881733 E

IMPORTANT SAFETY INSTRUCTIONS

WHEN USING ELECTRICAL PRODUCTS, BASIC PRECAUTIONS

SHOULD ALWAYS BE FOLLOWED INCLUDING THE FOLLOWING:

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

1. This is an electrical product - not a toy! To avoid risk of ﬁre, burns, personal injury, and electric shock, it should not be

played with or placed where small children can reach it.

2. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used

in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided,

contact a qualiﬁed electrician for proper installation.

3. This seasonal use product is not intended for permanent installation or use.

4. Do not mount or place near gas or electric heaters, ﬁreplaces, candles, or other similar sources of heat.

5. Do not secure product wiring with staples or nails or place on sharp hooks or nails.

6. Do not let lamps rest on the supply cord or on any wire.

7. This product is equipped with push-in type lamps. Do not twist lamps.

8. Unplug the product when leaving the house, when retiring for the night, or if left unattended.

9. Do not use this product for other than its intended purpose.

10. Do not hang ornaments or other objects from cord, wire, or light string.

11. Do not close doors or windows on the product, or extension cords, as this may damage the wire insulation.

12. Do not cover the product with a cloth, paper, or any material not part of the product when in use.

13. Do not place the product against carpeting, furniture, or any other fabric when in use.

14. This product employs overload protection (fuse). A blown fuse indicates an overload or a short-circuit condition. If the

fuse blows, unplug the product from the outlet. Also unplug any additional string or products that may be attached

to the product. Replace the fuse as per the user servicing instructions (follow product markings for proper fuse rating)

and check the product. If replacement fuse blows, a short-circuit may be present and the product should be discarded.

15. This product has a polarized plug (one blade is wider than the other) as a feature to reduce the risk of electric shock.

This plug will ﬁt in a polarized outlet only one way. If the plug does not ﬁt fully in the outlet, reverse the plug. lf it still does

not ﬁt, contact a qualiﬁed electrician. Do not use with an extension cord unless plug can be fully inserted. Do not alter or

replace the plug.

16. Read and follow all instructions that are on the product or provided with the product.

SAVE THESE INSTRUCTIONS

USE AND CARE INSTRUCTIONS

1. When the product is placed on a live tree, the tree should be well maintained and fresh. Do not place on live trees

in which the needles are brown or break off easily. Keep the tree holder ﬁlled with water.

2. If the product is placed on a tree, the tree should be well secured and stable.

3. Before using and reusing, inspect the product carefully. Discard any products that have cut, damaged or frayed wire

insulation cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire.

4. When storing the product, carefully remove the product from wherever it is placed, including trees, branches, or

bushes, to avoid any undue strain or stress on the product conductors, connections and wires.

5. When not in use, store carefully in a cool, dry location protected from sunlight.

WARNING: READ AND UNDERSTAND ALL INSTRUCTIONS.

Failure to follow all instructions listed below may result in electric shock, ﬁre and/or serious personal injury.

WARNING:

ELECTRIC PRODUCT. Keep away from children. Not recommended for children under 3 years

of age. As with all electrical products, precautions should be observed during handling and use to reduce the risk

of electric shock. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard. To avoid the risk of electrical shock, always make sure the product is

unplugged from the electrical outlet before assembling, disassembling, or relocating.

WARNING:

This product is to be assembled by adults only.

INSTRUCTIONS

Thank you for purchasing the

Lantern Snowman

! Below you’ll find assembly instructions and other information to get

maximum enjoyment from your purchase! Please keep these instructions for future reference.

Please read over the directions carefully before installing and operating this item. Some assembly is required.

CONTENTS

ASSEMBLY INSTRUCTIONS

1. Carefully remove item from the protective wrap to avoid damaging

any of the light bulbs or parts. Take out Lantern (A) from box stretch to

shape snowman. See illustration 1.

Illustration 1

PART DESCRIPTION QUANTITY

A Lantern 1

B Tube A 1

C Tube B 1

D Base 1

E String Lights 1

F Scarf 1

G Ribbon 1

PART DESCRIPTION QUANTITY

H Arms 2

I Plastic Ties 10

J Cotter Pins 2

K Yard Stakes 4

2. Attach the light string (E) to the tube A (B) with the included plastic

ties (I). To avoid having the light string slide down, make sure the ﬁrst

bulb is fastened to the ring on the top of the tube A (B). See illustration

3. Hang the snowman body on the tube A (B) by inserting the rod

in the top center of the snowman's hat into the top of the upper pole

while making sure that the upper pole is inserted thru the ring on the

bottom of the snowman's hat and neck. Then insert the tube B (C) into

the tube A (B), connect the bottom tube B (C) to the rod on the base (D).

Then gently lower the snowman downward. See illustration 3.

4. Insert 2 arms (H) with connecting poles into the body. Secure with

a cotter pin (J).

5. Find the side of the base (D) with the spring buckle, The hook on

the front of the snowman needs to attaching this side of the ring. Then

attach the other two hooks to the corresponding ring. See illustration 4.

Illustration 2

Illustration 3

Illustration 4

Spring Buckle

6. Place the scarf (F) around the neck, making sure the hole on the

scarf aligns with the hole for the hanging scarf on the side of the

neck, secure with the pre-attached velcro. Then insert the rod of the

hanging ribbon (G) into the hole on the neck. See illustration 5.

7. Secure the item ﬁrmly to the ground using the yard stakes (K). See

illustration 6.

Illustration 5

Illustration 6

CAUTION: The frame straps (Plastic ties) should not be placed around any conductor wire during assembly!

Disassembly Instructions --- Please refer to assembly instruction above, but in reverse order.

Approximate Assembly time:10-15 minutes.

USER SERVICING INSTRUCTIONS

Lamp Replacement: Disconnect the plug from the electrical outlet and allow the lamp to cool

completely before replacing bulb. Do not touch the bulb when the power is “ON” as it is extremely hot

and may cause electrocution. Remove the lampholder, gently unscrew the light bulb and replace with C7

light bulb.

Fuse Replacement:

WARNING: Risk of Fire: Replace only with same size and type of fuse.

WARNING: Risk of Fire: Do not replace the attachment plug. Contains a safety device (fuse) that should not be

removed. Discard product if attachment plug is damaged. 1. Grasp plug and remove from the receptacle or other outlet

device. Do not unplug by pulling on the cord. 2. Open fuse cover. Slide open the fuse access cover on top of the attachment

plug towards blades. (See illustration) 3. Remove fuse carefully. 4. Replace fuse only with 5 Amp Max, 125 volt (provided

with product) 5. Close the fuse cover. Slide closed the fuse access cover on top of the attachment plug.

CAUTION: Replace only with same type C7, 0.6 Watt Max Candelabra-base 120 Volt Classiﬁed lamps.

CAUTION: To reduce the risk of ﬁre, do not deliberately reposition either lamp holder contact.

CAUTlON: To reduce the risk of ﬁre and electric shock:

a) Do not install on trees having needles,leaves or branch coverings of metal or materials which look like metal.

b) Do not mount or support wires in a manner that can cut or damage wire insulation.

WARNING

Strobe lights have been known to trigger seizures in people with photosensitive epilepsy.

Do not remove light string from the product and hang on trees or other places for decoration.

STORAGE

Do not discard the box, it can be used to store the product. Store in a cool, dry location.

TROUBLESHOOTING CHECKLIST

If the item is not operating, the problem may be:

1. The power source is disabled or the cord is unplugged.

NOTE: ONCE THE ITEM IS UNPLUGGED, THE PRODUCT WILL CEASE OPERATION.

FREQUENTLY ASKED QUESTIONS (FAQs)

1. Can I leave it running overnight?

We recommend that you turn off while unattended. Extended use beyond 8 hours will not damage this item.

2. How much electricity does it use?

Please refer to the tag attached to the power cord.

3. What is the best way to store it?

Store dry in a bag, box or other storage container and keep in a cool, dry location.

4. My area is prone to unusually windy conditions, will this affect the product?

In order to prevent damage, we suggest you keep the product protected from high winds by simply relocating the

item to a sheltered area until wind conditions improve.

5. What if it is raining or snowing? Will this affect the product?

Operation in light weather conditions, such as a gentle rain or snowfall is ﬁne.

6. I have extra plastic Ties. What are these for?

You may use these to further secure the product as desired.

THESE INSTRUCTIONS ARE FOR ITEM NUMBER

881733

Visit WWW.GEMMY.COM for more information.

117 WRANGLER DRIVE, SUITE 100

COPPELL, TX 75019 U.S.A.

1(877)250-9032

MADE IN CHINA / PRINTED IN CHINA
