Specifications for the Gateway Solo™ 3150 Notebook

Processor and Core Logic

Processor Options

Intel Mobile Pentium®II at 233, 266/266PE, 300/300PE, 333, or 366 MHz

Intel Mobile Pentium®with MMX™Technology at 233 or 266 MHz

Mobile Intel®Celeron™ at 266 or 300 MHz

Cache

Intel 233/266/300 Mobile Pentium II: external 512K SRAM pipelined burst L2

Intel 266PE/300PE/333/366 Mobile Pentium II: on-die 256K L2

Intel 266/300 Mobile Celeron: on-die 128K L2

System Clock Frequency

60/66 MHz

BIOS

Phoenix Plug and Play NoteBIOS with ACPI 1.0 support, SMBIOS 2.1, 512K

flash ROM

System Memory 32 MB SDRAM standard. One additional SO-DIMM socket accepts 16, 32,

64, or 128 MB SDRAM module for a maximum capacity of 160 MB.

LCD Display Panel 12.1-inch active matrix TFT color LCD. Maximum resolution = 800×600.

Maximum color depth = 262,144 colors (18-bit).

Video

Video Subsystem

NeoMagic MagicMedia 256AV High Performance Multimedia Flat Panel/CRT

graphics controller with Microsoft DirectX and DDC support

Video Memory

2.5 MB integrated SDRAM

External Video

Supports simultaneous LCD/external monitor. Supports XGA, SVGA, VGA.

Internal LCD Panel Resolutions

800×600 and 640×480 with 262,144 colors (18-bit)

Zoomed Video

PC Card connection to Zoomed Video port in PC Card slot

Composite Video Output Port NTSC/PAL TV Out on optional port replicator

4332.fm Page 1 Thursday, April 15, 1999 10:46 AM

2 Update

Audio

Sound Support

16-bit stereo, full duplex with two DMA channels. OPL3 (FM synthesizer).

3D-enhanced controller. Sound Blaster Pro 3.01 game playback

compatibility.

Compression

ADPCM, ESPCM compression available for lower bit rates

Volume Control

Volume control wheel on right side of notebook provides full analog control.

Internal Interface Components

Omni-directional, low-impedance microphone above keyboard. Stereo

speakers built into palm rest. Stereo Headphone Out port on rear panel.

Input/Output (I/O)

Keyboard

13-15 mm keys with 3 mm travel. Windows 95/Windows 98 keys. US, UK,

German, French, and Japanese available (International keyboards available

only outside U.S.)

Pointing Device

EZ-Point®

I/O Ports and Connector

USB. Fast IR (not available while docked). High-speed serial

(16550A-compatible). Parallel (bi-directional, EPP, ECP). PS/2 keyboard or

mouse. DC input. Replicator connector. Type I or II PC Card socket.

XGA/SVGA/VGA external monitor. Stereo Headphone Out. Modem RJ-11.

Ethernet RJ-45.

Controller

TI-1210 with Zoomed Video support and CardBus support

Modem 56K data/fax, V.90, RJ-11 port

Network 3Com, Ethernet 10/100, RJ-45 port, internal, remote Wake Up support,

Managed PC Boot Agent (MBA)

Storage

Hard Disk Drive

User-removable. Accepts 2.5-inch 12.7 mm hard disk drive; 2 GB, 4 GB, and

6.4 GB capacities available. Controller uses two independent bus mastering

EIDE channels on PCI bus. Supports PIO and Bus Master DMA transfers up

to 16.6 MB/sec. and Bus Master Ultra ATA transfers up to 33 MB/sec.

3.5" Diskette Drive

External drive reads and writes to 3.5" diskettes up to 1.44 MB capacity.

CD-ROM Drive

8-20x, EIDE interface, full stroke access time 150 ms (at 20x speed), 128K

data buffer, CD-enhanced compatible

DVD-ROM Drive (optional)

CAV, 1-20x DVD mode, 8-20x CD-ROM mode. 128K data buffer.

4332.fm Page 2 Thursday, April 15, 1999 10:46 AM

Specifications for the Gateway Solo™ 3150 Notebook 3

Specifications are subject to change without notice or obligation.

Power

AC Adapter

2-pin AC inlet, 19 VDC, 50 W output. Automatic voltage adjustment between

100 and 240 VAC.

Battery Type

Removable intelligent Li-Ion, 8 cells. Internal bridge battery allows main

battery swapping when Solo 3150 is in Standby mode.

Battery Capacity

40.33 WHrcapacityprovidesapproximately3.5hourscapacity,dependingon

use.Three-hourchargingtime.Batterylifevariesdependingonconfiguration,

applications, power management settings, and features utilized.

Power Management

ACPI V1.0 support. Suspend mode lasts for about one week with a fully

charged battery.

Docking Optional Solo port replicator provides Serial, Parallel, VGA out, AC in, Line

out, Microphone in, Headphones/speakers out, PS/2 keyboard, PS/2 mouse,

modem (RJ-11), and Ethernet (RJ-45). Cold, warm, and hot docking

supported in Windows®95 and Windows®98. Cold docking supported in

Windows®NT.

Security Passwords: power-on password (2-level password support) and HDD access

password. Physical security: RAM and HDD screws and cable lock slot.

System Software Windows 95, Windows 98, or Windows NT 4.0

Physical Specifications

Dimensions

285 (W) × 213 (D) × 31 (H) mm

11.2 (W) × 8.4 (D) × 1.2 (H) inches

System Weight

4.6 lbs. (2.1 kg) to 5.2 lbs. (2.4 kg), depending on configuration

AC Adapter Weight

14.6 ounces (415g)

Environmental Tolerances

Temperature

Operating: 32° to 95° F, 0° to 35° C. Storage: -13° to 140° F, -25° to 60° C

Humidity

Operating: 20% to 80% RH, no condensation. Storage: 15% to 98% RH, no

condensation

Vibration

Operating: 5-500 Hz, 0.5 G acceleration, 1 oct/min., 15 min dwell at all

resonance points. Non-operating: 5-500 Hz, PSD 0.015G2/Hz, 2.16Grms,

200-500 Hz, -6dB/octave on 3 axis, 2 hours/axis

4332.fm Page 3 Thursday, April 15, 1999 10:46 AM

4 Update

MAN SYS US SL3150 SPEC UPD R0 2/99

*8504332*

8504332

4332.fm Page 4 Thursday, April 15, 1999 10:46 AM
