GE Appliances

Specification Created 7/01

JGBP35CEACC—GE Spectra™30" Free-Standing XL44™Gas Range

Dimensions (in inches) and Installation Information

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

30

46-1/2

28-1/4*

46-3/8

36±1/4

*Depth including handle

26-1/4"—Depth to front of closed oven door

25-1/4"—Depth to front top edge of cooktop

Optional Gas Range

Accessory Drip Pans for Sealed

and Standard Burner Models

(Available at additional cost)

To order these accessory drip pans,

call toll-free 800-848-7722

Optional Gas Range

Wok Accessory

(Available at additional cost)

JXWK—Wok accessory sits on

top of burner grate to hold a

round-bottom wok.

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before

installing, consult installation

instructions packed with product

for current dimensional data.

24

30

8

4

92

C

L2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common area

for gas outlet and electrical

outlet for GE free-standing gas

range models

For answers to your Monogram,

®GE Profile™or

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

CERTIFIED

GE Appliances

Specification Created 7/01

JGBP35CEACC—GE Spectra™30" Free-Standing XL44™Gas Range

PRECISESIMMERMAXIMUMOUTPUT

Features and Benefits

•Extra-Large 4.4 cu. ft. Capacity Self-Cleaning Oven

•One-Piece Upswept Porcelain-Enameled Cooktop

•Sealed Cooktop Burners

•(1) 12,000/1,000 BTU Maximum Output Burner

•(1) 5,000/600 BTU Simmer Burner

•(2) 9,500/850 BTU All-Purpose Sealed Burners

•TrueTemp™System

•SmartLogic™Electronic Controls

•QuickSet IV Oven Controls

•Medium Cast Removable Square Grates

•Porcelain-Enameled One-Piece Drip Pans

•Electronic Pilotless Ignition System

•Electronic Clock and Timer

•In-Oven Broiling with Extra-Large Broiler Pan with Grid

•2 Oven Racks / 6 Embossed Rack Positions

•Removable Frameless Glass Oven Door with Big View Window

•Designer-Style Handle

•Porcelain-Enameled Scratch-Resistant Backguard

•Easy Glide Storage Drawer

•Model JGBP35WEAWW–White on White

•Model JGBP35BEABB–Black on Black

•Model JGBP35AEAAA–Almond on Almond

•Model JGBP35CEACC–Bisque
