Spare Part List
Code Description
Accessories
MDL345019 Music Stand
271330 GK350 Owner's Manual (En lish, Italian, French, German)
271331 GK350 Owner's Manual (Spanish, Dutch, Danish)
Optional Accessories
970315 AC-DC Adapter 230Vac 26.4W (Europe)
970316 AC-DC Adapter 115Vac 26.4W (U.S.)
130301 2mt Midi Cable
970116 Switch Pedal
970110 X Metal Stand
GK350 Assembl
MDL825002 Controls Panel Assembl
MDL815008 * Controls Panel Board (Pcb#31-1467-6)
MDL735016 * Lcd Displa Assembl (Pcb#31-1479-1)
MDL675004 * Actuators Kit (comprehensive of all actuactors)
MDL655023 ** <0> Rubber Actuator
MDL655022 ** <9> Rubber Actuator
MDL655021 ** <8> Rubber Actuator
MDL655020 ** <7> Rubber Actuator
MDL655019 ** <6> Rubber Actuator
MDL655018 ** <5> Rubber Actuator
MDL655017 ** <4> Rubber Actuator
MDL655016 ** <3> Rubber Actuator
MDL655015 ** <2> Rubber Actuator
MDL655014 ** <1> Rubber Actuator
MDL345013 ** Trapezoidal Grey Rubber Actuator
MDL345011 ** Circular Grey Rubber Actuator
MDL345024 ** Rectan ular Black Actuator
MDL345025 ** Pitch Bender Rubber Actuator
MDL345026 ** Square Dark Grey Rubber Actuator
MDL345027 ** Square Li ht Grey Rubber Actuator
MDL345028 ** Square Red Rubber Actuator
MDL345029 ** Square Yellow Rubber Actuator
MDL345030 ** Small Circular Grey Rubber Actuator
MDL345031 ** "TEMPO" Rubber Actuator
MDL345001 * Rubber Contact Strip (step=14mm)
MDL345000 * Sin le Rubber Contact for Controls
MDL655044 * Front Panel
MDL655045 * Lcd Display Screen
MDL345020 * Power On/Off Actuator
MDL115000 * On/Off Power Switch
MDL735014 * Volume Board
MDL345017 * Volume Knob
MDL765006 GK350 Cpu & Sound Generator Board (Pcb# 31-1523-4)
The service support is made only by replacement the entire Cpu Board
unless for the ICs listed below:
MDL105001 * CA8898 - DSP2000 (A401 ASIC for SAM9733/SING98)
MDL105002 * CA9888 Sin 98 or SAM9733 DREAM - Cpu & Dsp
MDL105003 * KS88P4504 - OTP Microcontroller for Keyboard & Disk Drive
MDL104001 * MX29F1610 or 16Mbit Rom -H GK330/350
MDL104003 * MX29F1610 or 16Mbit Rom -L GK350
100591 * GM82C765B Floppy Disk Controller
104020 * KM62256CLG SOP 256Kbit SRam Ta=55nS
103033 * TDA1305T SOT Dual Bitstream DA Converter
103031 * 74HC00D SOIC Quad 2-In Nand Gate
103030 * 74HC32D SOIC Quad 2-In Or Gate
103010 * 74HC04D SOIC Hex Inverter
103003 * 74HC374DW SOIC Octal D-Type Flip-Flop
MDL115001 * Lithium Battery type CR2032 3V-200mAh
010704 * 16MHz Quartz Resonator
MDL735017 Power Amplifier & Suppl Board
MDL100000 * AN7148 Dual Power Amplifier
MDL145000 * 5 Poles Din Socket
140217 * Jack Stereo Slim Horizontal Socket
140207 * Jack Horizontal Female Socket
140211 * Dc Horizontal Male Socket
100602 * 74HC04 Hex Inverter
090183 * BC550 TO92 Npn Transistor (9014C equivalent)
100035 * 6N138 Optocoupler
100059 * 7805 +5V 1A Volta e Re ulator
080187 * 1N5403 3A 300V Rect. Diode (1N5401 equivalent)
MDL725003 61Notes D namic Ke board
MDL765004 * Ke board Interface Board (Pcb#31-1235-11)
MDL100002 ** KS88C0504 Keyboard Interface CPU
MDL815006 * Right Contacts Board (30Notes) (Pcb#31-1135-9)
MDL815007 * Left Contacts Board (31Notes) (Pcb#31-1136-9)
MDL345009 * 1 Octave Sharp Keys
MDL345008 * D-F-A Natural Keys
MDL345007 * C-E-G-B Natural Keys
MDL345006 * 13 Contacts Grey Strip
MDL345005 * 13 Contacts White Strip
MDL345004 * Last C Key
MDL655043 Top Chassis
MDL665000 * Ri ht Speaker Grid
MDL665001 * Left Speaker Grid
MDL655041 Bottom Chassis (Batteries Slot included)
MDL345022 Batteries Cover
MDL225000 Low Ran e Speaker
MDL225001 Hi h Ran e Speaker
110400 * 3.5" Floppy Disk Drive
Note:
Each spare part is sin le quantity unless otherwise specified.
Asterisk prefix explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed first level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk = ............
Any request for not above mentioned part must encompass specific description
includin :
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
