GE GLD5600N Manuel

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Reivsed 6/07 350235

Panel

Thickness

Kit A B C

GPF525 25-1/4" 23-1/2" N/A 1/4"

GPF575 25-1/2" 23-5/8" 1/4" 3/4"

Listed by

Underwriters

Laboratories

5" 5"

Figure A

Floor MUST be Even

With Room Floor

Cabinets

Square

and

Plumb

This Wall Area

must be Free

of Pipes or

wires

24"

Min.

24"

Min.

34-1/2"

Underside of

Countertop

to Floor

Plumbing and Electric Service

Must Enter Inside This Area

MAX.

20-1/2

4 (Adjustable)

33-3/4" MIN.

adj. to 35"

27-1/2

See Detail E for 3/4" Panel

Door insert A

Detail E for 3/4 panel only

Back ViewFront View

1-7/8 1-7/8

Section E-F

3/8

3/4

Electrical Rating

Voltage AC.......................................................... 120

Hertz..................................................................... 60

Total connected load amperage............. 10

Calrod® heater watts max........................ 875

For use on adequately wired 120-volt,

15-amp circuit having 2-wire service

with a separate ground wire. This appliance

must be grounded for safe operation.

Note: The rough cabinet opening must be at

least 24" deep, 24" wide and approximately

34-1/2" high from floor to underside of

the countertop. Dishwasher must not be

installed more than 10 feet from sink for

proper drainage. All plumbing and

electrical work must be in accordance

with local codes. The power cord and

connections must comply with the National

Electrical Code Section 422 and/or local

codes and ordinances. The cord must be no

longer than 6 ft. from the junction box to

the receptacle.

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

GLD5600/60N

GE®Tall Tub Built-In Dishwasher

Specification Revised 6/07 350235

GLD5660NSS

Features and Benefits

• Giant Tub with Maximum Capacity Racking - Holds tall and oversized items; washes

16 place settings at once

• 2 Utility Shelves in Upper Rack - Creates space in the upper rack for cups and utensils

• 6-Level BrilliantClean™Towerless Wash System - Quietly and efficiently powers dishes

clean using remarkably less water and energy; 6 wash levels and three wash arms

direct water onto dishes just where it's needed

• SaniSensor™- Continually measures water temperature to sanitize dishes

•

Electronic Controls with 5 Cycles/4 Options - Make it simple to select from

a wide range of wash cycles

• QuietPower™3 Sound Package - Dramatically reduces the sound

of washing the dishes

• 2/4/8-Hour Delay Start - Makes it easier than ever to wash dishes at any hour taking

advantage of reduced energy rates or washing dishes even when the family is asleep

• 100% Triple Water Filtration - Water stays clean, so just-washed dishes do, too

• SaniWash Cycle - Sanitizes tableware by reducing 99.999% of bacteria

found on dishes

• HotStart™Option - Preheats water before the main wash cycle

for dependable performance every time

• Model GLD5600NWW - White on white

• Model GLD5600NCC - Bisque on bisque

• Model GLD5600NBB - Black on black

• Model GLD5660NSS - Stainless steel

GLD5600/60N

GE®Tall Tub Built-In Dishwasher
