GE 175D1807P211 Manuel utilisateur

WPSF4170

GE Appliances

Owner’s Manual

Part No. 175D1807P211 Pub. No. 49-9946-1

9-97 CG

Washers

Congratulations!

You Are Now Part of the GE Family.

Welcome to the GE family.

We’re proud of our quality

products and we are

committed to providing

dependable service. You’ll

see it in this easy-to-use

Owner’s Manual and you’ll

hear it in the friendly voices

of our customer service

department.

Best of all, you’ll experience

these values each time you

do the laundry. That’s

important, because your

new washer will be part of

your family for many years.

And we hope you will be

part of ours for a long time

to come.

We thank you for buying

GE. We appreciate your

purchase, and hope you

will continue to rely on us

whenever you need quality

appliances for your home.

Important!

Staple sales slip or cancelled

check here.

Proof of the original purchase date

is needed to obtain service under

the warranty.

Write the model and serial

numbers here.

#You can find them behind the top edge

of the control panel.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
Safety Information . . . . . . .4–7
Operating Instructions
Control Panels . . . . . . . . . . . . . .8
Control Settings . . . . . . . . . . .8, 9
Washer Features . . . . . . . .10–12
Loading and Using
the Washer . . . . . . . . . . . .12–14
Troubleshooting Tips
Before You
Call For Service . . . . . . . . .15–19
Customer Service
Warranty . . . . . . . . . . . . . . . . .23
Service Telephone
Numbers . . . . . . . . . .Back Cover
3
GE&You,
AService Partnership.
Inside you will find many
helpful hints on how to use and
maintain your washer properly.
Just a little preventive care on
your part can save you a great
deal of time and money over the
life of your washer.
Read this Manual
Ask any GEappliance owner and they will
tell you we stand behind our products with
unmatched quality service. However, did
you know that most questions result from
simple problems that you can easily fix
yourself in just a few minutes? This
Owner’s Manual can tell you how.
You’ll find many answers to
common problems here.
If you review our chart of
Troubleshooting Tips first, you may
not need to call for service at all.
Review the Section on
Troubleshooting Tips
If you do need service, you can
relax knowing help is only a
phone call away. A list of toll-free
customer service numbers is
included in the back section.
Or call you can always call the
GE Answer Center®at
800.626.2000, 24 hours a day,
7 days a week.
If You Need Service

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

For your safety, the information in this manual must be

followed to minimize the risk of fire or explosion, electric

shock, or to prevent property damage, personal injury, or

loss of life.

Under certain conditions hydrogen gas may be produced

in a water heater that has not been used for two weeks

or more. Hydrogen gas can be explosive under these

circumstances.

If the hot water has not been used for two weeks or more, prevent

the possibility of damage or injury by turning on all hot water

faucets and allowing them to run for several minutes. Do this

before using any electrical appliance which is connected to the

hot water system. This simple procedure will allow any built-up

hydrogen gas to escape. Since the gas is flammable, do not smoke

or use an open flame or appliance during this process.

WATER HEATER SAFETY

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

This washer must be properly installed and located in

accordance with the Installation Instructions before it is

used. If you did not receive an Installation Instructions

sheet, you can receive one by calling us toll-free at the

GE Answer Center

, 800.626.2000.

PROPER INSTALLATION

■

Install or store where it will not

be exposed to temperatures

below freezing or exposed to

the weather.

■Properly ground washer to

conform with all governing

codes and ordinances. Follow

details in Installation

Instructions.

■Keep the area underneath

and around your appliances

free of combustible materials

such as lint, paper, rags,

chemicals, etc.

■Close supervision is necessary

if this appliance is used by or

near children. Do not allow

children to play on, with, or

inside this or any other

appliance.

YOUR LAUNDRY AREA

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INSTRUCTIONS.

READ ALL INFORMATION BEFORE USING.

Use this appliance only for its intended purpose as

described in this Owner’s Manual.

■ Never reach into washer while

it is moving. Wait until the

machine has completely

stopped before opening

the lid.

■Do not mix chlorine bleach

with ammonia or acids such

as vinegar and/or rust

remover. Mixing different

chemicals can produce a toxic

gas which may cause death.

■ Do not wash or dry articles

that have been cleaned in,

washed in, soaked in, or

spotted with combustible or

explosive substances (such as

wax, oil, paint, gasoline,

degreasers, dry-cleaning

solvents, kerosene, etc.)

which may ignite or explode.

Do not add these substances

to the wash water. Do not use

or place these substances

around your washer or dryer

during operation.

■ The laundry process can

reduce the flame retardancy

of fabrics. To avoid such a

result, carefully follow the

garment manufacturer’s

wash and care instructions.

■ To minimize the possibility

of electric shock, unplug this

appliance from the power

supply or disconnect the

washer at the household

distribution panel by

removing the fuse or

switching off the circuit

breaker before attempting

any maintenance or cleaning.

NOTE:

Turning the Cycle

Selector knob to an off

position does

NOT

disconnect

the appliance from the

power supply.

■ Never attempt to operate this

appliance if it is damaged,

malfunctioning, partially

disassembled, or has missing

or broken parts, including a

damaged cord or plug.

WHEN USING THE WASHER

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

■ Turn off water faucets to

relieve pressure on hoses and

valves and to minimize

leakage if a break or rupture

should occur. Check the

condition of the fill hoses;

they may need replacement

after 5 years.

■ Before discarding a washer,

or removing it from service,

remove the washer lid to

prevent children from

hiding inside.

■ Do not attempt to repair or

replace any part of this

appliance unless specifically

recommended in this

Owner’s Manual, or in

published user-repair

instructions that you

understand and have the

skills to carry out.

■ Do not tamper with controls.

WHEN NOT IN USE

REMEMBER…

Your continued health and safety are important to us.

Please read and follow this Safety Information carefully.

We want you to remain a happy and healthy part of our

GE family.

SAVE THESE INSTRUCTIONS

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the washer control panel.

You can locate your model number behind the top edge of the control panel.

KNITS

PREWASH SPOT SOAK

60 MIN

AUTO SOAK

30 MIN

AUTO SOAK

HEAVY

EXTRA

HEAVY

NORMAL

LIGHT SOIL

PERMANENT PRESS

COTTONS

LOAD SIZE

SensorWash

SUPER

VARIABLE

LARGE

MEDIUM SMALL

RESET

EXTRA

SMALL

EASY CARE

GENTLEWASH

SIGNAL

OPTIONS

HOT

COLD WARM

COLD EXTENDED

SPIN EXTRA

RINSE

FABRIC CARE

COLD

COLD RESET

OPTIONS

WARM

SOAK/WASH

COTTON

WHITES

WASH

RINSE

OFF ON

COTTON

COLORS

EASY

CARE GENTLE

WASH GENTLE

WASH

WRINKLE FREE COTTON

NORMAL

FAST

GENTLE

SLOW

GENTLE

SLOW

WOOLENS

DELICATES

123

Control Settings

Load Size

The water level should just cover the clothes. Adjust the

load size accordingly. Loosely load clothes no higher than

the top row of holes in the washer tub.

Fabric Care

Select the water temperature for the wash and rinse cycles.

Always follow fabric manufacturer’s care label or

instructions when laundering. Follow the water

temperature guide on washer lid.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Wash Cycle

The wash cycle controls the length of the washing process.

The chart below will help you match the wash cycle setting

with your clothing.

COTTONS For heavy to lightly soiled cottons, household linens,

work and play clothes.

PERMANENT PRESS For easy care and wrinkle-resistant items.

KNITS Specially designed for normal soil knits.

GENTLEWASH

For lingerie and special-care fabrics with light soils.

Select

GENTLEWASH

for load size and for cycle.

Provides periods of agitation and soak during wash

and rinse.

PREWASH

For heavily soiled clothes or for clothes with a care label

that recommends prewashing before wearing.

AUTO SOAK For heavily soiled clothes. Begins with a brief agitation,

soaks for a specified period of time, then moves

through the rest of the cycle automatically.

SensorWash

The SensorWash

senses the incoming water temperature

and adjusts the fill water to obtain a more precise

temperature.

For example, in a Cold Wash selection, some

warm water may be added to reach a temperature needed

to dissolve detergent.

Often, detergents are not completely

dissolved in very cold water, especially in cooler climates.

The SensorWash switch is located on the top of the

control panel. Turning the switch to

will activate this

option.

NOTE:

The SensorWash will not adjust the fill on

WARM

WASH

unless the washer lid is closed.

Be sure to start the

washer after the lid is closed.

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the washer features.

If the SIGNAL option is selected,

a signal will sound just

before the end of the cycle. This reminds you to remove

the clothes to avoid excess wrinkling before drying. If

you selected

EXTRA RINSE

the signal will sound at the

end of the cycle and at the end of the

EXTRA RINSE.

The EXTENDED SPIN option

is recommended for washable

woolens and sweaters. It will extend the spin without

stretching the knit.

When you use extra detergent or bleach to clean heavily

soiled clothes, you may want to use the

EXTRA RINSE

option. This option provides a second deep cold rinse in

the

COTTONS REGULAR

and

PERMANENT PRESS

cycles.

Select

EXTRA RINSE.

The washer will pause for a few

minutes before the

EXTRA RINSE

begins.

Selecting RESET OPTIONS

cancels all options that have

been selected.

SIGNAL

OPTIONS

EXTENDED

SPIN EXTRA

RINSE RESET

OPTIONS

Liquid Bleach Dispenser

The dispenser dilutes liquid chlorine bleach before it

reaches into your wash load.

Check clothing care labels for special instructions.

Measure liquid bleach carefully, following

instructions on the bottle.

Before starting the washer, pour measured amount

of bleach directly into bleach dispenser. Avoid

splashing or over-filling dispenser. If you prefer to

use powdered bleach, add it into the wash basket

with your detergent.

Never pour undiluted liquid chlorine bleach directly onto clothes or

into the wash basket.

Do not pour powdered bleach into bleach dispenser.

Do not mix chlorine bleach with ammonia or acids such as vinegar

and/or rust remover. Mixing can produce a toxic gas which may

cause death.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GE Rondelle

GE WLW1500R Instructions d'installation

GE WWA8480G Instructions d'installation

GE WWA8314V Instructions d'installation

GE GWSE5200 Manuel utilisateur

GE WCVH6260HWW Manuel

GE WCRD2050J Manuel utilisateur

GE WMCD2050HWC Manuel

GE WPSQ4160 Manuel utilisateur

GE GFWN1100LWW Instructions de montage

GE WPSE7003A Manuel utilisateur

GE Profile WPDH8900 Instructions originales

GE GTWP2005MCC Manuel

GE GFWH1400DWW Instructions originales

GE PROFILE WASHERS WPRE6100 Manuel utilisateur

GE Appliances Profile WASE4220 Manuel utilisateur

GE WWA8320G Instructions d'installation

GE Appliances Profile PFWS4605 Manuel utilisateur

GE Profile WPRB9250 Manuel utilisateur

GE Appliances Profile WASE4220 Manuel utilisateur

GE WWA6800S Manuel utilisateur

GE WBSR1060 Manuel utilisateur

GE Appliances Profile WASE4220 Manuel utilisateur

GE GBVH5140 Instructions originales

GE WW3000S Instructions d'installation

Manuels Rondelle populaires d'autres marques

Tricity Bendix

Tricity Bendix AW 1000 W Guide produit

Panasonic

Panasonic NA-F60L5WRB Manuel utilisateur

Electrolux

Electrolux EWF1284EDW Manuel utilisateur

Bosch

Bosch WAN2829BSN Manuel utilisateur

LG TV2516DV3B Manuel utilisateur

LG TH2517DSAV Manuel utilisateur

VESTEL

VESTEL CMH-XL 7510 TE Manuel utilisateur

AEG

AEG 74335 Manuel d'utilisation

Johnson

Johnson JWF721A Manuel utilisateur

Beko

Beko WTE7604XLW0 Manuel utilisateur

Danby

Danby DTT100A1WDB Instructions de montage

Amica

Amica WA 14 Ex Manuel utilisateur

Daewoo

Daewoo DWD-F1222 Manuel utilisateur

Bosch

Bosch WAS28461AU Manuel utilisateur

Miele

Miele PW 6080 Vario Manuel utilisateur

Finlux

Finlux FLX108CF220 Manuel utilisateur

Whirlpool

Whirlpool 3LBR5132AN0 Manuel utilisateur

Beko

Beko WKB 51231 PTMA Manuel utilisateur
