UVD-IP-EVRDNR(-P)
Camera User Manual
P/N 1069889 • REV 3.0 • ISS 08JUL10
Copyright © 2010 UTC Fire & Security. All rights reserved.
Trademarks and
patents
The UltraView name and logo are trademarks of
UTC Fire & Security.
GE and the GE monogram are trademarks of the
General Electric Company and are under license
to UTC Fire & Security, 9 Farm Springs Road,
Farmington, CT 06034-4065, USA
Other trade names used in this document may
be trademarks or registered trademarks of the
manufacturers or vendors of the respective
products.
Manufacturer Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification
FCC compliance Class A: This equipment has been tested and
found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment in
a residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
European Union
directives
1999/5/EC (R&TTE directive): Hereby, UTC Fire
& Security declares that this device is in
compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more
information see: www.recyclethis.info.
Contact
information
For contact information see our Web site:
www.utcfireandsecurity.com.
UVD-IP-EVRDNR(-P) Camera User Manual EN 5
Introduction 6
Product description 6
Features 6
User guidelines 7
Package contents 7
Installation 8
Viewing the camera via a digital (IP) connection 8
Software requirements 8
Connecting analog cables 10
Installing the camera 10
Angle adjustment 10
Zoom and focus adjustment 11
Connecting an analog monitor to set camera functions 12
Setting camera functions 12
White balance (WB) 12
Backlight compensation (BLC) 13
AI/AE exposure 13
Day/Night 13
Mirror 13
Flickerless control 13
Contacting Technical Support 14
EN 6 UVD-IP-EVRDNR(-P) Camera User Manual
Introduction
This user manual provides basic information on setting up and using
the UVD-IP-EVRDNR(-P) camera.
Product description
The UVD-IP-EVRDNR(-P) color video camera uses a digital signal
processor (DSP) to process video signals. The video camera includes
a microcontroller to provide high-quality images with high-color
reproduction and sharp pictures
Features
Camera features include:
• H.264-SVC video compression with multistream capability.
• Super HAD (hole accumulated diode) technology with 470,000
PAL (410,000 pixels NTSC).
• Use of LSI (large scale integration) digital processors to produce
540 lines of horizontal resolution.
• High-resolution picture production using digital signal processors
for horizontal and vertical aperture enhancement.
• Smart digital automatic BLC (back light control).
• Advanced autoexposure system to optimize the amount of light to
the imager.
• Internal or line lock external synchronization.
• Long life and high reliability.
• DIP switch control of camera settings.
• Signal-to-noise ratio better than 48 dB.
• Power over Ethernet (PoE) or Isolated switching power 12 VDC or
24 VAC.
UVD-IP-EVRDNR(-P) Camera User Manual EN 7
User guidelines
Use the following guidelines:
• Take appropriate safety precautions while completing
programming after installation.
• Always use a proper PoE switch or a 12 VDC or 24 VAC UL listed
Class 2 power supply to power the camera.
• Do not use the camera outside the temperature range
specifications: -30 to +50°C (-22 to +122°F)
• If the light source where the camera is installed experiences rapid,
wide-variations in lighting, the camera may not operate as
intended.
WARNING: To reduce the risk of fire or electronic shock, do not
expose the camera to rain or moisture and do not remove the cover or
back.
Package contents
The UVD-IP-EVRDNR camera is shipped with the following items:
• The camera assembly
• 1 channel passive video transceiver
• AC power wiring harness
• Mounting screws, wall anchors, and hex key
• 150 mm DC jack to terminal adapter
Use the video output BNC and power jack for normal system
operation.
EN 8 UVD-IP-EVRDNR(-P) Camera User Manual
Figure 1: Camera assembly
Camera body
RJ45 Ethernet/PoE input
24 VAC / 12 VDC input
Video output (BNC)
Installation
To install the camera you will need to prepare the mounting surface,
make cable connections, and mount the camera.
Viewing the camera via a digital (IP) connection
You can connect the IP camera to a network and view the images
through a browser. To view via a Network Video Recorder or similar
digital video system, please refer to the documentation associated with
that system.
Software requirements
The UVD-IP camera requires:
Microsoft Internet Explorer
UVD-IP-EVRDNR(-P) Camera User Manual EN 9
A VLC player ActiveX plug-in is required to play video when
Internet Explorer is used to monitor the camera.
Figure 2: ActiveX plug-in option
To configure the camera:
1. Configure the UVD-IP camera with a default IP address: 10.1.2.11
2. Configure your host PC/laptop within the same subnet, ex:
10.1.2.10
3. Connect the URL http://10.1.2.11 with Internet Explorer.
4. Select the “Live” menu to view live video.
5. Enter the following username and password to access the
Maintenance menu.
Login:
admin
Password:
admin
The IP address of the camera can be changed from the
Maintenance menu. Reboot the camera for the changes to take
effect.
EN 10 UVD-IP-EVRDNR(-P) Camera User Manual
Connecting analog cables
To connect the cables:
1. Connect a coaxial cable from the camera’s BNC connector to a
CCTV monitor or video recording device.
2. Connect a PoE switch, a 12 VDC or 24 VAC power supply to the
power input. Do not connect both the PoE connection and DC or
AC connection at the same time. The label on the camera gives
the following information:
Red cable. Power in.
Black cable. Power in.
White cable. Video out.
Black cable. Video ground.
Note: For 24 VAC or 12 VDC, Black or Red may be used for ground.
Installing the camera
To mount the camera, attach the camera to the mounting surface using
the appropriate fasteners.
Angle adjustment
To adjust the horizontal angle of the platform up to 180 degrees, turn
the platform (Figure 3 on page 11).
To adjust the horizontal angle of the rotor up to 350 degrees, turn the
rotor on the platform (Figure 3 on page 11).
To adjust the vertical angle of the platform up to 90 degrees, turn the
platform (Figure 3 on page 11).
