Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Created 4/07 330591

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

JGBP86SEM

GE® 30" Free-Standing Self-Clean Gas Range

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

All 30" GE gas and electric range backguards

are 30-7/8" wide.*

Note: 30" ranges conform to U.L. requirements

for 0" spacing from adjacent walls below

countertops. To reduce possible scorching of

walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended,

high heat, no-load heating element operation.

*Except these models: JGBS07, JGBS04, JGBP90,

all GE Profile free-standing electric and gas

ranges

Fits most countertop backsplash applications.

Consult Use & Care Manual for detailed

installation instructions.

30-7/8"

Features and Benefits

• Self-CleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing

• Extra-LargeOvenCapacity-Providesalargeoveninterioridealforcookingmore

items at once

• DeepRecessedCooktop-Designedwitharecessedsurfacetohelpcontainspills

and make cleaning easy

• CenterOvalBurner-Addsafifthelementtothecenterofthecooktop,ideal

for griddle or odd-size cookware

• Non-StickGriddle-Offersaflatcookingsurface,placedoverthecenterovalburner,

for cooking multiple foods at once

• PowerBoil™16,000BTUBurner-Delivers16,000BTUsofforcefulheat

for rapid boiling

• QuickSetIVOvenControls-Featureaneasytousedesignwhichallowsyou

to set precise cooking temperatures

• ContinuousGrates-Provideaflat,sturdysurfaceallowingeasymovement

of pans between burners

• Dishwasher-SafeGrates-Featuredurableconstructionforworry-freeandeffortless

cleaning and maintenance

• SealedCooktopBurners-Eliminatethespacebetweentheburnersandthecooktop

to help contain spills and boil over liquids, ensuring easy cleanup

• TrueTemp™System-Deliversevenheatdistributionandmaximumovencontrol

• BigHearthWindow-Featuresanenhancedshapetoaddanelegantappearance

and make viewing trouble-free

• ModelJGBP86SEMSS-Stainlesssteel

JGBP86SEM

PRECISESIMMER HIGHOUTPUT

ime

ontrols

ven

ontrols

Start

CTStart

Time

ake

roil

Clean

Specification Created 4/07

JGBP86SEM

GE® 30" Free-Standing Self-Clean Gas Range

330591
