Gemini GVC100BK Manuel utilisateur
Model No./ 型號 : GVC100BK
直立/手提
充電式吸塵機
STICK / HANDHELD
RECHARGEABLE
VACUUM CLEANER
Please read this instruction manual carefully before
use and keep it for future reference.
請於使用前仔細閱讀本說明書並加以保存。
SAFETY INSTRUCTION
Attention! When using electric tools, basic safety precautions should be followed
to reduce the risk of fire,electric shock and personal injury,including the following,
Please read this manual carefully before operating this product and retain it for
future reference.
1.For the first time use or use after long-term storage, please fully charge the
product. Please use the power adapter of 5V/2A or above which need a safety
certification, and a standard charging line to charge the product.
2.Long press the power button, the indicator light flashes, the vacuum cleaner
cannot be started, the battery is low, please charge it immediately.
3.Please use the charging cable delivered by this machine to charge the
product, or use the mobile phone charger to charge the product. It is forbidden
to purchase an adapter to charge the product without permission.
4.The battery life of the vacuum cleaner may decrease as the number of times
the product is used increases.
5.Clean up the HEPA filter in time, otherwise it will affect the dust removal effect.
6.After using the product, please put it in a cool, dry, away from high temperature,
high humidity and high dust environment.
7.When using this product to remove dust, it is strictly forbidden to inhale
combustion materials, such as cigarette butts, just-extinguished charcoal
ashes and burning paper scraps.
8.Due to the built-in high-rate lithium battery, it is strictly forbidden to
disassemble the product without permission in case of abnormal noise or other
suspected quality problems.
9.Do not use this product to absorb water and wet objects, otherwise it will
damage the motor and cause permanent damage to the product, and the
product quality problems caused by this behavior are not covered by the
product warranty.
10.After use, please put it out of the reach of children. Children are strictly
prohibited from operating without permission.
11.This product is not suitable for use in high magnetic field environments.
12.The filter should be cleaned frequently. If the filter is too dirty, it will affect the
use of the vacuum cleaner.
1
1.Do not place in high temperature or high humidity environment.
2.Do not modify, disassemble, crush, or throw into fire.
3.If there is any abnormality, please do not continue to use and disassemble
without permission.
4.It is strictly forbidden to use unapproved or incompatible adapters and charging
cables to charge the product, which may cause malfunctions and dangers.
5.Before long-term storage, please fully charge the product. Please charge the
battery to at least 85%. It is recommended to charge the battery every 2-3
months to extend its service life. Otherwise, the service life of the battery will
be affected and the product cannot be used normally.
6.This product is not suitable for use by children, or persons with physical,
sensory and mental impairments.
WARNING
!
2
APPLIANCE COMPONENTS
TYPE-C charging port
Air outlet
Dust bin
Dust bin switch button (press the
buttons on both sides at the same
time to open the dust bin)
Handle
Indicator light
LED lights
HEPA filter
Air inlet dust shield
On/off button
First gear about 8000Pa
Recommend using 5V 2.4A charger.
（Tip: This product does not contain adapters）
Press and hold for 1s to start the vacuum cleaner,
short press the first gear/second gear cycle,
long press for 1s to shut down.
30%
60%
100%
Vacuum degree
The battery is fully charged: Three indicators are
always on(with the increase of the machine use time,
the battery power gradually decreases, and the
indicator lights turn off in turn)
The battery is discharged: the three indicators flash,
and the machine shuts down at the same time
charging: The three indicators flash alternately
3
Second gear about 13000Pa/
/
Product power 100W
Working noise <95dB
Working voltage 11.1V
Battery Specification 2000mA*3
Endurance time First gear 20-25min Second gear 10-13min
Charging time About 4H
Charging voltage DC-5V
Charging current ≥2000mA
Charging port TYPE-C
Working Temperature -10℃~50℃ (14℉~ 122℉)
Storage Temperature -20℃~60℃ (-4℉~140℉)
Dust cup capacity 0.35L
Product Dimension H*W*D: 35.1*14*10.4CM
Weight About 1.2kg
How to Charge
1. Place the vacuum cleaner on the desktop/flat surface.
2. Insert the USB power cable into the charging hole of the vacuum cleaner.
3. Connect the other end of the power cord to a 5V 2.4A USB socket, such as
a USB charger, mobile power supply, etc.
Note: Please use the charging cable delivered by this machine or the purchased
mobile phone charger to charge the product.
1. When the power supply is exhausted, the three indicators flash and turn off to
protect the equipment.
2. The battery is not removable. Please do not squeeze or remove the battery.
3. When the ambient temperature exceeds 50℃/140℉, it is forbidden to use the
battery.
4. Please charge the battery to 60% before not using the storage for a long time.
5. If the machine stops working in a short time, please keep the battery fully
charged.
1. Suction nozzle: suitable for dust cleaning of various gaps such as doors, seats,
cabinet corners, drawers and ashtrays.
2. Brush: It combines the dual functions of suctionand wiping, and is suitable for
cleaning dust on various surfaces such as cushions,suede parts of foot pads,
keyboards and air-conditioning outlets.
3. Corrugated hose: it can be twisted at any angle, and can be used to clean
various inaccessible corners with other accessories.
4. Extension tube+floor brush: suitable for dust cleaning on the floor, bed bottom,
sofa bottom, cabinet bottom and various large flat surfaces that cannot be
touched.
4
Note
Accessories installation and use
What’s in the box
Suction nozzle
5
TYPE-C charging cable
Brush
30cm corrugated hose
Hose connector (small/large)
Floor brush
Extension tube
X1
Car charger X1
X1
X1
X1
X2
X1
X2
Small brush X1
Replace accessories
Hose connector
(small)
Installation method of corrugated hose and floor brush
Hose connector
(large)
Extension tube
Insert connections in the direction of the arrows in turn
Insert connections in the direction of the arrows in turn
Product Name: Car charger
Product size: 24*46mm
Product weight: 20g
Material: All aluminum alloy
Input: DC 12V-24V
Output: 5V/2.4A
Applicable models: 12V-24V models
6
Car charger use and safety instructions
One end of the car charger is inserted into the
car cigarette hole, straight into the bottom, so
that it is tightly stuck with the cigarette hole,
after the USB interface is powered on, it lights
up with blue light, and then the other end is
connected to the USB charging cable.
!Note:
1. Do not allow the machine to collide with hard objects, as this may cause
grinding on the surface of the machine or other hardware damage.
2. Please use the voltage specified by this machine (DC 12V-24V),
otherwise the machine may work abnormally or damaged.
3. For a long time of non-use, please disconnect the unit from the power
supply of the cigarette lighter.
4. For safety reasons, do not use this product under drops, high temperatures
or short circuits, do not throw this product into fire, and keep this product
out of the reach of children.
!
1. Press the dust bin switch buttons on both sides of the host at the same time,
and the dust collection hood will open automatically.
2. Remove the filter element from the dust collection hood.
3. Rotate the filter element anticlockwise to separate the steel mesh from the
HEPA filter element.
4. Pour the garbage in the dust collection hood into the garbage can.
5. If necessary, clean the dust collection cover with a slightly wet rag or
disposable paper towel; The filter element can be flushed with water.
6. After cleaning, the filter element must be thoroughly dried before reuse. (Do
not expose to the sun)
Note: After washing, the filter element must be dried and then installed into
the dust collection cover. It is forbidden to install the filter element into the
dust collection cover without drying, so as to prevent the moisture of the filter
element from causing corrosion of the motor and the base plate.
How to Clean
7
Push the
button
Take out the
filter element
Counterclockwise rotation
Air dried HEPA
filter element
take out the
trash
Cleaning the
HEPA filter
8
TECHNICAL DATA
Model No. : GVC100BK
Power supply: DC 5V/ 2A
Product power : 100W
Dust cup capacity: 0.35L
Product Dimensions: H*W*D: 35.1*14*10.4 CM
Product size: H*W*D: 111*14*10.4 CM (including floor mop)
Net Weight: About 1.2kg
MULTIPLE CIRCUIT PROTECTION
This marking indicates that this product should not be disposed with
other household wastes.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for
environmental safe recycling.
Over-charge protection: When voltage reaches 4.2 V, it will automatically
stop charging and prevents the damage caused by the over charging of
the battery.
Over-discharge protection: When the fan speed will automatically decrease to
protect the device when power is going to exhaust.
Over-voltage protection: When the external charging voltage is higher
than 4.25V, it will automatically stop charging.
!
重要安全事項
警告
9
注意：當使用此產品時，應遵循基本的安全預防措施，以減少火災，觸電和人身
傷害的風險，包括以下內容：
在操作本產品之前，請仔細閱讀本手冊，並保留本手冊以備將來參考。
1. 首次使用或長期存放後使用，請將產品充滿電，請使用經過安全認證的5V/2A及
以上的轉接器和標配的充電線給產品充電。
2. 長按開機鍵指示燈閃爍，吸塵機無法啟動，是電池電量不足，請即時充電。
3. 請使用本機配送的充電線給產品充電，或者使用手機充電器給產品充電，禁止
私自購買轉接器給產品充電。
4. 隨著產品使用次數的增加，吸塵機續航時間可能會衰減。
5. 要及時清理HEPA 濾網，否則會影響除塵效果。
6. 產品使用完畢後請放在陰涼、幹燥、遠離高溫、高濕、高塵環境。
7. 在使用本產品除塵時嚴禁吸入燃燒物，如煙頭、剛熄滅的炭火灰和燃燒的紙屑。
8. 因內置高倍率鋰電池，如遇產品異響或其他疑似質量問題嚴禁私自拆卸。
9. 請勿使用本產品吸水以及潮濕物體，否則會損壞電機造成產品永久損壞，由此
行為造成的產品質量問題不屬於產品質保範疇。
10. 使用完畢後請放在兒童觸摸不到的地方，嚴禁兒童私自操作。
11. 本產品不適用高磁場環境下使用。
12. HEPA 濾網應經常清潔，如果HEPA 濾網太臟，會影響吸塵機的使用。
1. 請勿置於高溫或高濕的環境中。
2. 禁止改裝、拆卸、擠壓、或投入火中。
3. 如出現異常請勿繼續使用。
4. 嚴禁使用未經認證許可或不兼容的轉接器、充電線給產品充電、可能引發故障
和危險。
5. 長期存放前,請將產品充滿電,請至少將電池充電至85%，並建議每2-3個月充電
一次，以延長電池使用壽命,否則會影響電池使用壽命,導致產品不能正常使用。
6. 本產品不適用兒童、或肢體、感官、精神上有缺陷的人使用。
