PMA-2000 POWER MANAGEMENT ADAPTER
INSTALLATION MANUAL
November 13th, 2020
1. Introduction
GDC PMA-2000 INSTALLATION MANUAL - 2 - November 13th, 2020
Table Of Contents
1Introduction .................................................................................................. 4
2Packing List .................................................................................................. 5
3Hardware Installation ................................................................................... 7
3.1 Introduction of Front Panel and Ports...................................................... 8
3.2 Device Installation and Cabling .............................................................. 10
3.3 Power Supply Connection to the Projector............................................ 12
3.4 Power Supply Connection to the Ventilation System............................ 13
3.5 Power Supply Connection to the Audio System.................................... 14
3.6 Power Supply Connection to the Lighting System................................ 15
3.7 Power Supply Connection to the Device Sockets ................................. 16
3.8 Power Supply Connection to the Screen Masking System................... 16
3.9 Power Supply Connection to the PMA-2000 .......................................... 17
4Software Configuration.............................................................................. 18
4.1 Setting up IP Address.............................................................................. 18
4.2 Adding a new device ............................................................................... 20
4.3 Remote Control of Power Connection/Disconnection .......................... 21
1. Introduction
GDC PMA-2000 INSTALLATION MANUAL - 4 - November 13th, 2020
1 Introduction
The PMA-2000 is a power management device designed especially for theatre projection
rooms. It provides intelligent power supply management for theatre projection equipment,
giving exhibitors the means to achieve a complete unmanned projection system.
▪Retrofit installation means zero interference with the existing power supply system,
making seamless integration possible for theatres under construction or currently in
operation.
▪Intelligent power supply management system monitors and controls power routed to
a range of theatre equipment, including projectors, servers, audio systems and
luminance equipment.
▪Together with Theatre Management System (TMS) and Quality Management
System (QMS), unmanned projection can be achieved, based on the foundation of
automated projection.
2. Packing List
GDC PMA-2000 INSTALLATION MANUAL - 5 - November 13th, 2020
2 Packing List
The PMA-2000 package includes two boxes: the main package and the accessories
package. The contents are listed under
Table 1.
PMA-2000 Packing List
Sr. No.
Description
Quantity
1
PMA-2000 Power
Management Adapter
1
2
Mounting Bracket
1
3
Projector Wires
(6mm2- Red)
2
4
Audio System
(6mm2 - Yellow)
2
5
Exhaust Fan Wires (2.5
mm2 -Yellow/Green/Red
2pcs each)
6
2. Packing List
GDC PMA-2000 INSTALLATION MANUAL - 6 - November 13th, 2020
6
Lighting System Wires
(2.5mm2 - Yellow/ Blue)
3
7
Equipment Socket Wires
(2.5 mm2 - Red/ Blue)
3
8
International standard
power cord
1
9
Metal hose
3m
10
Supplementary Parts
and Accessories
Multiple
Table 1
3. Hardware Installation
GDC PMA-2000 INSTALLATION MANUAL - 7 - November 13th, 2020
3 Hardware Installation
The PMA-2000 power management device adopts wall-mounted installation.
The PMA-2000 power management device adopts wall-mounted installation. It is usually
installed adjacent to the power distribution box in the projection room, as shown in Figure 1.
The device has two outlet ports on either side for cable connections.
Figure 1: Mounting location for PMA-2000
When there is not enough space around the distribution box, the PMA-2000 can be
installed above or below the distribution box and the metal hose can be used for
wiring, as shown in Figure 2.
Figure 2: Alternate Installation Positions
3. Hardware Installation
GDC PMA-2000 INSTALLATION MANUAL - 8 - November 13th, 2020
3.1 Introduction of Front Panel and Ports
The upper half of the device to designed to be a manual control panel and a status
display area. The buttons themselves are status light indicators. Illuminated indicator
means that the device connected to the corresponding output of the PMA-2000 is
powered up, while non-illuminated indicator means that the device is not powered. Due
to safety considerations, pressing the individual button will not execute power supply
connection/disconnection unless it is pressed concurrently with the ‘Unlock button’
located at the top right corner, to achieve manual control. The control buttons are
arranged in the order from left to right: Projector, Exhaust, Audio, Lights, Devices,
Masking, Aux-A, Aux-B.
Figure 3: Front panel of PMA-2000
The lower half of the device consists of the connecting terminal of the
corresponding control buttons, network connectors and the power switch for the
device. The connecting terminals of the Projector and Audio System adopts 65A
and the rated load current is 50A. The other connecting terminals adopt 30A and
the rated load current is 20A. The Projector, Audio System, Exhaust fan and Screen
Masking system are designed to be connected with 380V voltage device. The
Lighting system, Device sockets, Aux-a and Aux-b have regular 220V power
loading. The PMA-2000 is a device with 220V input voltage. Detailed connector
arrangement sequence and illustrations are shown in Figure 4.
Note: The power of the device should be connected shall not exceed the rated
power of the PMA terminal and wire load. Otherwise the device will be damaged.
3. Hardware Installation
GDC PMA-2000 INSTALLATION MANUAL - 9 - November 13th, 2020
Figure 4: Connectors on the PMA-2000
Two network ports have been provided on the PMA-2000 with in-built switching function.
The Management Network cable from the cinema control room is first connected to one
of these network ports and then routed to the single hall manageable switch via the other
network port. In this setup, the PMA-2000 is available on the network in case of power
failure to the single hall switch.
Figure 5: Network Ports on the PMA-2000
3. Hardware Installation
GDC PMA-2000 INSTALLATION MANUAL - 10 - November 13th, 2020
3.2 Device Installation and Cabling
Step 1: Install the bracket in the
accessory box on the back of the PMA
device.
Step 2: Use the cardboard in the PMA
device as a template to determine the
position of the mounting holes.
Step 3: Properly punch holes with
cardboard template and install the
bracket.
Step 4: Install the PMA on the bracket
and mark the position of the outlet port
on the distribution box using a marker.
Step 5: Remove the PMA and use a
32mm hole opener to cut the hole. Polish
any sharp hole edge to prevent
breakage of any wires.
Step 6: Install PMA threading and connect
the corresponding incoming and outgoing
power supply wires according to the device
labels.
