GE Profile PSW26PSWSS Manuel utilisateur
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 7/07 210259
Overall
Dimensions
Height to top of hinge (in.) A 70-1/2*
Height to top of case (in.) B 68-3/4
Case depth without door (in.) C†28-1/2
Case depth less door handle (in.) D†32-3/4
Case depth with door handle (in.) E†35-3/8
Depth with fresh food door open 90° (in.) F†50-9/16
Width (in.) G
36
Width with door open 90° less door handle (in.) H 42-3/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
PSW26PSW
GE Profile™ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
Dimensions and Installation Information (in inches)
*When cap is removed: 69-1/4"
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 7/07 210259
To Remove Top Caps and Doors on PSW26PSW
Step 1: the refrigerator. Remove two screws, one on each side at the rear of the top
cap. Lift off and remove top cap.
Step 2: Open both doors. Remove one screw on each side of the toekick. Pull forward
to remove toekick.
Step 3: On the freezer door, disconnect water line coupler by pushing against the collar
on the left side. Disconnect wire harness.
Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the top hinge. Carefully
remove hinge while supporting door. Lift door up and off bottom hinge. Remove fresh
food door in the same manner. Note: Do not remove bottom hinges! Door alignment
will be difficult if bottom hinges are removed.
Step 5: Place refrigerator onto a hand truck, upright and against one side.
Move refrigerator to the installation location.
Step 6: Carefully lower doors onto bottom hinges. Be sure to route the tubing and
electrical connector through the bottom hinge. Reinstall top hinges.
Step 7: Place cap over the top of the refrigerator. Reinstall the original screws in the top
and back of the cap.
Step 8: Reconnect the wiring harness and waterline.
Water Line Coupler
1.
366-15A
Hinge Screws
Wire Harness
Toekick Screw
4.
3.
2.
PSW26PSW
GE Profile™ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
PSW26PSWSS
PSW23PSWSS
PSC25PSWSS
PSC23PSWSS
PSS26PSWSS
HOME
HELP
WATER
CRUSHED
LOCK CUBED
Hold3for Seconds
SELECTAMOUNT
BACK ENTER
NEWSETTING
SELECTTYPE
2CUPS
Features and Benefits
• Stainless-Wrapped Exterior with Hidden Hinge and Top Bevel - Provides a consistent appearance
with other appliances and includes contoured doors with a concealed hinge
• ClimateKeeper2™System - Keeps food garden fresh longer, while protecting ice from odor transfer,
with its unique dual-evaporator system
• Color LCD Controls with Touch Screen - Makes it easy to control all the functions of the refrigerator
with just a touch
• QuickFreeze Setting - Provides faster, fresher freezing to maintain the flavor and quality of meats
• Integrated Dispenser with LED Lighting, PreciseFill & UltraFlow100 - Illuminates the dispenser and
pours water in accurate increments or up to 100 ounces per minute
• Electronic Beverage Center - Keeps beverages and treats icy cold and easily accessible
• CustomCool™Technology - Chills in minutes, thaws in hours and keeps foods fresher, longer
• Slide 'n Store™Freezer Basket - Offers easy access and flexible storage
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™Setting - "Revs up" the refrigerator, cooling it quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space; It tilts down, providing easy access to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Adjustable ClearLook™Door Bins - Hold gallon-size containers with style and ease
• Adjustable Slide-Out, Spillproof Glass Shelves - Shelves slide out, spills stay put
• Model PSW26PSWSS - Stainless steel
PSW26PSW
GE Profile™ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
Specification Revised 7/07 210259
