GE Appliances

JBS27SH – GE® 30" Free-Standing Electric Range

Dimensions (in inches) For all 30" Free-Standing Range

models with coil heating elements

26-1/4*

46-1/4

29-7/8

46-7/8

CENTER LINE

2-1/4

7-1/2

7-1/2

7

5

2-1/4

3-1/2

REAR

WALL

1/4†

†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires that new

construction (not existing) utilize a 4-conductor connection to an electric range.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because

terminals are not accessible after range installation. See shaded area in

drawing for location of electrical outlet box. Recommended outlet locations

allow range to be installed directly against wall.

Note: 30" Ranges conform to U.L. requirements for 0" spacing for adjacent

walls below countertops. Allow 1-1/2" spacing from the side of the range

to adjacent vertical walls above the cooktop surface.

Installation Information: Before installing, consult installation instructions

packed with product for current dimensional data.

26-1/4*

46-1/4

29-7/8

46-1/2

CENTER LINE

2-1/4

7-1/2

7-1/2

7

5

2-1/4

3-1/2

REAR

WALL

1/4†

R

Listed by

Underwriters

Laboratories

* Dimension from wall to front of closed oven door

without handle.

† The range may be placed with a 0" clearance (flush) at

the back wall and side walls if the range side trims

extend beyond the cabinet fronts at least 1/4".

Self Clean models only. All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

For answers to your Monogram,

® GE Profile™ or

GE® appliance questions, visit our website at

GEAppliance.com or call

GE Answer Center® service, 800.626.2000.

Specification Revised 11/05

321685

KW Rating

240V 12.6

208V 9.9

Breaker Size

40 Amps†

Specification Revised 11/05

321685

GE Appliances

JBS27SH – GE® 30" Free-Standing Electric Range

JBS27SHSS.EPS

CLOCK

SET

TIMER

ON

OFF

Features and Benefits

• Super-Large Oven Capacity – Provides an impressively large oven interior for cooking

more dishes and large meals at one time.

• Coil Heating Elements – Provides consistent and even heat on the cooktop with a plug-in

element that is removable for easy cleaning.

• ClearView™ Window – Features a convenient viewing area to check the progress of food.

• Dual Element Bake – Alternates the upper broiling element and the lower baking element

for even heating and optimal baking results.

• Electronic Clock and Timer – Features a convenient digital clock and easy-to-use timer

with an audible signal to help coordinate cooking times in the kitchen.

• Frameless Glass Oven Door – Offers an easy-to-clean and stylish design that blends

seamlessly into existing cabinetry.

• Drip Bowls – Contains minor spills and are removable for easy cleaning.

• Model JBS27WHWW – White on white (white door and white cooktop)

• Model JBS27CHCC – Bisque on bisque (bisque door and bisque cooktop)

• Model JBS27BHBB – Black on black (black door and black cooktop)

• Model JBS27SHSS – Stainless steel (stainless steel door and control panel/

black cooktop)
