Operation Instruction

PUMA

Thank you for your purchase the PUMA Touch Screen

Universal Remote Control. The

universal remote control has the stylish design with transparent

buttons and shiny surface, it contains one

of the largest infrared code library obtainable in Europe for 4

different devices.

For preprogrammed code, all you have to do is to choose the

device which you wish to control (for

example TV) and it’s 3-digit code numbers from the brand

code list (for example 003 under Lifetec TV).

After you set up . it will remember all the data what you set up

permanently even you remove the batteries

later.

The 4 in 1 universal remote control is suitable for practically

almost all common brands of television set ,

DVR and DVD player (DVD), digital and analogue satellite

receiver and cable box and DVB, viedeo

rcorder (VCR), It can operate all main functions of your

device.

You can use Auto Search to scan the code library in case of

you can’t find your device brand in the code

list.

Besides,this universal remote control also can learn a new

code from a original remote control to

supplement the codes in case of it’s shortage.

Volume lock can fix VOL+/VOL- button to only control

amplifier for your home theater.

Device lock can fix the device against changing by a new set

up until you unlock it.

Macro function makes several sequent operations with one

button for your home theater.

All the set up data will be stored in back up memory

permanently, you don’t need to be worry about data

loss when you replace battery.

Please enjoy the time with this new intelligent touch screen

universal remote control.

Device Code Assignment

Bank for Device Initial code Set-up confine Total of codes

TV TV 042 001-383 383

VCR VCR 026 001-172 172

CBL/SAT Satellite，Cable Box,DVB 251 001-341 341

DVD DVD,DVR 012 001-180 180

Total codes:1645

Realize the Buttons

SET—For you start to set up the universal remote control.

Learn—Used to setup learning functions.

Light Lets you control the touch screen back light.

TV、VCR、CBL/SAT,DVD、—Let you select the device you

want to control.

POWER—Turns the device on and off .

0-9—The number keys operate the same as on your original

remote control, and maybe also used for

entering device codes when set up.

ENTER—Works like as the entering on your original remote.

TV/AV—Works like the TV/Video key on your original TV

remote, and TV/SAT key on your original

satellite remote A.B in cable and CD modes.

MENU —Works like the Menu or OSD (on-screen display) or

Memory key on your original remote

control.

CH± —Works like the Channel Up and Down keys on your

original remote control.

VOL± —Control the volume like the Volume Up and Down on

your original remote control.

Mute To mute the sound

REW（fast reverse）

PLAY (operate your DVD, CD etc)

FFWD (fast forward)

REC (Record)

STOP (terminating your operation)

PAUSE

，OK，EXIT Works like as the

UP，DOWN，LEFT，RIGHT，OK，EXIT Keys

on your original remote control for menu function .

RED，GREEN，YELLOW and BLUE: for TV Fast Text.

Television video

TV and text mixed

Teletext mode

Page hold

M1,M2, Lets you make sequent operation for you home

theater.

Set up

Make sure that 3 new batteries have been inserted correctly

into your new universal remote control unit.

To make your remote control ready for use, you need to carry

out one of the following steps:

A. Set up by Brand Code

1. Switch on the device, which you would like to control (e.g.

TV set).

2. In the back section of this manual, find out the correct brand

name and code no. in the code list for your

device what you want to control (e.g. Lifetec 003,010,062, …).

Note: the codes must be in the column for the corresponding

device group (TV).

3. Hold down the SET key and actuate the device key (e.g.

TV1) at the same time. The LED will be on at

the moment. Then release the pressed both keys.

4.You must enter into the 3-digit device code (e.g. 003 for

Lifetec TV) within 10 seconds now. If no entry

within 10 seconds, the setting up mode is terminated

automatically.

5.The LED goes out if the code has been accepted by the

universal remote control. If the LED flashes twice,

that means the code may be wrong, and the universal remote

control remains in set-up mode, you should

enter into the correct code from the list again in time.

6.Check the function of the keys on remote control. If most of

keys on your new remote control do not

function correctly, try another 3-digit device code (e.g. 010…)

from the list under the same brand.

Repeat step 3 to 6 until all the basic functions operate correctly.

Once you satisfy the code, that means you have already got

correct set up for the device.

Remark: To leave set up mode, press the device key (e.g.

TV1). Or if you do not actuate any keys

within 10 seconds, it will be terminated automatically.

You may set up more than one device on the new remote

control. Before you operate your new

remote control, please press the requested device key first (e.g.

TV1), so the remote control is surely at

the proper device status, otherwise it may control the wrong

device which did not requested by you.

B. Set up by Automatic Search

If setting up by brand name and codes is unsuccessful, or you

can not find your brand name in the list,

you can use the Automatic Search to find the correct code for

your remote control.

1.Switch on the device that you like to control. If it is a video

recorder, please insert a video cassette.

2.Point the remote control at your device. Press the SET and

the device (e.g. TV) keys

simultaneously and hold them down for 3 seconds. Then the

LED flashes, that means it is in Automatic

Search now.

3.The OFF signal is automatically transmitted to the device

from the remote control (code scan). Once the

device (e.g. TV) switches off, immediately press any key

(except SET key) to stop the Automatic

Search.

4.Switch on the device again by pressing the POWER key.

Check the function of the other keys on the

remote control. If all the keys do not function (that means you

may not stop the search in time), or most

of keys’ operation is not good enough, you can start the search

again (see steps 2–4) to find out a

suitable code to fit your device completely.

If most of keys’ function properly, that means your setting up

is successful, press the device key (e.g.

TV1) again to save the code and finish the set up.

Remark: To abort the Automatic Search, press any key

(except set key). The LED lamp will go out and

the search is terminated. When remote control searches through

all different type of codes, and the LED

will turn off, then the remote control will quit from search

process automatically.

C. Setting up by Manual Search

If setting up with brand name and codes is unsuccessful, you

can also use the Manual Search to find the

correct code for operating your device.

1.Switch on the device that you like to control. If it is a video

recorder, insert a video cassette.

2.Point the remote control at your device. Press down and hold

the SET key and press the device key (e.g.

TV) in a short time (less than 3 seconds, otherwise it goes to

Automatic Search), then release the both

keys pressed.

3. The LED will be on at the moment and the remote control is

then in setting-up mode.

4.Actuate the POWER key (ON/OFF key) about every 2

seconds. (If the device being sought is a video

recorder, DVD player, CD player, AUX etc., you can press the

PLAY button also.), the device button

now flashes, that means it is in Manual Search mode.

5.Once the searched device switches off (or react), test the

functions of other keys (don’t press POWER

key, in case it goes to next code) on the remote control. If most

of them do not function properly, press

the POWER key about every 2 seconds again to search the next

reactive code (continues the Manual

Search, see step 4-5).

If you feel most of keys on the remote control work good

enough, you can save the code by pressing

the device key (e.g. TV) to finish the Manual Search.

Remark: The Manual Search will be automatically terminated

if no entry within 30 seconds.

D. Set up by Learning

The LEARNING function is used to supplement the

preprogrammed codes. The standard code list may

provide most of functions needed, but you can add a small

number of additional functions on it. Or you can

add a new code from a original remote control which is

shortage in the code list.

In learning mode, you must prepare a another original remote

control from where you will take the codes.

Please use fresh batteries for both the Learning Remote Control

and the Original Remote Control.

1.Press down and hold the Learn key and press the device

what you wanted to learn(e.g. DVD), then

release the both pressed keys. The LED on your new remote

control blinks and then the remote control is

in learning mode for DVD codes.

2. Press and release the target button which you want to learn

(e.g.POWER), the LED lights up.

3. Point the original remote control to the receiver LED(as the

same as it’s transmitter LED) on your new

remote control, the both remotes facing each other by

approximately 30mm apart.

4. Press and hold the source button on your original remote

control (e.g.POWER) until the LED on your

new remote control blinks 2 times and lights up 2 seconds, then

blinks again. (That means you have

learnt POWER singnal from the original remote,and you new

remote control is in learning again for next

learning.) If there is a learning problem, the light blinks 4 times

and lights up for 2 seconds then blinks,

(That means you failed to learn POWER singnal from the

original remote, and your new remote control

is in learning again for next learning.)

5. Repeat Step 2 to 4 to learn more bottons.

Remark:

1. If you want the learning mode to be exited, Press and release

Device key.

2. In learning mode .you must be less than 30 mm between 2

remotes, and the 2 remotes must be put in a

straight line.

3. It will eixt the learning mode if you don’t press any key in

30 seconds .

4. You can press SET and 4 together to delete all buttons you

have learnt under the device button, the LED

will flash 2 times to confirm it.

5. If the memory is full, LED blink 4 times then quit for

learnning.

6. The last singal learnt will overwrite the previous signal.

7. About 100 commands can be stored in this remote control

and about 40 commands can be learnt for one

device.

Other Functions

A. Display the Device Code:

The device codes, which has been set up in your new remote

control, can be called up

as following:

1. Press the SET key and hold it down, now actuate number

key 1 to display the 100th position of the 3-

digit code. Count the numbers when the LED flashes. If the

LED doesn’t flash, that means the digit is

ZERO.

2．Similarly, press the SET key and hold it down, at the same

time actuate number key 2 to display the

10th position of the 3-digit code.

3．Press the SET key and hold it down, at the same time

actuate number key 3 to display the 1st position of

3-digit code.

Example for Code 108:

1. Press SET and ―1‖

LED flashes 1 time.

2. Press SET and ―2‖

LED flashes 0 times , no flashes.

3. Press SET and ―3‖

LED flashes 8 times.

B. Volume lock

This function makes you very convenient when you only use

one device to adjust volume. For example,

you may use your amplifier as your main volume control, then

you can use this function to fix the volume

and mute key to AMP, no matter which device you used (even

you use TV1, DVD, VCR etc), the volume

and mute key on remote control still control the volume and

mute of your amplifier.

1. Press the device button which you want to lock. E.g. AMP

2. Press SET and 5，the current VOL and mute will be locked,

LED flashes two times to confirm it.

Remark: you can press SET and 6 to unlock it.

C. Write-protection of Device Codes:

To protect the device codes from being inadvertently

overwritten / deleted, you can carry out the

following:

1. Press the device key (e.g. TV) that you would like to protect

on your remote control.

2. Press and hold down the SET key and press the 7 key at the

same time. Then release the both pressed

keys, the LED will flash twice and the code is then protected

from being overwritten/deleted.

Note: To cancel write protection,please press the SET key and

hold it down, and activate the 8 key at the

same time, and then release the both pressed keys. The LED

flashes twice and the protection have been

cancelled.

D．Set up Macro:

Macro function let you make sequent operation for you home

theater. Please press M1 key ( or M2 key),

and then release it. The remote control will send out a sequent

IR commands that you programmed before.

You can set up a Macro by following below steps:

1. Press and hold down the SET key and press the M1 key at

the same time. then release it and the LED on

that means it is in the setting up mode.

2. You can select the device and function key for a sequent

operation what you enjoyed. (e.g.:

TV+POWER+MUTE+TV/AV, DVD+PLAY,

VCR+RECORD, etc. That means you want to turn on

the TV and shut off its sound, switch TV and input to AV port,

DVD start to play disc, VCR begins to

record at the same time. )

3. Press the M1 key to save the setting, LED then exit to

current setup state.

E．Reset / Delete Function:

To delete the codes which have been set up in the remote

control, press and hold down the SET key, then

press the 0 key simultaneously for more than 3 seconds and

then release the both pressed keys. The LED

will flash twice and all the set up data and all learn commands

in the remote control are deleted.

Remark: Please don’t operate this function if you don’t want to

delete all the settings.

Istruzioni per l’uso

PUMA

Grazie per aver acquistato il Telecomando Universale PUMA

Touch Screen. Il telecomando universale ha un elegante design

con tasti trasparenti e superficie brillante, contiene uno dei

maggiori pacchetti di codici che si possono ottenere in Europa

per 4 diversi apparecchi.

Per il codice preprogrammato, tutto quello che dovete fare è

scegliere l’apparecchio che intendete controllare (ad esempio la

TV) e i suoi numeri di codice a 3 cifre dalla lista dei codici

delle marche (ad esempio 003 sotto Lifetec TV).

Dopo la configurazione, tutti i dati configurati rimarranno in

memoria permanentemente, anche se rimuoverete le batterie.

Il telecomando universale 4 in 1 è adatto praticamente per tutte

le comuni marche di apparecchi televisivi, lettori DVR e DVD

(DVD), ricevitori satellitari digitali ed analogici e cable box e

DVB, videoregistratori (VCR). Può controllare tutte le

principali funzioni dei vostri apparecchi.

Potete usare la Ricerca Automatica per fare la scansione del

pacchetto di codici nel caso non riusciate a trovare la marca del

vostro apparecchio nella lista dei codici.

Inoltre, questo telecomando universale può anche imparare un

nuovo codice da un telecomando originale per incrementare i

codici in caso di indisponibilità.

Volume lock può bloccare il tasto VOL+/VOL- per controllare

solo l’amplificatore del vostro home theater.

Device lock può bloccare l’apparecchio per evitare una nuova

configurazione a meno che non venga disattivata questa

funzione.

La funzione Macro esegue diverse operazioni consecutive con

un tasto per il vostro home theater.

Tutti i dati configurati saranno conservati nella memoria di

back up permanentemente, non dovrete preoccuparvi di

eventuali perdite di dati quando sostituirete le batterie.

Godetevi il nuovo telecomando universale intelligente touch

screen.

Assegnazione Codice Apparecchio

Serie per Configurazione iniziale Codice Apparecchio confine

Totale codici

TV TV 042 001-383 383

VCR VCR 026 001-172 172

CBL/SAT Satellite, Cable Box, DVB 251 001-341 341

DVD DVD,DVR 012 001-180 180

Totale codici:1645

Spiegazione dei tasti

SET—Per iniziare a configurare il vostro telecomando

universale.

Learn—Si usa per configurare le funzioni di apprendimento.

Light Permette di controllare la retroilluminazione del touch

screen.

TV, VCR, CBL/SAT, DVD —Permette di selezionare

l’apparecchio che si intende controllare.

POWER—Accende e spegne l’apparecchio.

0-9—I tasti numerici hanno la stessa funzione del vostro

telecomando originale, e possono essere usati anche per

inserire i codici degli apparecchi durante la configurazione.

ENTER—Funziona come il tasto enter del vostro telecomando

originale.

TV/AV—Funziona come il tasto TV/Video del vostro

telecomando TV originale, e come il tasto TV/SAT del vostro

telecomando originale per il satellite A.B nelle modalità cavo e

CD.

MENU —Funziona come il tasto Menù o OSD (on-screen

display) o Memory del vostro telecomando originale.

CH± —Funziona come i tasti Channel Up e Down del vostro

telecomando originale.

VOL± —Controlla il volume come i tasti Volume Up e Down

del vostro telecomando originale.

Mute Per attivare la modalità silenziosa.

REW (indietro veloce)

PLAY (avvia il vostro DVD, CD etc)

FFWD (avanti veloce)

REC (Registrazione)

STOP (termina le operazioni)

PAUSE

，OK，EXIT Funziona come i tasti

UP，DOWN，LEFT，RIGHT，OK，EXIT del vostro

telecomando originale per le funzioni del menù.

ROSSO，VERDE，GIALLO e BLU: per Televideo.

Television video

TV e testo misto

Modalità Teletext

Mantieni pagina

M1, M2, Vi consente di eseguire operazioni consecutive per il

vostro home theater.

Set up

Assicuratevi di aver inserito 3 batterie nuove nel vostro nuovo

telecomando universale

Perché il vostro telecomando sia pronto per l’uso, dovrete

effettuare una delle seguenti operazioni:

Table des matières

Langues :

Autres manuels GBS Elettronica Télécommande

GBS Elettronica

GBS Elettronica Universal S Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
