Gefen EXT-3G-HD-C Manuel utilisateur

Audio

Embedder

3GSDI

EXT-3G-HD-C

User Manual

3GSDI to HDMI

Converter

Release A1

*Preferred

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this unit near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this unit near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the unit.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this unit, never handle or touch

this unit or power cord if your hands are wet or damp. Do not expose this

unit to rain or moisture.

13. Unplug this unit during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when

the unit has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the unit,

the unit has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this unit and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

For the latest warranty coverage information, refer to the Warranty and Return Policy under

the Support section of the Gefen Web site at www.gefen.com.

iii

Warranty Information

Technical Support

(818) 772-9100 (800) 545-6900

8:00 AM to 5:00 PM Monday - Friday, Pacic Time

Fax

(818) 772-9120

[email protected]

Web

http://www.gefen.com

Mailing Address

Gefen, LLC

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

Product Registration

Contacting Gefen Technical Support

• Always make sure that the 3GSDI to HDMI Scaler/Converter is running the latest

rmware. The Gefen Syner-G Software Suite is a free downloadable application from

Gefen that provides automatic download and installation of rmware upgrades for this

product.

Download the application here: http://www.gefen.com/support/download.jsp

• SDI audio will be embedded in the HDMI signal.

3GSDI to HDMI Converter is a trademark of Gefen, LLC.

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation

without prior written notice.

Operating Notes

This product uses UL or CE listed power supplies.

Features and Packing List

Features

• Converts SDI to HDMI

• Input resolutions up to 1080p60

• Output resolutions up to 1080p Full HD

• HDMI (YCbCr 4:4:4) or DVI (RGB 4:4:4) output modes

• Supports 3G-SDI Levels A and B, Single-Link HD-SDI, and SD-SDI

• Supports up to 10 bit color on input and output

• Up to LPCM 7.1 audio support

• Field congurable via DIP switch settings

• Mini USB port for use with Gefen Syner-G™ for in-eld rmware updates

• Wide power supply operating range (6V to 24V DC)

• Locking power supply connector

• 1/4-20 industry-standard camera gear attachment thread on bottom

• Surface-mountable using the included detachable bracket

Packing List

The 3GSDI to HDMI Converter ships with the items listed below. If any of these items are

not present in the box when you rst open it, immediately contact your dealer or Gefen.

• 1 x 3GSDI to HDMI Converter

• 1 x Surface Mounting Bracket

• 1 x 12V Power Supply

• 1 x Quick-Start Guide

viii

Table of Contents

1 Getting Started

Introduction............................................................................................................ 2

Installation ............................................................................................................. 4

Connection Instructions................................................................................. 4

Sample Wiring Diagram ................................................................................ 4

2 Basic Operation

DIP Switches......................................................................................................... 8

3 Appendix

Mounting Instructions .......................................................................................... 12

Flat Surface................................................................................................. 12

Camera Mount ............................................................................................ 13

Specications ...................................................................................................... 14

Index.................................................................................................................... 15
