AJM10AF—”J Series” Cool Unit

GE Appliances

Revised 6/96

Note: When installing units in through-the-wall applications. 

Do not restrict air flow areas.

26

15-5/8

16-7/8

R

Total capacity and E.E.R.

ratings are calculated

based on the Association

of Home Appliance

Manufacturers' standards.

Listed by

Underwriters

Laboratories

For answers to your GE Monogram,™GE Profile,™

GE, Hotpoint and RCA appliance questions, call

GE Answer Center®service, 800.626.2000.

Wall Case Dimensions (in inches)

Parallel

115V

15 Amp

Revised 6/96

GE Appliances

AJM10AF—Built-In Room Air Conditioner RAB46/47/48

Brick Block and Brick

Frame Construction

Fill open cells

with mortar

or insulation

5" Min.

from floor

15-3/4

26-1/8

Lintel

R

Total capacity and E.E.R.

ratings are calculated

based on the Association

of Home Appliance

Manufacturers' standards.

Listed by

Underwriters

Laboratories

For answers to your GE Monogram,™GE Profile,™

GE, Hotpoint and RCA appliance questions, call

GE Answer Center®service, 800.626.2000.

Dimensions (in inches)

Installation Information: A finished opening of

26-1/8" x 15-3/4" clear of intrusions is required. Keep

clearance of 4" from side walls. Brick veneer or frame

walls should have wood studding surrounding case to

provide firm anchoring with screws. Case can be fastened

directly to brick or block walls with screws sunk in lead

expansion shields.

Make frame if desired or caulk 

between case and siding

15-3/4

26-1/8 5" Min.

from floor

Frame Construction

Lintel

OUTSIDE INSIDE

16-7/8

Caulking

Drip Rail

Trim Moulding

(if desired)

Plaster Line

Flexible Mounting Position

GE Appliances

Revised 6/96

AJM10AF—”J Series” Cool Unit

Features and Benefits

•Decorative Warm Gray-Beige Front

•10,200 BTUH, 8.5 EER, 115 Volts

•Hidden Energy Saver Switch for Reduced Energy Consumption

•10-Position Thermostat

•2 Cooling/2 Fan Speeds

•Slide-Out Filter for Easy Cleaning

•Hidden Exhaust Control for Air Exchange

•Slide-Out Chassis

•Chassis Only–Without Wall Case and Mounting Kit

•Wall Case–Optional Accessory

•Window Mounting Kit–Optional Accessory

•Plug Type–Parallel

1

5

4

3

2

67

8

9

10

HIGH

FAN

LOW

FAN

OFF LOW

COOL

HIGH

COOL

C

O

O

L

E

R

THERMOSTAT SELECTOR

GE Quality Product
