GE WMRO4GAV Instructions originales

197D5616P005 49-60561 03-08 JR

ge.com

Write the model and serial numbers here:

Model # __________________________

Serial # __________________________

Find these numbers on a label inside

the refrigerator on the side wall.

Refrigerators

WMRO4GAV

Owner’s Manual

& Installation

Instructions

Safety Information . . . . . . . . .2, 3

Operating Instructions

Care and Cleaning . . . . . . . .6, 7

Control Settings . . . . . . . . . . . . .4

Refrigerator Features . . . . . . . .5

Installation Instructions . . .8–10

Troubleshooting Tips . . . .13, 14

Consumer Support

Consumer Support . .Back Cover

Warranty . . . . . . . . . . . . . . . . . .15

ATTENTION:

Defrosting—Do not use sharp, pointed

objects to remove frost or ice from

surfaces of the refrigerator and/or

freezer compartment. Doing so could

puncture the cooling coil, causing the

unit to lose its ability to maintain cold

temperatures and voiding the warranty.

See the

Care and Cleaning

section for

instructions on defrosting the

refrigerator and/or freezer

compartment.

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Safety Instructions

Operating InstructionsTroubleshooting Tips

Consumer Support Installation Instructions

DANGER! RISK OF CHILD ENTRAPMENT

Use this appliance only for its intended purpose as described

in this Owner’s Manual.

WARNING!

■This refrigerator must be

properly installed and located in

accordance with the Installation

Instructions before it is used.

■Do not allow children to climb,

stand or hang on the shelves

in the refrigerator. They could

damage the refrigerator and

seriously injure themselves.

■Do not store or use gasoline or

other flammable vapors and

liquids in the vicinity of this or

any other appliance.

■Keep fingers out of the “pinch

point” areas; clearances between

the doors and cabinet are

necessarily small. Be careful

closing doors when children

are in the area.

■Unplug the refrigerator before

cleaning and making repairs.

■GE does not support any

servicing of the refrigerator.

■Turning the temperature

control dial to the

O (off)

position stops cooling but does

not shut off power to the

refrigerator.

When using electrical appliances, basic safety precautions

should be followed, including the following:

SAFETY PRECAUTIONS

Child entrapment and

suffocation are not problems of

the past. Junked or abandoned

refrigerators are still dangerous…

even if they will sit for “just a few

days.” If you are getting rid of

your old refrigerator, please

follow the instructions below to

help prevent accidents.

Before You Throw Away Your

Old Refrigerator or Freezer:

■Take off the doors.

■Leave the shelves in place so

that children may not easily

climb inside.

Refrigerants

All refrigeration products contain

refrigerants, which under federal

law must be removed prior to

product disposal. If you are

getting rid of an old refrigeration

product, check with the company

handling the disposal about

what to do.

PROPER DISPOSAL OF THE REFRIGERATOR

ge.com

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions

USE OF EXTENSION CORDS

Because of potential safety hazards under certain conditions,

we strongly recommend against the use of an extension cord.

However, if you must use an extension cord, it is absolutely necessary

that it be a UL-listed, 3-wire grounding type appliance extension cord

having a grounding type plug and outlet and that the electrical rating

of the cord be 15 amperes (minimum) and 120 volts.

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or remove the third

(ground) prong from the power cord. For personal safety,

this appliance must be properly grounded.

The power cord of this appliance

is equipped with a 3-prong

(grounding) plug which

mates with a standard 3-prong

(grounding) wall outlet to

minimize the possibility of electric

shock hazard from this appliance.

Have the wall outlet and circuit

checked by a qualified electrician

to make sure the outlet is

properly grounded.

If you have only a standard

2-prong wall outlet, it is your

personal responsibility and

obligation to have it replaced

with a properly grounded

3-prong wall outlet.

The refrigerator should always be

plugged into its own individual

electrical outlet which has a

voltage rating that matches the

rating plate.

This provides the best

performance and also prevents

overloading house wiring circuits

which could cause a fire hazard

from overheated wires.

Never unplug your refrigerator

by pulling on the power cord.

Always grip plug firmly and pull

straight out from the outlet.

Repair or replace immediately all

power cords that have become

frayed or otherwise damaged.

Do not use a cord that shows

cracks or abrasion damage along

its length or at either end.

When moving the refrigerator

away from the wall, be careful

not to roll over or damage the

power cord.

About the control on the refrigerator.

Control Settings

The temperature control maintains the temperature in the

refrigerator.

is the warmest setting; higher numbers are colder

settings with

being the coldest setting. The typical setting is between

and

Allow 24 hours for the refrigerator to reach the desired temperature.

If you want a colder or warmer temperature, move the dial one setting

at a time. Moving the control to

stops cooling but does not turn off

the power to the refrigerator. Setting the control too high may cause

freezing in the refrigerator depending on the room temperature.

How To Test Temperatures

Use the milk test. Place a container of milk on a shelf and check it

a day later. If the milk is too warm or too cold, adjust the temperature

control.

After changing the control, allow 24 hours for the refrigerator to reach the

temperature you have set.

The control will look like the one above.

The arrow indicates the setting selected.

Safety Instructions

Operating InstructionsTroubleshooting Tips

Consumer Support Installation Instructions

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions

Shelves

To remove a shelf, lift up the back slightly and pull forward.

Some models have multi-position shelves that can be moved

to different levels.

Ice Tray Compartment

This compartment is designed for production of ice cubes and

short-term storage (a few days at most) of some commercially-

frozen foods when in contact with the evaporator (cold surface

in compartment.)

Door Shelves

Shelves on the door provide convenient storage for frequently

used items. Some models have doors that are deep enough to

store large bottles.

About the refrigerator features. ge.com

Safety Instructions

Operating InstructionsTroubleshooting Tips

Consumer Support Installation Instructions

Cleaning the Outside

Keep the outside clean.

Wipe with a clean cloth lightly dampened

with kitchen appliance wax or mild liquid dish detergent. Dry and

polish with a clean, soft cloth.

Do not wipe the refrigerator with a soiled dish cloth or wet towel. These may

leave a residue that can erode the paint. Do not use scouring pads, powdered

cleaners, bleach or cleaners containing bleach because these products can

scratch and weaken the paint finish.

Protect the paint finish.

The finish on the outside of the refrigerator

is a high quality, baked-on paint finish. With proper care, it will

stay new-looking and rust-free for years. Apply a coat of kitchen/

appliance wax when the refrigerator is new, and then at least

twice a year.

Cleaning the Inside

To help prevent odors,

leave an open box of baking soda in the

refrigerator.

Unplug the refrigerator before cleaning.

If this is not practical,

wring excess moisture out of sponge or cloth when cleaning

around the control.

Use warm water and baking soda solution–about a tablespoon

(15 ml) of baking soda to a quart (1 liter) of water. This both

cleans and neutralizes odors. Rinse and wipe dry.

Other parts of the refrigerator–including door gaskets, fruit

and vegetable drawers, and all plastic parts–can be cleaned

the same way.

Do not wash any plastic refrigerator parts in the dishwasher.

Care and cleaning of the refrigerator.

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions

Defrosting

(on manual defrost models with freezer area)

Defrost whenever frost on the wall of the ice tray compartment becomes

1/4

″

thick. Never use a sharp or metallic instrument to remove frost as

it may damage the cooling coils. (A punctured cooling coil will cause

serious problems and void the warranty.) We recommend using a plastic scraper.

Do not use any electrical device in defrosting your refrigerator.

To defrost:

■Remove foods and ice trays from the ice tray compartment.

■Set the temperature control dial at

O (off)

position.

■On models without a drip tray, place a pan beneath the ice tray

compartment to collect water.

Defrosting usually takes a few hours. To defrost faster, keep the

door open. Also, pouring warm (not hot) water on the frosted part

may speed defrosting.

Do not use boiling water—

it may damage

plastic parts.

After defrosting:

■Empty water from the drip tray or from the pan placed beneath

the ice tray compartment. Wash the tray or pan with warm water.

■Wipe the ice tray compartment with a damp cloth.

■Turn the temperature control to the desired setting and

return food and ice trays to the refrigerator.

NOTE: If ice buildup is very thick, it may keep the ice tray compartment door

from opening or closing completely. Don’t try to force it open; after defrosting,

the door will open and close easily.

ge.com

Preparing for Vacation

For long vacations or absences, remove food and unplug the

refrigerator. Move the control to the

O (off)

position, and clean the

interior with a baking soda solution of one tablespoon (15 ml) of

baking soda to one quart (1 liter) of water. Leave the door open.

Preparing to Move

Secure all loose items such as shelves and ice trays by taping them

securely in place to prevent damage.

Be sure the refrigerator stays in an upright position during moving.

Safety Instructions

Operating InstructionsTroubleshooting Tips

Consumer Support Installation Instructions

Preparing to install the refrigerator.

Read these instructions completely and carefully.

Turn counterclockwise to raise,

clockwise to lower.

Refrigerator Location

■Do not install the refrigerator where the temperature will go below

50°F (10°C) because it will not run often enough to maintain

proper temperatures.

■Install it on a floor strong enough to support it fully loaded.

■Do not install it closer than 5″(13 cm) next to a range.

■Do not install it in a recessed area.

■Do not build in the refrigerator.

Clearances

Allow the following clearances for ease of installation and proper

air circulation.

Sides

1/2″ (13 mm)

Top

2″(51 mm)

Back

2″(51 mm)*

*From the rear cabinet surface to the wall

Leveling Legs

Adjustable legs

at the front corners of the refrigerator

should be set so the refrigerator is firmly positioned on

the floor and the front is raised just enough that the

door closes easily when opened about halfway.

To adjust the leveling legs,

turn the legs

counterclockwise

to raise

the refrigerator,

clockwise to lower

it.

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions

ge.com

Door Reversal

1. Remove the two plug buttons on the top left of the cabinet.

2. Remove the plastic hinge cover by gently pressing forward

and lifting

by the back edge.

3. Remove the two screws from the top hinge.

4. Lift the top hinge up and off of the refrigerator.

5. Lift the door up and off of the bottom hinge.

6. Remove the hinge pin grommet from the bottom of the door

on the right side and insert into the left side.

7. Tilt the refrigerator cabinet backward.

8. Remove the hinge pin. Keep the two spacers for

reinstallation.

9. Remove the hinge leveling leg and the three screws to

remove the bottom hinge on the right side.

10. Remove the case leveling leg and the case screw from the

left side. Notice that the case leveling leg is different from

the hinge leveling leg.

11. Flip the bottom hinge plate to install on the left side of the

refrigerator.

12. Screw the three bottom hinge screws into place.

13. Put a spacer between the hinge pin and the bottom hinge

and screw the hinge pin into place.

14. Place the second spacer between the hinge pin and the

door. Position the door on the bottom hinge.

15. While the magnetic gasket holds the door in place, secure

the top hinge with two screws.

16. Replace the hinge cover on the top hinge.

17. Place the two plug buttons in the holes on the right side of

the refrigerator cabinet.

Preparing to install the refrigerator. (cont.)

Safety Instructions

Operating InstructionsTroubleshooting Tips

Consumer Support Installation Instructions

Leveling legs

Bottom

hinge

Spacer

Hinge cover

Plug buttons Hinge

Spacer

Screws

Hinge pin

grommet

Bottom

hinge pin

Table des matières

Autres manuels GE Réfrigérateur

GE TPG 24PF Manuel utilisateur

GE GTS18TCSABB and Mode d'emploi

GE PSDS5YGXSS - 24.6 cu. Ft. Refrirator Instructions de montage

GE TBX14SYBWW Instructions d'utilisation

GE Bottom-Freezer Built-In Refrigerator Manuel utilisateur

GE GMR04HASCS Instructions d'utilisation

GE PSDF5RGXBB - 24.6 cu. Ft. Refrirator Manuel utilisateur

GE GSL25IGXLS Manuel utilisateur

GE TFX24E Instructions d'installation

GE Monogram ZISS360NRSS Manuel utilisateur

GE HTH18EBDCC Instructions de montage

GE Profile PSHF6MGZ Manuel utilisateur

GE SIDE-BY-SIDE REFRIRATOR 22 Manuel de réparation

GE GTT16BBSHRCC and Mode d'emploi

GE RHM 15 Mode d'emploi

GE Profile PDSF5NBX Manuel

GE GMR04BANWW - Compact 4.3 Cubic Foot Total Capacity... Instructions de montage

GE GFSF2HCY Manuel

GE PZS23KPEBV Manuel

GE Profile PFSF5NFC Profile PFSF5NFCWW Manuel

GE Profile PFCF1NFY Manuel

GE Profile CustomStyle PSC23SHTSS Instructions d'utilisation

GE GSH25JFXBB - 25 cu. Ft. Refrigerator Manuel

GE TFXA27f Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
