Gate NanoHARD Manuel utilisateur
Last update on DECEMBER 22, 2016 www.gatee.eu
USER GUIDE
GATE Menet, Wojtak Sp. J. does not take any responsibility for damages, injuries
and accidents resulting in the use of this product or the use of Air Electric Gun
with the product installed.
Information contained in this document is subject to updating without notice.
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE INSTALLING THE DEVICE
THE DEVICE COVER MUST NOT BE REMOVED BY THE USER
Caution must be exercised to prevent short circuiting the battery as the
consequences can be very dangerous.
We recommend that this product should be installed by an experienced airsoft
service.
Notice
Safety Summary
DANGER!
FOR YOUR SAFETY
USER GUIDE
02 WWW.GATEE.EU
CERTIFICATE OF CONFORMITY
The symbol shown here means that the product is classed as Electrical or Electronic Equipment
and should not be disposed with other household and commercial waste at the end of its
working life. The Waste of Electrical and Electronic Equipment (WEEE Directive 2012/19/UE)
has been put in place to recycle products using best available recovery and recycling
techniques to minimize the impact on the environment. Purchasers shall take any old electrical
equipment to waste recycling public centers or points of sale.
PRODUCT DISPOSAL INSTRUCTIONS
GATE Menet, Wojtak Sp. J. hereby declares under our sole responsibility that the product
GATE NanoHARD is in conformity with the essential requirements of the following Directives:
EC DIRECTIVE 2011/65/EU
This product has been certified as RoHS Compliant.
WARNING:
WARNING:
WARNING:
WARNING:
NOTE:
Before starting installation process, please ensure that your AEG is
empty and there are no BBs inside.
Always use a fuse between the battery and the mosfet.
Incorrectly connecting positive and negative battery terminals will
cause immediate damage to the unit and it can lead to fire.
To use the Battery Protection function (p.6), it must be enabled before
(p.10).
Please check if you have downloaded the latest manual from the Technical Support
section of our website: www.gatee.eu. The Product Warranty Form is also
available there.
In case you have any difficulties while installing or using this product, we
recommend to email us at [email protected].
USER GUIDE
03
WWW.GATEE.EU
Table of Contents:
Safety Summary .......................................................................................................2
Table of Contents ......................................................................................................4
01. Overview .............................................................................................................5
• Key Functions .........................................................................................................5
• Package Contents ...................................................................................................7
02. Installation ...........................................................................................................8
• AEG standard installation diagram .......................................................................8
• Installation of NanoHARD without replacement of wires....................................8
• Installation of NanoHARD with replacement of wires.........................................9
03. Programming ....................................................................................................10
04. How to read Diagnostic Trouble Codes ...........................................................13
05. Diagnostic Trouble Codes Interpretation .........................................................15
06. GATE Limited Warranty Policy .........................................................................16
04 WWW.GATEE.EU
USER GUIDE
01. Overview
NanoHARD is a multifunctional programmable AEG Controller. It has 8 functions.
Thanks to its special coating, it is resistant to atmospheric conditions (Military
Specification MIL-V-173C). Battery protection supports: Li-Po 7.4V / 11.1V / 14.8V.
You can also disable the protection and use other batteries.
05
WWW.GATEE.EU
USER GUIDE
Key Functions
Do you want to achieve higher rate of fire and faster trigger response?
Are you planning power upgrade of your rifle? In that case, you need
a MOSFET.
It targets the energy from the battery directly to the motor, bypassing
the mechanical trigger contacts. As a result, you gain a higher rate
of fire of the rifle and faster trigger response, and the contacts
are protected against burn out.
MOSFET
Modern LiPoly batteries are very sensitive to over-discharge. If you do
not want to damage the battery and you care about its service life, this
protection is indispensable. The microprocessor constantly monitors
the battery voltage. When it drops down to a critical level, it will not
permit firing.
Protection against Over-Discharge of Battery (UVP Protection)
This provides full compatibility with the micro-switches. It is fully
resistant to contact bounce. You gain a bigger ROF, a faster trigger
response and your MOSFET is less prone to heating.
Debouncing (Digital Interface)
The usage of modern transistors and microcontroller has enabled us
to create the smallest and most reliable AEG Controller in the market.
3rd Generation MOSFET
14.8V LI-PO Ready
The system can be used with batteries up to 14.8V LI-PO. Minimum
operating voltage is 3V and maximum voltage is 17V.
06 WWW.GATEE.EU
USER GUIDE
Coating
Thanks to its special conformal coating, it is resistant to atmospheric
conditions (Military Specification MIL-V-173C).
Smart Fuse
We have developed an electronic fuse with an accurate current
sensor. A combination of current, voltage and temperature
measurements makes your AEG installation highly reliable. It protects
the MOSFET against overheating, overloading and short-circuiting. If
your airsoft gun becomes jammed, the function protects the motor
and battery against damage.
The Controller provides you with the opportunity to decide if you
want to use the Active Brake function. If you do not need this, you can
turn it off easily. It will lead to improving the lifespan of your motor.
ON/OFF Active Brake
Do you care about realism? Would you like to increase the life of the
gearbox? Does your rifle have such a high rate of fire that you are not
able to make a single shot? The Active Brake sorts things out. In SEMI
Mode, the brake does not allow for compressing a piston after a shot.
The piston will stop in the front position which eliminates
unnecessary stresses, increasing the service life of the gearbox and its
parts. This is important, especially with an AEG power upgrade. After
releasing the trigger, the rifle immediately stops firing. So, you gain
more realism and, additionally, you do not waste your precious
ammunition.
Active Brake
Built-In Self-Test
It allows you to quickly check whether the AEG Controller works
properly. If you have problems with your AEG, the BUILT-IN SELF-TEST
allows you to check that the problem is not caused by the Controller.
07
WWW.GATEE.EU
USER GUIDE
Included in the kit:
NanoHARD
Additional kit of Deans-T Connectors
Double signal wire for trigger contacts
Single signal wire for trigger contacts
Programming button
Jumper (2pcs.)
01
02
03
04
05
06
01
02
05
03
04
06
08 WWW.GATEE.EU
USER GUIDE
02. Installation
To adapt the standard AEG installation to work with NanoHARD it is necessary to
get to the trigger contacts. In case of GB v2 contacts these are located inside a
gearbox. With a version 3 gearbox, the installation will be easier because the
contacts are on the outside of the gearbox. Please consult a local airsoft technician if
you have never disassembled a gearbox before or if you have any installation
concerns.
Fig 1. Standard AEG wiring scheme
BATTERY
UP TO 14.8V
AEG Motor
A B
CONTACTS
C
DANGER! Incorrectly connecting positive and negative battery terminals
will cause immediate damage to the unit and it can lead to fire.
a) Installation of NanoHARD without replacement of wires. Using this method, the
original wiring is kept intact, and the connections are modified. Referencing Fig 1.,
de-solder A wire from the one of the trigger contacts and then solder it to the B wire.
It does not matter which wire you disconnect from the trigger switches, just join the
two wires together at one terminal. In the place of the A wire, solder the additional
single signal wire (No. 04 – provided in the kit). The GATE wire is very thin because it
handles very low current and it is only used for switch-detection. Now connect the
device between the battery and AEG. Do not forget about the signal wire. Connect it
to the top pin.
FUSE
09
WWW.GATEE.EU
USER GUIDE
Fig 2. Connection-modification scheme
b) Installation of NanoHARD with replacement of wires. Replacing the existing
AEG wiring with high-quality, low-resistance wiring in conjunction with the
installation of a MOSFET allows for the ultimate in system efficiency. 16 awg or
thicker wire is recommended. Solder the dual signal wire (No. 03 – provided in the
kit) to the trigger contacts. Connect the motor directly to the NanoHARD.
Fig 3. Complete re-wiring scheme
1.
TOP PIN
AEG Motor
CONTACTS
MAX LENGHT 30 CM (11.8 inch)
BATTERY
UP TO 14.8V
1.
AEG Motor
CONTACTS
BATTERY
UP TO 14.8V
FUSE
FUSE
10 WWW.GATEE.EU
USER GUIDE
03. PROGRAMMING
gatee.eu/technical-support/videos
We invite you to watch videos about NanoHARD programming on the GATE
website or on our YouTube channel:
youtube.com/GateMovies
Battery Protection and Active Brake settings
Step 1. Disconnect BATTERY and MOTOR from NanoHARD.
Step 2. Connect JUMPER to NanoHARD.
uC
BATTERY
UP TO 14.8V AEG Motor
FUSE
