GE TVC-BIRSR Manuel utilisateur
GE
Security
g1065696A
TruVision Bullet IR Camera
Pocket Guide
Copyright Copyright © 2008 GE Security. All rights reserved.
This document may not be copied in whole or in part
or otherwise reproduced without prior written
consent from GE Security except where specifically
permitted under US and international copyright law.
Document num/rev: 1065696A (November 2008).
Disclaimer The information in this document is subject to
change without notice. GE Security (“GE”) assumes
no responsibility for inaccuracies or omissions and
specifically disclaims any liabilities, losses, or risks,
personal or otherwise, incurred as a consequence,
directly or indirectly, of the use or application of
any of the contents of this document. For the
latest documentation, contact your local supplier
or visit us online at www.gesecurity.com.
This publication may contain examples of screen
captures and reports used in daily operations. Exam-
ples may include fictitious names of individuals and
companies. Any similarity to names and addresses of
actual businesses or persons is entirely coincidental.
Trademarks
and patents
GE and the GE monogram are registered trademarks
of General Electric Company. TruVision Bullet IR
Camera is a trademark of GE Security.
Other trade names used in this document may be
trademarks or registered trademarks of the manu-
facturers or vendors of the respective products.
Intended
use
Use this product only for the purpose it was designed
for; refer to the data sheet and user documentation.
For the latest product information, contact your local
supplier or visit us online at www.gesecurity.com.
TruVision Bullet IR Camera
Pocket Guide
iii
FCC
compliance
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful inter-
ference when the equipment is operated in a resi-
dential environment. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the
instruction manual, may cause harmful interference
to radio communications.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
EU
directives
2004/108/EC (EMC directive). Non-European manu-
facturers must designate an authorized representa-
tive in the Community. Our authorized
manufacturing representative is GE Security B.V.,
Kelvinstraat 7, 6003 DH Weert, Nederland.
2002/96/EC (WEEE directive). Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information, visit www.recyclethis.info.
Regulatory
iv
TruVision Bullet IR Camera
Pocket Guide
v
Introduction . . . . . . . . . . . . . . . . . . . . 1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Contacting us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Contact information . . . . . . . . . . . 10
vi
TruVision Bullet IR Camera
Pocket Guide
1
Introduction
This is the GE TruVision Bullet IR Camera
Pocket Guide for models TVC-BIR-MR and
TVC-BIR-HR. This pocket guide describes a
standard installation.
Overview
The TruVision Bullet IR Camera consists of
the following:
• Camera with power and video output
cables
• Flying lead
Figure 1shows the parts of the camera, and
figure 2show the lens, IR LEDs, and the light
sensor.
2
1
ASunshield BPower and video
cable
A B
TruVision Bullet IR Camera
Pocket Guide
3
2
B
A
C
ALED IR lights (total
number of lights
varies by model)
BLens
CLight sensor
4
Installation
Note: When installing the TVC-BIR-MR or
TVC-BIR-HR, please use the optional bracket,
TVC-BIR-WM, which is sold separately.
To install the camera, do the following.
1. Using the mount as a template, place
it level against the mounting surface
and mark the position of the
mounting holes.
2. Following all local codes, drill and
prepare the mounting holes.
3. Securely fasten the mount to the
mounting surface with the appro-
priate fasteners.
4. If needed, seal all mounting holes so
that no moisture can leak into the
mounting surface.
