improper

use of the mobile phone.

Our company keeps the right to make modifications to any of the content here in this user guide

without public announcement in advance.

The content of this manual may vary from the actual content displayed in the mobile phone. In

such case, the latter shall govern.

2.Mobile Phone Profile

The mobile phone has 17 keys on the keypad. In addition, it is inbuilt with one vibration motor, one

charger/data common transmission port.

(Below is the front of the mobile phone)

Receiver

Right selection key

Left selection key

Switch on/off/end key

Send /call key

Ok key Number key

3.Preparation before Use

Install SIM Card

When registering mobile phone number, you can apply for two different phone numbers, two different

mobile phone network service providers and thus obtain two SIM (Subscriber Identification Module) cards.

With these two SIM cards, you can use all functions of your mobile phone. The SIM cards save the

parameters needed for communications and personal data, including PIN (Personal Identification Number)

code, phonebook, short message and other extra system services.

SIM card

Warning: Do not distort or scratch the SIM card nor let it contact static, dust or moisture. If it is lost, please

contact immediately with your network operator for help.

Before SIM card installation, please switch off the mobile phone. The SIM card is installed on the back

of the mobile phone.

Follow the following diagram to install the SIM card. Please insert the host SIM card into the SIM1 slot

and the slave SIM card into the SIM2 slot.

Note: If SIM card is inserted only into the SIM1 slot, then only the host works; likely, If SIM card is

inserted only into the SIM2 slot, then only the slave works. When two SIM cards are inserted into the SIM1

slot and SIM2 slot respectively, you can choose work mode freely as you wish.

Note: As the SIM card is small object, keep it out of children’s touch or prevent children gulping it!

Install Memory card

As the mobile phone does not have enough storage space, to use some functions, you need to install a

memory card (This mobile phone use T-FLASH card.)

Install T-FLASH card: Open the back cover to take off the battery, release the T-Flash card lock, insert

the T-Flash card into its slot, restore the lock and then put back the battery restarting the mobile phone. The

LCD will give the note that the T-flash card has been detected.

Note: As the T-FLASH card is small object, keep it out of children’s touch or prevent children gulping it!

Install Battery

The mobile phone is suitable for original battery and accessories. When the battery is idle, it is

recommended to put it into the protection box.

Follow the following diagram to install the battery.

Battery

Note: Do install the battery as per the diagram so as prevent the battery contact patch being damaged.

Charge Battery

The new battery cannot reach the optimal efficiency unless it has undergone several continuous

complete charges and discharges.

When the battery is used up, charge it in time. Over-discharge can damage the battery.

After the battery is charged full, cut off the connection of charger with the AC power supply and then

the connection with the mobile phone.

Follow the following diagram to connect the charger.

Headset/Charger Interface

During charging, the battery capacity icon on the screen flickers from the right to the left. After the

battery is charged full, the icon is full of bars. Slight heat during charging is normal.

Warning: When a travel charger and its accessories are used to charge the battery, please firstly check if they

are original or recognized by the original manufacturer. The use of other accessories may damage your

mobile phone and cause risks! Always use them indoor and in dry places.

Notices on using the battery

The performance of the battery is affected by many factors, including radio barrier network settings,

signal strength, work temperature, chosen and used functions or settings as well as phone accessories, tone,

data or other applications.

For optimal performances, please follow the rules below:

 New battery or the battery having been idle for long need charging for long. The standard voltage

scope for the battery is 3.6V-4.2V.

 During charging, keep the battery at room temperature or similar temperature.

 With time passing by, the battery will gradually be worn and thus need longer time to charge. This is

normal. However, after normal charging, if call duration decreases but charging time increases, you

need to buy another battery from the original manufacturer or authorized by the original manufacturer.

The battery of interior quality can damage your mobile phone and cause danger!

 If the phone is overused at low battery when charging, there might need a longer time for the charge

indicator to be shown on the screen.

Note: Please dispose the battery according to the local regulations. Try to recycle the battery as possible. Do

not treat the waste battery as common waste.

Warning: Do not throw the battery into fire so as to prevent fire. The broken battery may cause explosion.

Warning

Charging the mobile phone by improper means can cause to explosion.

Always refer to the related regulations for the disposal of the battery.

PIN Code

PIN1 Code:It is the personal identification number used to enter SIM1 and able to prevent others using

SIM1 without permission. If the mobile phone has activated the PIN1 code protection, when the mobile

phone is switched on, the screen will display “Input SIM1 PIN”. In the process of inputting PIN1 code, the

screen will use “*” to represent the input content. While obtaining SIM1, you can obtain its PIN1 code.

PIN2 Code: It is the personal identification number used to enter SIM2 and able to prevent others using

SIM2 without permission. If the mobile phone has activated the PIN2 code protection, when the mobile

phone is switched on, the screen will display “Input SIM2 PIN”. In the process of inputting PIN2 code, the

screen will use “*” to represent the input content. While obtaining SIM2, you can obtain its PIN2 code.

PUK Code and PUK2 Code(8-digit)

To change the locked PIN1 code, you need to use PUK1 (Personal Unblocking Key) code. To change

the locked PIN2 code, you need to use PUK2 code. If these two codes are not provided together with the

SIM cards, ask the local service provider for them.

Warning: If the PIN code is input wrongly for successively three times, the SIM card will be locked. Please

contact the network operator immediately for help. Attempting to unlock the code may make the SIM card

ineffective forever!
