GE Capacitor & Power Quality Product

MATRIX FILTER 

SERIES B

480 Volts, 60HZ

USER MANUAL

GE Capacitor & Power Quality Product

IMPORTANT USER INFORMATION

NOTICE

The GE Corporation Matrix Filter is designed for harmonic mitigation of six pulse

inverter drives supplying variable torque loads in a wide variety of applications. The

suitability of this filter for a specific application must therefore be determined by the

customer. In no event will GE assume responsibility or liability for any direct or

consequential damages resulting from the use or application of this filter. Nor will GE

assume patent liability with respect to the use of information, circuits or equipment

described in this instruction manual.

GE Capacitor & Power Quality Product

TABLE OF CONTENTS

1. Safety .......................................................................................................... 1

2. Introduction ................................................................................................. 3

3. Model Number Codes.................................................................................. 4

4. Specifications .............................................................................................. 5

Ratings .................................................................................................. 5

Service Conditions ................................................................................. 5

Performance ......................................................................................... 6

Altitude Derating Curve ........................................................................ 11

5. Installation Instructions .............................................................................. 12

Filter Installation ................................................................................... 12

Outline Drawings and Mounting Dimensions ....................................... 13

Power Wiring Connection .................................................................... 29

Ground and Ground Fault Protection................................................... 29

Input and Output Terminal Specifications ............................................ 30

Interconnection Diagrams.................................................................... 31

6. Filter Description ....................................................................................... 44

7. Start – Up .................................................................................................. 46

8. Troubleshooting......................................................................................... 48

GEH-7252 1 May 2003

GE Capacitor & Power Quality Product

1. IMPORTANT SAFETY INFORMATION

WARNING

ONLY A QUALIFIED ELECTRICIAN CAN CARRY OUT THE ELECTRICAL

INSTALLATION OF THIS FILTER

WARNING

High voltage is used in the operation of this filter. Use Extreme caution to avoid contact with

high voltage when operating, installing or repairing this filter. INJURY, DEATH AND/OR

PROPERTY DAMAGE MAY RESULT IF SAFETY PRECAUTIONS ARE NOT

OBSERVED.

After removing power, allow at least five minutes to elapse and verify that the capacitors

have discharged to a safe level before contacting internal components. Connect a DC

voltmeter across the capacitor terminals or terminals 1, 2 and 3 on terminal block 1TB.

Start with the meter on the highest scale and progressively switch to a lower scale as the

indicated voltage falls below the maximum value of the scale used.

WARNING

THE OPENING OF THE BRANCH CIRCUIT PROTECTIVE DEVICE MAY BE AN INDICATION THAT A

FAULT CURRENT HAS BEEN INTERRUPTED. TO REDUCE THE RISK OF FIRE OR ELECTRICAL

SHOCK, CURRENT-CARRYING PARTS AND OTHER COMPONENTS OF THE FILTER SHOULD BE

EXAMINED AND REPLACED IF DAMAGED.

WARNING

AN UPSTREAM DISCONNECT/PROTECTION DEVICE MUST BE USED AS REQUIRED BY THE

NATIONAL ELECTRICAL CODE (NEC).

WARNING

EVEN IF THE UPSTREAM DISCONNECT/ PROTECTION DEVICE IS OPEN, THE DRIVE DOWN

STREAM OF THE FILTER MAY FEED BACK HIGH VOLTAGE TO THE FILTER. THE DRIVE

SAFETY INSTRUCTIONS MUST BE FOLLOWED.

INJURY, DEATH AND/OR PROPERTY DAMAGE MAY RESULT IF THE DRIVE SAFETY

PRECAUTIONS ARE NOT OBSERVED.

WARNING

THE FILTER MUST BE GROUNDED WITH A GROUNDING CONDUCTOR CONNECTED TO

ALL GROUNDING TERMINALS

GEH-7252 2 May 2003

GE Capacitor & Power Quality Product

WARNING

ONLY SPARE PARTS OBTAINED FROM GE OR AN AUTHORIZED GE DISTRIBUTOR CAN BE

USED.

GEH-7252 3 May 2003

GE Capacitor & Power Quality Product

2. INTRODUCTION

This manual was specifically developed to

assist in the installation, interconnection and

operation of the GE Matrix Filter.

This manual is intended for use by personnel

experienced in the operation and maintenance

of electronic drives. Because of the high

voltages required by the filter and drive and

the potential dangers presented by rotating

machinery, it is essential that all personnel

involved in the operation and maintenance of

this filter know and practice the necessary

safety precautions for this type of equipment.

Personnel should read and understand the

instructions contained in this manual before

installing, operating or servicing the filter and

the drive to which the filter is connected.

Upon Receipt of this Filter:

The GE Matrix Filter has been subjected to

demanding factory tests before shipment.

Carefully inspect the shipping container for

damage that may have occurred in transit.

Then unpack the filter and carefully inspect for

any signs of damage. Save the shipping

container for future transport of the filter.

In the event of damage, please contact and

file a claim with the freight carrier involved

immediately.

If the equipment is not going to be put into

service upon receipt, cover and store the filter

in a clean, dry location. After storage, ensure

that the equipment is dry and that no

condensation has accumulated on the internal

components of the filter before applying

power.

Repair/Exchange Procedure

GE requires a Returned Material Authorization

Number before it can accept any filters that

qualify for return or repair. If problems or

questions arise during installation, setup, or

operation of the filter, please call us for

assistance at:

Phone: 518-746-5793

FAX: 518-746-5524

GEH-7252 4 May 2003

GE Capacitor & Po

er Quality Product

3. MODEL NUMBER CODES

37GM (5 or 8) X X X X X X X X X X X

Total Harmonic Current Distortion (THID)

5% or 8% THID

Mechanical Configuration

G = General Purpose NEMA 1 & 2

W= General Purpose NEMA 3R

N = Industrial Style NEMA 1

Enclosure Size

B CAB 17B or CAB-002

C CAB 20B or CAB-003

D CAB 30B or CAB-004

E CAB 42B or CAB-005

F CAB-006

Output Current Rating

(i.e., 0044 is 44 amps)

Voltage and Frequency

A 208-240V, 60Hz

B 240V, 50Hz

C 380-415V, 50Hz

D 480V, 60Hz

E 600V, 60Hz

Options

Matrix Filter Designator

GEH-7252 5 May 2003

GE Capacitor & Po

er Quality Product

4. SPECIFICATIONS

Ratings

Table 1

480 VAC, 60 Hz SERIES B Filter Ratings

THID Rating 8% 5%

Maximum

Output Amps

RMS

Efficiency

(Typical)

(%)

Power Dissipation

@ Rated Current

(Typical)

(Watts)

Efficiency

(Typical)

(%)

Power Dissipation

@ Rated Current

(Typical)

(Watts)

6 97.2 139 97.4 132

8 97.5 164 97.6 161

11 97.8 200 97.8 197

14 98.0 233 98.0 232

21 98.3 299 98.3 294

27 98.4 351 98.5 343

34 98.6 406 98.6 399

44 98.7 479 98.7 472

52 98.8 539 98.8 533

66 98.9 626 98.9 621

83 98.9 740 98.9 735

103 99.0 850 99.0 844

128 99.1 964 99.1 959

165 99.2 1143 99.2 1145

208 99.2 1355 99.2 1361

240 99.3 1493 99.2 1498

320 99.3 1829 99.3 1838

403 99.4 2110 99.4 2098

482 99.4 2393 99.4 2371

636 99.4 2978 99.4 2929

786 99.5 3432 99.5 3402

Service Conditions

Load: 6 pulse variable torque rectifier only

Input voltage: 480 VAC +/- 10%, 60 + 0.75 Hz, 3 phase

Input voltage line unbalance: 1% maximum

Maximum source impedance: 6.00%

Minimum source impedance: 1.5%

Service Factor: 1.00

SPECIFICATIONS - continued

GEH-7252 6 May 2003

GE Capacitor & Power Quality Product

Ambient Temperature (Operating)

Enclosed Filters: -40 to +40 degrees C

Open Panel Filters: -40 to +50 degrees C

Storage Temperature: -40 to +90 degrees C

Altitude: 0 to 3300 Feet above sea level. Refer to Figure 6 for altitude derating.

Relative Humidity: 0 to 95% non-condensing

Agency Approvals

UL-508C File E191686 Component Recognized

(3-1000 HP, 120 VAC through 600 VAC

50, 50/60, 60 Hz Three Phases

CAN/CSA C22, 2 No. 14-95

Performance

Total Harmonic Current Distortion:

Eight Percent Filter: 8% typical at full load 12% maximum no load to full load

Five Percent Filter: 5% typical at full load 8% maximum no load to full load

Standby Current:

Without Optional Capacitor Contactor: 70% of the full load capacitor current listed in Table 3

With Optional Capacitor Contactor: Refer to Drive Users Manual

8% Filter Voltage Regulation with nominal 480 volts RMS source

Maximum output voltage at no load: 502 volts RMS, 710 volts peak

Maximum PCC* voltage with 6.00% source impedance at no load: 490 volts RMS, 693 volts peak

Minimum output voltage at full load: 460 volts RMS, 600 volts peak

5% Filter Voltage Regulation with nominal 480 volts RMS source

Maximum output voltage at no load: 502 volts RMS, 710 volts peak

Maximum PCC voltage with 6.00% source impedance at no load: 490 volts RMS, 693 volts peak

Minimum output voltage at full load: 460 volts RMS, 600 volts peak

*Note: PCC is the point of common coupling with the power distribution system

SPECIFICATIONS - continued

GEH-7252 7 May 2003

GE Capacitor & Power Quality Product

Table 2

480 Volt, 60 Hz Series B Matrix Filter

Weights

Open Panel General Purpose

NEMA 1, 2, 3R Industrial

NEMA 1

THID THID THID

Output

Amps RMS 8%

Weight Lbs 5%

Weight Lbs 8%

Weight Lbs 5%

Weight Lbs 8%

Weight Lbs 5%

Weight Lbs

6 273883946273

8 304085966575

11 35 45 95 105 70 80

14 35 45 95 105 80 90

21 45 60 105 120 85 100

27 50 65 135 150 100 115

34 70 85 160 175 125 140

44 70 85 160 175 125 140

52 105 135 170 200 235 265

66 125 155 300 330 270 300

83 200 250 355 405 325 375

103 200 250 355 405 325 375

128 225 275 385 435 350 400

165 265 325 420 480 475 535

208 275 325 425 475 485 535

240 300 400 500 600 525 625

320 650 750 740 840 1175 ---

403 700 825 830 955 1250 ---

482 775 930 890 1045 1350 ---

636 --- --- 1200 1450 --- ---

786 --- --- 1400 1700 --- ---

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GE Alimentation

GE EPS 301 Manuel utilisateur

GE Tetra GEPS24-100U-GL Manuel utilisateur

GE DEH-40417 Mode d'emploi

GE NetworX Series Manuel d'installation

GE RAK315D Manuel utilisateur

GE LED 55 CC 1.4A ESRDL 1-10V 220-240 Manuel utilisateur

GE Tetra GEPS12-25U-EU Manuel utilisateur

GE RAK4157 Manuel utilisateur

GE Digital Energy LP 31 Series Caractéristiques techniques

GE Infinity S Manuel utilisateur

GE Tetra GEPS24-100U-GLX Manuel utilisateur

GE NX-320E Manuel utilisateur

GE RAK3152 Manuel utilisateur

GE Digital Energy LP 33 Series Manuel utilisateur

GE LED 55 CC 1.4A TBDL 1-10V Manuel utilisateur

GE GEPS12-25U-NA Manuel utilisateur

GE Mastr II 19E501149G1 Manuel utilisateur

GE Digital Energy Manuel utilisateur

GE SMOR-B GEK 105593C Manuel utilisateur

GE EPS 601 Manuel utilisateur

GE 517EPS1 Manuel utilisateur

GE Tetra GEPS12-60 Manuel utilisateur

GE Current Tetra GEPS12-25U-EU Manuel

GE Tetra GEPS24W-80M Manuel

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
