GE JGP960SEDSS Manuel
Specification Revised 11/01
GE Appliances
JGP960SEDSS—GE 36” Built-In Gas Cooktop
Dimensions (in inches) Counter Installation Dimensions (in inches)
Cooktop
2-1/2
3-1/16
33-7/8
19-1/8
36 21
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
3-3/4" MIN.
clearance to
side wall
from cut-out
3-3/4" MIN.
clearance to
side wall
from cut-out
18" MIN.
to cabinet
2-1/4" to
rear wall
13" MAX.
depth
Optional Gas Range Wok Accessory
(Available at additional cost)
JXWK = Wok accessory holder sits on top of the maximum
burner grate to hold a round-bottom wok.
AGA Requirement: All gas cooktop models require 7/16"
free area below countertop height to combustible material.
Requires 18" minimum from countertop to adjacent overhead
cabinets. 0” Clearance is required between left and right
sides of cooktop below countertop.
Electrical Rating: 120V, 60Hz, 5A
Installation With Single Wall Oven Information:
30" Gas Cooktops are approved for use over GE 27" Wall
Ovens. 30" and 36" Gas cooktops are approved for use over
30" Wall Ovens. Refer to cooktop and wall oven installation
instructions packed with product for current dimensional data.
Installation Information: Before installing, consult
installation instructions packed with product for current
dimensional data.
For answers to your Monogram,
® GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Specification Revised 11/01
GE Appliances
JGP960SEDSS—GE 36” Built-In Gas Cooktop
Features and Benefits
• 36" Tempered Glass Cooktop
• Sealed Cooktop Burner Design
• Maximum Output Burner
• (2) Precise Simmer Burners
• Dishwasher-Safe Deluxe Cast Grates
• Procelain-Enameled One-Piece Drip Pans
• Electronic Pilotless Ignition
• Up-Front Controls
• Model JGP960SEDSS–Stainless Steel
