Gefen EXT-DVIKVM-ELR Manuel utilisateur

DVIKVM

Extra Long Range

Extender

Over One CAT5

EXT-DVIKVM-ELR

User Manual

www.gefen.com

ASKING FOR ASSISTANCE

Rev A1

29.81

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen LLC

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen LLC reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

DVIKVM Extra Long Range Extender Over One CAT5

is a trademark of Gefen LLC

All trademarks are the property of their respective owners.

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Sender Unit Layout

5 Sender Unit Descriptions

6 Receiver Unit Layout

7 Receiver Unit Descriptions

8 Connecting the DVIKVM Extra Long Range Extender Over One CAT5

8 Wiring Diagram

9 DIP Switch Conﬁguration

11 Network Cable Wiring Diagram

12 Rack Tray Installation

13 Troubleshooting

14 Glossary

21 Speciﬁcations

22 Warranty

Congratulations on your purchase of the Gefen DVIKVM Extra Long Range Ex-

tender Over One CAT5. Your complete satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to install and simple to operate.

The Gefen DVIKVM Extra Long Range Extender Over One CAT5

The DVIKVM Extra Long Range Extender Over One CAT5 extends any DVI and

USB source to a monitor, touch screen display, or other digital signage applica-

tion over a distance up to 330 feet (100 meters) using one Cat-5 cable. USB 2.0

data rates up to 100 Mbps are supported in addition to backward-compatibility

with USB 1.1. The Receiver Unit allows the connections of up to three (3) USB

devices, providing access to printers, scanners, cameras, external storage me-

dia, digital signage, and automated control systems. This product uses Gefen

ELR technology, allowing DVI and USB signals to travel along the same Cat-5

cable, reducing cabling costs and providing easier installation.

How It Works

Place the DVIKVM Extra Long Range Extender Over One CAT5 Sender Unit next

to the DVI source. Use the included DVI cable to connect the computer or other

DVI source to the Sender Unit. Use the supplied USB cable to connect the USB

host (source) device to the USB port on the Sender Unit. Connect the Receiver

Unit to the monitor or digital signage display with a DVI cable. Connect the USB

devices to the Receiver Unit. Use one Cat-5 cable, up to 330 feet (100 meters),

to connect the Sender Unit to the Receiver Unit. Connect the included locking

power supplies to the Sender Unit and Receiver Unit, and then connect both

power cords to available electrical outlets.

INTRODUCTION

OPERATION NOTES

PLEASE READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE DVIKVM EXTRA LONG RANGE EXTENDER OVER

ONE CAT5

• Cat-5 or Cat-6 cables should not exceed 330 feet (100 meters).

• Shielded (STP) Cat-5 or Cat-6 is recommended. However, un-shielded

(UTP) Cat-5 or Cat-6 is acceptable.

NOTE: The shielded cable has an advantage by providing immunity to

Electromagnetic Interference (EMI), cell phones and A/C motors.

• The Gefen DVIKVM Extra Long Range Extender Over One CAT5 features

the ability to generate compatible EDID and Hot Plug signals when working

with different brands of source devices and monitors.

• This product supports HDCP with HDMI sources.

• Dual-link resolutions are not supported.

FEATURES

Features

• Supports DVI resolutions up to 1920x1200 @ 60 Hz or 1080p at 330 feet

(100 meters)

• Extends USB 2.0 up to 330 feet (100 meters)

• Digital signal transmission over Cat-5 cable for zero signal loss

• Supports USB 2.0

• Backward-compatible with USB 1.1 devices

• Field Upgradeable via USB mini-jack

• Works with PC and Mac computers

• Locking Power Supplies

• Rack-mountable

Applications

• Ideal for digital signage applications

• Extension of KVM workstations

Package Includes

(1) Gefen DVIKVM Extra Long Range Extender Over One CAT5 - Sender Unit

(1) Gefen DVIKVM Extra Long Range Extender Over One CAT5 - Receiver Unit

(1) 6 ft. DVI Cable (M-M)

(1) 6 ft. USB cable (A-B)

(2) 5V DC Locking Power Supplies

(1) Set of rack ears

(1) User Manual

SENDER UNIT LAYOUT

Back

Front

2 3 41

6 7 8 95

SENDER UNIT DESCRIPTIONS

1 Power Indicator

This LED will turn bright blue once the included 5V DC locking power supply

has been properly connected to the unit and the locking power supply has been

connected to an available electrical outlet.

2 Link Indicator

This LED glows bright blue when the Sender Unit and Receiver Unit are

connected using Cat-5 / Cat-6 cable.

3 USB Indicator

This LED glows bright blue when a USB source is connected to the Sender Unt.

4 DVI Indicator

This LED ﬂashes on (bright blue) and off when a DVI video source is connected

to the Sender Unit. The Sender Unit and Receiver Unit must also be connected

using a Cat-5 / Cat-6 cable.

5 Service Port

Mini-USB service port used for upgrading the ﬁrmware.

6 Link

Connects the Sender Unit to the Receiver Unit using Cat-5 / Cat-6 cable.

7 DVI In

Connect a DVI cable from the computer to this DVI-I connector.

8 USB In

Connects the Sender Unit to the network using an Ethernet cable.

9 5 V DC Locking Power Connector

Connect the included 5 V DC locking power supply to this connector.

RECEIVER UNIT LAYOUT

Back

Front

2 3 41

5 6 7 8 9

RECEIVER UNIT DESCRIPTIONS

1 Power Indicator

This LED will turn bright blue once the included 5V DC locking power supply

has been properly connected to the unit and the locking power supply has been

connected to an available electrical outlet.

2 Link Indicator

This LED glows bright blue when the Sender Unit and Receiver Unit are

connected using Cat-5 / Cat-6 cable.

3 USB Indicator

This LED glows bright blue when a USB source is connected to the Receiver

Unt.

4 DVI Indicator

This LED ﬂashes on (bright blue) and off when a DVI display is connected to

the Receiver Unit. The Sender Unit and Receiver Unit must also be connected

using a Cat-5 / Cat-6 cable.

5 Service Port

Mini-USB service port used for upgrading the ﬁrmware.

6 Link

Connects the Receiver Unit to the Sender Unit using Cat-5 / Cat-6 cable.

7 DVI Out

Connect a DVI display to this DVI-I connector.

8 USB Input Ports (1 - 3)

Connect USB devices to these ports.

9 5 V DC Locking Power Connector

Connect the included 5 V DC locking power supply to this connector.
