GCE ARCONTROL 161 Guide de démarrage rapide

GCE

CUTTING & WELDING TECHNOLOGIES

2/68

ARCONTROL are welding machines for MMA arc welding that can also perform TIG operations. They adopt the latest

Pulse Width Modulation (PWM) technology and the Insulated Gate Bipolar Transistor (IGBT) power module. They are

equipped with some automatic protection functions for undervoltage, overcurrent, overheating, etc. that prolong their

lifetime and greatly improve their reliability and practicality.

Read and understand all instructions before using.

Arc welding produces intense electric and magnetic emissions that may interfere with the proper function of cardiac

pacemakers, hearing aids, or other electronic health equipment. Persons who work near arc welding applications should

consult their medical health professional and the manufacturer of the health equipment to determine whether a hazard

exists. To prevent possible injury, read, understand, and follow all warnings, safety precautions and instructions before

using the equipment.

Only qualified persons should install, operate, maintain, and repair this equipment.

During the operation, non-concerned people should not be present, especially children.

Contact with live electrical parts can cause fatal shocks or severe burns. The electrode and the work circuit are

electrically live whenever the output is on. The input power circuit and the internal circuits of the machine are also active

when power is on. The equipment installed incorrectly or improperly grounded is dangerous.

Never touch electrical parts.

Wear dry, hole-free gloves and clothes to insulate yourself.

Insulate yourself from workpiece and ground using dry insulation. Make sure the insulation is large enough to cover

your full area of physical contact with workpiece and ground.

Be careful when using the equipment in a tight place, or when there's a risk of fall and moisture.

Make sure to install the equipment correctly and ground the work or metal to be welded to a good electrical (earth)

ground according to the operation manual.

The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts

with your bare skin or wet clothing. Wear dry, hole-free gloves to insulate your hands.

Always make sure the work cable makes a good electrical connection with the metal being welded. The connection

should be as close as possible to the area being welded.

Maintain the electrode holder, work clamp, welding cable and welding machine in good, safe operating condition.

Replace damaged insulation.

Never dip the electrode in water for cooling.

Never simultaneously touch electrically “hot” parts of electrode holders connected to two different welders because

voltage between the two can be the total of the open circuit voltage of both welders.

When working above floor level, use a safety belt to protect yourself from a fall in case of shock.

Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases. When welding,

keep your head out of the fume. Use enough ventilation and/or exhaust at the arc to keep fumes and gases away from

the breathing zone. When welding with electrodes which require special ventilation such as stainless or hard facing or

on lead or cadmium plated steel and other metals or coatings which produce highly toxic fumes, keep exposure as low

as possible and below Threshold Limit Values using local exhaust or mechanical ventilation. In confined spaces or in

some circumstances, outdoors, a respirator may be required. Additional precautions are also required when welding

on galvanized steel.

Do not weld in locations near chlorinated hydrocarbon vapours coming from degreasing, cleaning, or spraying

operations. The heat and rays of the arc can react with solvent vapours to form phosgene, a highly toxic gas, and

other irritating products.

Shielding gases used for arc welding can displace air and cause injury or death. Always use enough ventilation,

especially in confined areas, to ensure breathing air is safe.

Read and understand the manufacturer’s instructions for this equipment and the consumables to be used, including

the material safety data sheet and follow your employer’s safety practices.

3/68

Arc rays from the welding process produce intense visible and invisible ultraviolet and infrared rays that can burn eyes

and skin.

Use a shield with the proper filter and cover plates to protect your eyes from sparks and the rays of the arc when

welding or observing open arc welding.

Use suitable clothing made from durable flame-resistant material to protect your skin and that of your helpers from the

arc rays.

Protect other nearby personnel with suitable, non-flammable screening and /or warn them not to watch the arc nor

expose themselves to the arc rays or to hot spatter or metal.

Welding on closed containers, such as tanks, drums, or pipes, can make them explode. Flying sparks from the welding

arc, hot workpiece, and hot equipment can cause fires and burns. Accidental contact of electrode to metal objects can

cause sparks, explosion, overheating, or fire. Check and be sure the area is safe before making any welding.

Remove fire hazards from the welding area. If this is not possible, cover them to prevent the welding sparks from

starting a fire. Remember that welding sparks and hot materials from welding can easily go through small cracks and

openings to adjacent areas. Avoid welding near hydraulic lines. Have a fire extinguisher easily available.

Where compressed gases are to be used at the job site, special precautions should be used to prevent hazardous

situation.

When not welding, make sure that no part of the electrode circuit is touching the work or ground. Accidental contact

can cause overheating and create a fire hazard.

Do not heat, cut, or weld tanks, drums or containers until the proper steps have been taken to ensure that such

procedures will not cause flammable or toxic vapours from substances inside. They can cause an explosion even

though they have been cleaned.

Vent hollow castings or containers before heating, cutting, or welding. They may explode.

Sparks and spatter are thrown from the welding arc. Wear oil free protective garments such as leather gloves, heavy

shirt, cuff less trousers, high shoes, and a cap over your hair. Wear ear plugs when welding out of position or in

confined places. Always wear safety glasses with side shields when in a welding area.

Connect the work cable to the work as close to the welding area. Work cables connected to the building framework or

other locations away from the welding area increase the possibility of the welding current passing through lifting

chains, crane cables or other alternate circuits. This can create fire hazards or overheat lifting chains or cables until

they fail.

DO NOT refuel near an open flame welding arc or when the engine is running. Stop the engine and allow it to

cool before refuelling to prevent spilled fuel from vaporizing on contact with hot engine parts and igniting. Do

not spill fuel when filling tank. If fuel is spilled, wipe it up and do not start engine until fumes have been

eliminated.

Keep all equipment safety guards, covers and devices in position and in good repair. Keep hands, hair, clothing, and

tools away from V-belts, gears, fans, and all other moving parts when starting, operating, or repairing equipment.

Do not put your hands near the engine fan.

Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating

regulators designed for the gas and pressure used. All hoses, fittings, etc. should be suitable for the application and

maintained in good condition.

Always keep cylinders in an upright position securely chained to an undercarriage or fixed support.

Cylinders should be located:

Away from areas where they may be struck or subjected to physical damage.

A safe distance from arc welding or cutting operations and any other source of heat, sparks, or flame.

Never allow the electrode, electrode holder or any other electrically “hot” parts to touch a cylinder.

Keep your head and face away from the cylinder valve outlet when opening the cylinder valve.

Valve protection caps should always be in place and hand tight except when the cylinder is in use or connected for

use.

Electric current flowing through any conductor causes localized Electric and Magnetic Fields (EMF). The discuss on the

effect of EMF is ongoing all the world. Up to now, no material evidences show that EMF may have effects on health.

However, the research on damage of EMF is still ongoing. Before any conclusion, we should minimize exposure to EMF

as few as possible. In order to minimize EMF, we should use the following procedures:

Route the electrode and work cables together – Secure them with tape when possible.

All cables should be put away and far from the operator.

Never coil the power cable around your body.

4/68

Make sure welding machine and power cable to be far away from the operator as far as possible according to the

actual circumstance.

Connect the work cable to the workpiece as close as possible to the area being welded.

People with heart-pacemaker should be away from the welding arc.

ARCONTROL are welding machines for MMA arc welding which adopts the latest Pulse Width Modulation (PWM)

technology and the Insulated Gate Bipolar Transistor (IGBT) power module. It can change work frequency to medium

frequency to replace the traditional hulking work frequency transformer with the cabinet medium frequency transformer.

Thus, the welding machine is featured by portability, small size, low consumption, etc.

ARCONTROL welding machines have excellent performances: constant current output makes welding arc more stable;

fast dynamic response speed reduces the impact from the arc length fluctuation to the current; accurate stepless current

adjustment and pre-setting function. There are also some automatic protection functions for under voltage, over current,

over heat, etc. inside the welders, when the problems listed before occurred, the alarm on the front panel is light and at

the same time the output current will be cut off. It can self-protect and prolong the using life and greatly improved the

reliability and practicability of the welders.

ARCONTROL welding machines can also realize TIG operation. While MMA operation, if the electrode touches work

piece over two seconds, the welding current will drop to the minimum current automatically to protect the electrode. While

TIG operation, the minimum current will be outputted firstly until the arc is ignited by lifting method, the output current will

rise to the pre-set value, which can protect the electrode.

Built-in extra functions

"Hot Start" function for easier arc striking.

"Arc Force" to prevent electrode sticking to the workpiece. Smoother welding and deeper penetration.

"Anti-sticking" device to prevent overload and ease the electrode removal from the workpiece.

Fully protected against over-voltage, under-voltage, and over-heat.

Generator friendly. Designed to work with diesel generators and to avoid failures due to its voltage spikes.

1 piece Welding machine.

1 piece Cable + Connector + Earth Clamp

1 piece Cable + Connector + Electrode Holder

1 piece Operation manual (via QR code).

This device has been designed and manufactured in accordance with the requirements of

Directive 2014/30/EU – EMC on electromagnetic compatibility

Directive 2014/35/EU – LVD on low voltage devices

and it is thus CE marked.

The welding machine complies with the standards EN 60974-1: 2012 and EN 60974-10: 2014 and is identical to the

sample certified by ECMG Electronic Technical Testing Corp.

The Declaration of Conformity can be requested by filling out the form in the contact section of our website

www.gcegroup.com.

Model

Power Supply Voltage 1-230 V ±10%

ARCONTROL 161

1-230 V ±10%

ARCONTROL 201

Frequency 50/60 Hz 50/60 Hz

Rated Input Power 8,2 kW (MMA)

5,5 kW (TIG) 10,6 kW (MMA)

7,1 kW (TIG)

Rate Input Current 35,6 A (MMA)

26,3 A (TIG) 46,0 A (MMA)

31,0 A (TIG)

Duty Cycle

(40°C 10 min) 160 A (40%)

135 A (60%)

105 A (100%)

200 A (30%)

145 A (60%)

110 A (100%)

No Load Voltage 70,8 V 63,0 V

Welding Current Range 10-160 A 10-200 A

Efficiency 80% 80%

5/68

The above parameters are subject to change with the improvement of machines.

The working principle of ARCONTROL (See Pic. 1 at the end of this manual).

The single-phase 230 V alternating current with 50/60 Hz working frequency is rectified into direct current (about 312V),

then it is converted into a medium frequency alternating current (about 50 KHz) by the inverter device (IGBT module).

The voltage is then reduced by the medium transformer (the main transformer) and rectified by the medium frequency

rectifier (fast recovery diodes) and is then outputted by inductance filtering. The circuit adopts the current feedback

control technology to ensure the stability of the current output. In this way the welding current parameter can be set by a

stepless adjustment to better meet the welding requirements.

ARCONTROL welding machines have excellent volt-ampere characteristic (See Pic. 2 at the end of this manual).

In MMA welding, the relation between the rated loading voltage U2 and welding current I2 is as follows:

See Pic. 3 at the end of this manual

Manual Metal Arc welding (MMA)

The choice of connecting the electrode to the Positive (DCEP) or Negative (DCEN) polarity depends on the type of

electrode. The different electrodes must be connected differently. Please refer to the electrode manual.

See Pic. 4 at the end of this manual

Connect the electrode lead and the earth lead to the proper output and tighten clockwise.

Ensure good contact and prevent oxidation.

Check the input voltage is within the range by measuring with a multimeter.

Power Factor 0,6 0,6

Model

Connections DINSE 25mm2

ARCONTROL 161

DINSE 35mm2

ARCONTROL 201

Protection Class IP21S IP21S

Insulation Class H H

EMC Classification A Class A Class

Cooling Automatic Fan Automatic Fan

Dimensions 335 ×114 ×205 mm 335 ×114 ×205 mm

Net Weight 4,7 kg 4,7 kg

Electrode Diameter ø1.6 - ø3.2 ø1.6 - ø4.0

Electrode Type 6013, 7018, etc. 6013, 7018, etc.

Negative polarity output terminal (-)

Digital display

Welding Type Switch

MMA - Choose (right)

TIG - Choose (left)

Positive polarity output terminal (+)

Power led

When the LED is on indicates that the machine is on.

Alarm led

When the LED is on indicates that the protection of

the machine has been activated.

5Power switch (Main switch)

Fan

Welding current adjustment knob

Turn this knob to adjust the output current.

6/68

Tungsten Inert Gas Welding (TIG)

For TIG welding operations the TIG torch must be connected to the Negative polarity (DCEN) while the ground cable to

the Positive polarity.

During TIG operation, the shielding gas is fed directly into the welding torch, and the "lifting arc" striking method must be

adopted.

See Pic. 5 at the end of this manual

Connect the torch cable and the grounding cable to the proper output and tighten clockwise.

Ensure good contact and prevent oxidation.

Check the input voltage is within the range by measuring with a multimeter.

Turn the power switch to the “ON” position. The power indicator on the front panel lights up, the fan turns on, the

device is working properly.

Select the welding mode according to your welding method by switching the mode selector (MMA or TIG).

ARCONTROL welding machines have the function of welding current pre-setting. Before welding, adjusting welding

current, the welding current display will show the ampere. It is convenient to set parameters and adjust accurately.

In MMA welding set the welding current relevant to the electrode type and size being used as recommended by the

electrode manufacturer.

In TIG welding set the welding current relevant to the electrode type and size being used according to standard ISO 6848.

Manual Metal Arc welding (MMA)

See Pic. 6 at the end of this manual

Tapping technique: Hold the electrode upright and touch the workpiece. After forming a short circuit, quickly lift up

about 2~4 mm, and arc will be ignited. This method is difficult to master. But in welding brittle or hard steel, it is better

to use knocking way.

Take the electrode upright

The Electrode touch the workpiece

Lift up for about 2-4mm

Scratching technique: Hold the electrode and scrape the workpiece to strike the arc. This method can cause

scratches, so it is advisable to use it into the groove.

Hold the electrode inclined at an angle.

Scrape the workpiece with the electrode and strike the arc

Lift up for about 2-4mm

Tungsten Inert Gas Welding (TIG)

When tungsten electrode touches the workpiece, the short-circuit current is 100A. After generating arc, current turn to the

setting welding current. If the tungsten electrode touches the workpiece when welding, the current will drop to 30A within

1s, which can reduce the tungsten spoilage significantly, prolong the using life of the tungsten electrode, and prevent

tungsten clipping.

See Pic. 7 at the end of this manual

TIG Lift: Place the welding gun aslant.

Scrape the workpiece with the electrode.

Lift arc.

Complete the operations.

After welding is completed, the power supply should be left ON for 2 to 3 minutes. This allows the fan to cool the internal

components.

Switch the ON/OFF Switch (located on the rear panel) to the OFF position and turn off the machine.

Height above sea level is below 1000m.

Operation temperature range: -10°C~+40°C.

Relative humidity is below 90% (+20°C).

Preferably place the machine at an angle not exceeding 15° compared to the floor level.

Protect the machine against heavy rain or in hot circumstance against direct sunshine.

The content of dust, acid, corrosive gas in the surrounding air or substance cannot exceed normal standard.

Take care that there is sufficient ventilation during welding. There is at least 30cm free distance between the machine

and wall.

The input power must be in AC single phase, 50Hz, 220/230V. Do not operate in case of phase failure.

In case closing the power switch, no-load voltage may be exported. Do not touch the output electrode with any part of

your body.

7/68

When power switch shuts off protectively because of failure, do not restart the unit until problem is solved. Otherwise,

the range of problem will be extended.

Note the polarity of wiring. Select the appropriate connections based on the welding technical requirements. An

incorrect choice will result in arc instability, increase in spatters and other phenomena.

If the workpiece is very far from the welding machine, the use of longer cables (electrode holder and ground) may

result in a voltage drop. In this case it is necessary to use cables with a larger cross-section.

The duty cycle is defined as the proportion of time that a machine can work continuously within a certain time lapse

(10 minutes). The rated duty cycle means the proportion of time that a machine can work continuously within 10

minutes when it outputs the rated welding current. If the welding machine overheats, the IGBT overheat protection unit

inside cuts the output welding current, and the overheat pilot lamp on the front panel lights up. At this point, the

machine should be left to stand for 15 minutes so that the fan can cool it. When operating the machine again, the

welding output current or the duty cycle should be reduced.

The electrode should be dried before use to reduce the presence of hydrogen in the molten pool and the welding bead

and to avoid blowhole and cold cracks.

In the welding process, the arc should not be too long, otherwise it would cause unstable arc burning, a wider area of

spatters, poor penetration, undercut, blowhole, etc. If the arc is too short, this will cause electrode sticking.

DEFECT NAME

Welding seam

does not meet

the requirements

The groove angle is not perfect

The root face and assembly gap are equal

Welding technics parameters are unreasonable

The welder’s operation skill is lower

CAUSED REASON

Choose the proper groove angle and the

assembly gap, improve the assembly quality

Choose the proper welding parameters

Improve the operation skill of welders

PREVENT METHODS

Undercut Over current

Arc length is too long

The electrode angle is wrong

Manipulation of electrode is not proper

Choose the proper welding current & speed

The arc can’t be drawn too long

The electrode angle should be proper

Manipulation of electrode should be correct

Incomplete

penetration The groove angle or gap is too small, the root

face is too big

Welding parameters are not suitable, or the

assembly is not good

The welder’s operation skill is lower

Choose and correctly process the groove size

Assemble correctly and ensure clearance

Choose the suitable welding current & speed

Improve the operation skill of welders

Incomplete fusion The welding thermal input is too low

The arc direction is lean

There are rust & dust on the side of groove

The slag between the layers is not cleared well.

Choose correctly the welding parameters

Operation seriously

Enhance the clearness of layers

Overlap The temperature of molten pool is too high

The liquid metal concretes slowly Choose parameters based on the welding

different position

Strictly control the molten hole size

Crater The crater time lasts too short

Over current in the welding of thin plate The electrode must stay in the crater for a short

time or be handled with circular movements

After the molten pool is filled in with metal, work

on the side of the crater.

Blowhole There are some dust like oil, rust or water on

the work piece surface and groove

The coating of electrode is damped & is not

drying

Under current or over speed in the welding

The arc is too long or lean burning, the molten

pool protection is not good

Over current, the coating of electrode falls off

and lose protection

Manipulation of electrode is not proper

Clear out the dust around groove for about

20~30mm

Strictly dry the electrode according to manual

Choose the proper parameters and operate

correctly

Use the short arc operation

Welding operation in the field should have anti-

wind protection

Don’t use the invalid electrode

8/68

In order to guarantee that arc welding machine works high-efficiently and in safety, it must be maintained regularly. Let

customers understand the maintenance methods and means of arc welding machine more, enable customers to carry on

simple examination and safeguarding by oneself, try one’s best to reduce the fault rate and repair times of arc welding

machine, so as to lengthen service life of arc welding machine. Maintenance items in detail are in the following table.

Warning: For safety while maintaining the machine, please shut off the supply power and wait for 5 minutes, until

capacity voltage already drops to safe voltage 36V.

Observe that whether panel knob and switch in the front and at the back of arc welding machine are flexible and put

correctly in place. If the knob has not been put correctly in place, please correct; If you can’t correct or fix the knob,

please replace immediately;

If the switch is not flexible or it can’t be put correctly in place, please replace immediately; Please get in touch with our

company maintenance service department if there are no accessories.

After turn-on power, watch/listen to that whether the arc welding machine has shaking, whistle calling or peculiar smell.

If there is one of the above problems, find out the reason to get rid of; if you can’t find out the reason, please contact

local this area our company agent or the branch company.

Observe that whether the display value of LED is intact. If the display number is not intact, please replace the

damaged LED. If it still doesn’t work, please maintain, or replace the display PCB.

Observe that whether the min/max value on LED accords with the set value. If there is any difference and it has

affected the normal welding craft, please adjust it.

Check that fan is not damaged and is normal to rotate or control. If the fan is damaged, please change immediately. If

the fan does not rotate after the arc welding machine is overheated, observe that whether there is something blocked

in the blade, if it is blocked, please get rid of; If the fan does not rotate after getting rid of the above problems, you can

poke the blade by the rotation direction of fan. If the fan rotates normally, the start capacity should be replaced; If not,

change the fan.

Observe that whether the fast connector is loose or overheated. if the arc welding machine has the above problems, it

should be fastened or changed.

Observe that whether the current output cable is damaged. If it is damaged, it should be replaced, insulated or changed.

Using the dry compressed air to clear the inside of arc welding machine. Especially for clearing up the dusts on

radiator, main voltage transformer, inductance, IGBT module, the fast recover diode and PCB, etc.

Check the bolt in arc welding machine, if it is loose, please screw down it. If it is skid, please replace. If it is rusty,

please erase rust on bolt to ensure it works well.

Check that the actual current corresponds to the displayed value. Otherwise, perform the necessary adjustments. The

actual current value can be measured by means of an adjustable plier-type ammeter.

DEFECT NAME CAUSED REASON PREVENT METHODS

Inclusion & slag

inclusion The slag clears bad in the middle layer in the

welding process

Under current or over speed in the welding

Welding operation is not proper

The welding material cannot match the work

piece

The groove design & processing are not proper

Choose the electrode with an easy slag

removal

Strictly remove the slag in the layers

Choose the welding parameters correctly

Adjust the electrode angle and manipulation

way

Hot crack In the process of solidification, the inter crystal

segregation is seriously caused. At the same

time, with the effect of welding stress, the hot

crack is formed

Strictly control the percentage of S and P in

welding material.

Adjust the structure of welding material.

Adopt the basic electrode.

Cold crack Three reasons will cause cold crack:

The structure turned from the marten site

The residual stress caused by big restraint

intensity

The residual hydrogen in welding gap.

Adopt low hydrogen type basic electrode.

Bake under the instruction before use.

Remove the feculence before use, reduce the

percentage of hydrogen

Adopt appropriate parameters and heat input

After welding, do dehydrogenation at once.

9/68

Measure the insulating impedance among the main circuit (PCB) and the case, if it is below 1MΩ, the insulation is

thought to be damaged and need to be changed or reinforced.

EMC - In particular situations, the device could be affected by electromagnetic interferences caused by other devices

nearby (eg: Safety devices, Power line, Signal and Data transmission lines, telecommunication equipment, TV and radio,

etc.). In this condition, the operator should adopt some appropriate measures to remove interference (shieldings, filters,

shorter cables, grouping cables, improved grounding, etc.).

Before arc welding machines are dispatched from the factory, they have already been debugged accurately. So forbid

anyone who is not authorized by our company to do any change to the equipment!

Maintenance course must be operated carefully. If any wire becomes flexible or is misplaced, it maybe potential

danger to user!

Only professional maintenance personal who is authorized by our company could overhaul the machine!

Guarantee to shut off the arc welding machine’s power before open/unfasten the outer case of the equipment.

If there is any problem and has no the authorized professional maintenance personal of our company, please contact

local our company agent or the branch company!

Trouble

Turn on the power source,

and fan works, but the

power light is not on

The power light is damaged or the

connection is not good

Cause

Power PCB failures

Test and repair the inside circuit of power

light Pr3

Remedy

Repair or change power PCB Pr2

Turn on the power source,

and the power light is on,

but fan doesn’t work

There is something in the fan

The fan motor damaged

Clear out

Change fan motor

Turn on the power source,

and the power light is not

on, and fan doesn’t work

No input voltage

Overvoltage (Input voltage is too much or

not)

Check whether there is input voltage

Check input voltage

No no-load voltage output There is trouble inside the machine

Welding cable is not connected with the two

output of the welder.

Check the main circuit, Pr1 and Pr2

Connect the welding cable to the welder’s

output

No current output in the

welding

Welding cable is broken Wrap, repair or change the welding cable

Earth cable is not connected or loosen Check the earth clamp

The plug loosen or connect not well Check and tighten the plug

Not easy to start arc in the

welding, or easy to cause

sticking Oil or dust covered the workpiece Check and clear out

MMA/TIG welding selection is wrong Selecting the MMA welding

Increase the arc force

The arc is not stable in the

welding process The arc force is too small

Repair or change the potentiometerThe welding current cannot

be adjusted The welding current potentiometer in the

front panel connection not so good or

damaged

The welding current adjusted too low Increase the welding current

The penetration of molten

pool is not enough(MMA) The arc force adjusted too small Increase the arc force

Arc blow Airflow disturbance

The electrode eccentricity

Use the shelter from airflow

Adjust the electrode angle

Magnetic effect

Change the electrode

Incline the electrode to the opposite way of

the magnetic blow

Change the position of earth clamp or add

earth cable in the two side of workpiece

Use the short arc operation

1 0/68

Storage temperature : -20°C ~ +70°C (-4°F ~ +158°F).

It is advisable to store and transport the device in its original packaging.

This device meets the requirements of the Environmental Protection Directives (2011/65/EU, 2012/19/EU) and

their amendments.

At the end of the products life cycle it must be disposed of according to the regulations concerning special waste

collection as it cannot be treated as normal urban refuse. The product is made up of materials that are both non-

biodegradable and of potentially polluting substances to the environment if not disposed of correctly

Manufactured in China by Shanghai HI-ZONE Welding Equipment Manufacture Co., Ltd. Distributed by GCE.

GCE guarantees this product for 24 (twenty-four) months or in accordance with statutory warranty rights, from the date of

delivery, against faulty design, material, and workmanship.

GCE shall not be liable for loss of production, loss of profit or any other consequential damage or indirect loss. In the

event of any fault in the goods due to defective design, materials or workmanship, the liability of GCE is limited to

reparation or replacement of this good, provided that written notification is given to GCE within three months of the date

of delivery or deemed delivery. GCE cannot be held liable if the product is modified, serviced or repaired by personnel not

authorized by GCE or if the apparatus is used in a manner not conforming to its intended use. GCE cannot be held

responsible for the misuse of the equipment in case of non-application of the instructions for use.

The alarm light is on Over heat

protection

Over current

protection

Induce the welding current output

Induce the duty cycle (interval work)

Test and repair the main circuit and drive

PCB (Pr1)

Over welding current

Working time too long

Unusual current in the

main circuit

Trouble Cause Remedy

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels GCE Système de soudage

GCE

GCE LORCH PROPALINE LOMEN Manuel utilisateur

GCE

GCE KOMBI 17 Manuel utilisateur

GCE

GCE U7 Manuel utilisateur

Manuels Système de soudage populaires d'autres marques

Berner

Berner PLASMACUT 54 Manuel utilisateur

Pro Spot

Pro Spot PR-155 Manuel utilisateur

Forney

Forney 210 Manuel utilisateur

Thermal Arc

Thermal Arc 400S Manuel utilisateur

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manuel utilisateur

GYS

GYS PROTIG 201 AC/DC Manuel utilisateur

TAFA

TAFA 30*8B35 Manuel utilisateur

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manuel utilisateur

ESAB

ESAB Buddy Arc 145 Manuel utilisateur

CIGWELD

CIGWELD 636804 Guide rapide

Red-D-Arc

Red-D-Arc DC-400 Manuel utilisateur

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manuel utilisateur

Elettro

Elettro HI-MIG 3000 SYNERGIC Manuel utilisateur

WIA

WIA Weldmatic 270 CP132-2 Manuel utilisateur

Sonics

Sonics H520T Manuel utilisateur

Miller

Miller Big Blue 400D Manuel utilisateur

NewArc

NewArc RT2000 Guide de démarrage rapide

Hypertherm

Hypertherm powermax1000 Manuel utilisateur
