Gateway Convertible Notebook pc Manuel utilisateur

www.gateway.com

Contents

Replacing Gateway Convertible Notebook Components . . . . . . . . . . . . . . . . . . 1

Identifying the convertible notebook model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Identifying components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Preparing your work space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Preventing static electricity discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Preparing the convertible notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Removing the main battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Removing the optional secondary battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Replacing the modular drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Adding or replacing memory modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Replacing the cooling assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Replacing the processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Replacing the IEEE 802.11 Mini PCI card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Replacing the CMOS battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Replacing the hard drive kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Replacing the hard drive in the hard drive kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Replacing the hinge covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Replacing the keyboard cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Replacing the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Replacing the LCD panel assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Replacing the LCD panel inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Replacing the LCD panel lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Replacing the palm rest assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Replacing the modem and system board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

ii www.gateway.com

Replacing Gateway Convertible

Notebook Components

Use this service guide to help plan maintenance tasks for

the Gateway CX200 convertible notebook. All tasks

covered in this guide can be performed by an authorized

field technician without jeopardizing the notebook’s

warranty.

Important This service guide is not intended to be

provided to individual users or consumers.

It cannot be provided to anyone other than

an authorized service provider.

Important For information on the convertible

notebook’s general maintenance, technical

support, safety notices, and regulatory

notices, see the Gateway user guide.

Important If you have suggestions regarding the

content of this guide, send an e-mail with

the subject “Service Guide Comments” to

channel.services@gateway.com.

2www.gateway.com

Replacing Gateway Convertible Notebook Components

Identifying the convertible notebook

model

The label on the bottom of the convertible notebook contains information that identifies

the convertible notebook model and its features.

Caution It is important that you use the correct service guide for the convertible

notebook. Failure to follow the approved tasks for the convertible

notebook model may result in damage to the convertible notebook.

www.gateway.com

Identifying components

Where screw measurements are shown, the first number indicates screw head width, and

the second number indicates screw length.

Use this chart to identify the main components of the convertible notebook. For a complete

list of replaceable parts, see “Contents” on page i.

Processor

(see page 20)

Cooling assembly

(see page 16)

LCD panel assembly

(see page 44)

Keyboard cover

(see page 38)

Keyboard

(see page 40)

Palm rest assembly

(see page 60)

System board

(see page 65)

4www.gateway.com

Replacing Gateway Convertible Notebook Components

Preparing your work space

Before performing maintenance on the convertible notebook, make sure that your work

space and the convertible notebook are correctly prepared.

■Wear a grounding (ESD) wrist strap, and use a grounded or dissipative work mat.

■Use a stable and strong table, and make sure that the table top is large enough to

hold each component as you remove it.

■Use bright lighting to make part identification easier.

■Keep your work surface free from clutter and dust that may damage components.

■Use a magnetized screwdriver for removing screws.

■When removing components that are attached to the convertible notebook by a

cable, unplug the cable before removing the screws, when possible, to avoid

damaging the cable.

■As you remove components and screws, lay them toward the rear of your work

surface (behind the convertible notebook) or far enough to the side that your arms

do not accidentally brush them onto the floor.

■To help keep track of screws, try the following:

■Place each component’s screws in their own section of a parts sorter.

■Place each component’s screws next to the component on your work surface.

■Print the first page of each task, then place the page toward the rear of your

work surface. As you remove screws, place the screws in their respective boxes

on the page. Where screw measurements are shown, the first number indicates

screw head width, and the second number indicates screw length.

■After loosening screws that are deeply recessed in a hole (for example, on the

bottom of the base assembly), you can leave the screws in the holes if you place

small pieces of masking tape over the hole openings. When reassembling the

component, just remove the tape and tighten the screws.

■When you place flat-headed screws on your work surface, stand them on their

heads to prevent the screws from rolling off the table.

www.gateway.com

Preventing static electricity discharge

The components inside your convertible notebook are extremely sensitive to static

electricity, also known as electrostatic discharge (ESD).

Before performing maintenance on the convertible notebook, follow these guidelines:

■Avoid static-causing surfaces such as carpeted floors, plastic, and packing foam.

■Remove components from their antistatic bags only when you are ready to use

them. Do not lay components on the outside of antistatic bags because only the

inside of the bags provide electrostatic protection.

■Always hold components by their edges. Avoid touching the edge connectors.

Never slide components over any surface.

■Wear a grounding wrist strap (available at most electronics stores) and attach it to

a bare metal part of your workbench or other grounded connection.

■Touch a bare metal surface on your workbench or other grounded object.

Important Before performing maintenance on the convertible notebook, you

should read and understand the information in this section.

Warning To avoid exposure to dangerous electrical voltages and moving parts,

turn off your convertible notebook and unplug the power cord, modem

cable, and network cable before opening the case.

Warning To prevent risk of electric shock, do not insert any object into the vent

holes of the convertible notebook.

6www.gateway.com

Replacing Gateway Convertible Notebook Components

Preparing the convertible notebook

To prepare the convertible notebook for maintenance:

1Make sure that the CD or DVD drive is empty.

2Turn off the convertible notebook and unplug the power cord, modem cable, and

network cable.

3Make sure the LCD panel is in notebook mode, then close the LCD panel.

4Disconnect all peripheral devices and remove any PC Cards.

5Unplug from the optional port replicator from the notebook.

6Remove the main and optional secondary battery. For more information, see

“Removing the main battery” on page 7 and “Removing the optional secondary

battery” on page 8.

Warning To avoid exposure to dangerous electrical voltages and moving parts,

turn off the convertible notebook, remove the battery, and unplug the

power cord, modem cable, and network cable before opening the

case. Replace the cover before you restore power or reconnect the

modem and network cables.
