GE Profile PGB910SEMSS Manuel

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

*Note: Dimension from the wall to the front

of the closed door handle is 29". Depth to

front edge of cooktop 25-1/4".

Electrical Rating: 120V, 60Hz, 9A

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47-3/16"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47-3/16"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

PGB910SEM

GE Profile™ 30" Free-Standing Gas Range

Specification Revised 7/07

230585

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop

to accommodate large cookware and deliver ideal results

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval burner,

for cooking multiple foods at once

• PowerBoil™ 16,000 BTU Burner - Delivers 16,000 BTUs of forceful heat

for rapid boiling

• QuickSet V Oven Controls - Feature an easy to use design that allows you to set

precise cooking temperatures

• Precise Simmer Burner - Delivers a low setting of 140 degrees, ideal for delicate

foods and sauces

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement of pans

between burners

• Dishwasher Safe Grates - Durable grate construction can be placed into the

dishwasher for easy cleaning and maintenance

• Model PGB910SEMSS - Stainless steel

PGB910SEM

LITE

FRONT

654

LOHI

LITE

REAR

654

LITE

RECISESIMMER

REAR

654

LITE

POWER

BOIL

FRONT

POWERBOIL

SETTINGINTENDEDFOR

USEWITHLARGER POTS

LITE

CENTER

654

VEN

ONTROLS

IME

ONTROLS

AKE

ARMING

RAWER

ROIL

12345

67890

LOMEDHI

ARMING

RAWER

ET/

ELF

LEAN

VEN

IGHT

ONTROL

OCKOUT

ELAY

TART

LOCK

ITCHEN

IMER

LEAR

OOKING

IME

TART

Specification Revised 7/07

230585

PGB910SEM

GE Profile™ 30" Free-Standing Gas Range
