GAS MAX S1 Manuel utilisateur
MAX
HARDCORE CAR AUDIO
MAX
S1-12D1/S1-12D2
S1-15D1/S1-15D2 / S1-18D1
WE PLAY LOUD!!
We know what you want. You want it LOUD, and that
is exactly what we do, what we live for. Vibrations,
gut-punches and straight up loud music - that’s what
makes us tick. We won’t dress up in fancy words or
claim to be something we’re not. We are the NO
BULLSH!T car audio brand!
Every single product with the GAS logo on it is born
out of passion, the same that has driven us for two
generations and that will keep us rolling up to your
neighbourhood, winning and pushing the limits for
many generations to come!
It’s up to you to choose your own level of loud, and if
you don’t like what we do that’s OK. You are welcome
back when you’ve had your first true GAS experience.
We don’t exclude, we don’t judge and we do not make
up any excuses for who we are.
We are GAS and we are proud to be LOUD!
TABLE OF CONTENT
SAFETY...................................................................................................
UNPACKING.........................................................................................
DIMENSIONS...............................................................................................
SPECIFICATIONS.................................................................................
MAX S1-6D1......................................................................................
MAX S1-8D1......................................................................................
MAX S1-10D1.....................................................................................
MAX S1-10D2....................................................................................
PERFORMANCE.......................................................................................
Thiele/Small parameters..................................................................
Impedance vs frequency..................................................................
FEATURES................................................................................................
Next level bass.................................................................................
Made to move...................................................................................
Tuned to the extreme.......................................................................
Coolest subwoofer on the block.......................................................
HOW TO.........................................................................................................
Install subwoofer..............................................................................
Build enclosure................................................................................
Do I need polyfill?.............................................................................
TROUBLESHOOTING......................................................................................
No power/sound..............................................................................
Unwanted noise...............................................................................
Distortion.......................................................................................
WARRANTY & DISPOSAL...............................................................................
THE GAS WORLD............................................................................................
3
4
4
5
5
5
6
6
7
7
8
9
9
9
9
9
10
10
12
14
15
15
15
15
16
17
SAFETY
Make sure to pay attention to the instructions when you see this symbol:
Do not expose your new subwoofer to excessive damp or moisture. If the subwoofer is
exposed it might result in electric failure, shock or damage to the product. Servicing
is required when the product has been damaged in any way and/or doesn’t operate
normally. Refer all servicing to qualified service personnel only.
Keep the cables inside the vehicle separate from sharp edges or components that
may be affected or take damage. Follow the recommended cable sizes and always use
high quality cables and accessories. Even if you’re eager to put the subwoofer to use
– take no shortcuts when installing the cables, make sure that all connectors are
protected and secured.
Do not drill any holes without checking what lies beneath, and don’t cut anything
without making sure that no important components risk being damaged.
There is a first time for everything, if you need help - ask a friend or contact your local
GAS AUDIO POWER dealer/installer.
We want you to experience your products to the MAX, but we don’t want you to injure
yourself or others. Use common sense, respect high pressure levels and volume, and
follow your local laws and regulations.
3
NO COMPROMISES! Especially when it comes to safety. Before installing your MAX
S1 series subwoofer, make sure that you read through the manual thoroughly and
follow the instructions. Save the manual for future usage and reference!
UNPACKING
Unboxing your new MAX product is an experience, make sure that the subwoofer and all the
accessories are included in the packaging:
4
S1-12D1/D2
S1-15D1/D2
A
Ø326
Subwoofer
DIMENSIONS
Manual
GF
E
D
mm
mm
A
B
C
B
Ø303
C
Ø6
D
Ø202
E
Ø285
F
187
G
203
Ø396 Ø375 Ø6 Ø202 Ø350 206 222
S1-18D1 mm
Ø470 Ø446 Ø6 Ø202 Ø423 258 275
SPECIFICATIONS
5
Below you’ll find the specifications that has been checked and tested in our workshop. The
specified sensitivity isn’t directly connected with the sound pressure in the vehicle, and
shouldn’t be used as the sole indicator for comparison with other subwoofers.
MAX S1-12D1
Component
Size
Nominal impedance
Power RMS
Freq. response
Voice coil
Voice coil former
Cone
Power MAX
Subwoofer
12” (300mm)
1+1 Ohm
1600W
20-200Hz
Dual 3” PCW
Aluminum
Non-Pressed
Paper
3200W
Dustcap 3D IMPP
Basket
Magnet
Aluminum
T-bone
2x100oz
HQ Ferrite
Suspension High roll foam
w. dual stitch
Spider Dual Nomex
Weight 13.2 KG
Tinsel Dual silver
coated leads
Terminal Heavy duty
push terminals
MAX S1-12D2
Component
Size
Nominal impedance
Power RMS
Freq. response
Voice coil
Voice coil former
Cone
Power MAX
Subwoofer
12” (300mm)
2+2 Ohm
1600W
20-200Hz
Dual 3” PCW
Aluminum
Non-Pressed
Paper
3200W
Dustcap 3D IMPP
Basket
Magnet
Aluminum
T-bone
2x100oz
HQ Ferrite
Suspension High roll foam
w. dual stitch
Spider Dual Nomex
Weight 13.2 KG
Tinsel Dual silver
coated leads
Terminal Heavy duty
push terminals
SPECIFICATIONS
6
MAX S1-15D1
Component
Size
Nominal impedance
Power RMS
Freq. response
Voice coil
Voice coil former
Cone
Power MAX
Subwoofer
15” (380mm)
1+1 Ohm
1600W
20-200Hz
Dual 3” PCW
Aluminum
Non-Pressed
Paper
3200W
Dustcap 3D IMPP
Basket
Magnet
Aluminum
T-bone
2x100oz
HQ Ferrite
Suspension High roll foam
w. dual stitch
Spider Dual Nomex
Weight 14.6 KG
Tinsel Dual silver
coated leads
Terminal Heavy duty
push terminals
MAX S1-15D2
Component
Size
Nominal impedance
Power RMS
Freq. response
Voice coil
Voice coil former
Cone
Power MAX
Subwoofer
15” (380mm)
2+2 Ohm
1600W
20-200Hz
Dual 3” PCW
Aluminum
Non-Pressed
Paper
3200W
Dustcap 3D IMPP
Basket
Magnet
Aluminum
T-bone
2x100oz
HQ Ferrite
Suspension High roll foam
w. dual stitch
Spider Dual Nomex
Weight 14.6 KG
Tinsel Dual silver
coated leads
Terminal Heavy duty
push terminals
SPECIFICATIONS
7
MAX S1-18D1
Component
Size
Nominal impedance
Power RMS
Freq. response
Voice coil
Voice coil former
Cone
Power MAX
Subwoofer
18” (460mm)
1+1 Ohm
1800W
18-200Hz
Dual 3” PCW
Aluminum
Non-Pressed
Paper
3600W
Dustcap 3D IMPP
Basket
Magnet
HD Aluminum
2x100oz
HQ Ferrite
Suspension High roll foam
w. dual stitch
Spider Dual Nomex
Weight 15.3 KG
Tinsel Dual silver
coated leads
Terminal Heavy duty
push terminals
PERFORMANCE
8
THIELE/SMALL PARAMETERS
Impedance 1+1 Ohm
1.8 Ohm
Fs
Qms
27.4Hz
5.81
Re
0.53
0.48
Vas 33.4 L
Qts
Qes
S1-12D1
2+2 Ohm
3.8 Ohm
25.6Hz
6.15
0.52
0.48
33.4 L
S1-12D2
Sd (cm²) 530
345.8 g
Le
Xmax
1.17mH
40mm
Mms
84dB 1W/1M
13.9
Driver Vol.
Displacement 3.1 L
Bl
dB/SPL
530
391.7 g
3.13mH
40mm
83dB 1W/1M
22.3
3.1 L
Impedance 1+1 Ohm
1.8 Ohm
Fs
Qms
25.5Hz
5.99
Re
0.54
0.49
Vas 76.3 L
Qts
Qes
S1-15D1
2+2 Ohm
3.8 Ohm
24.4Hz
6.33
0.58
0.53
79.7 L
S1-15D2
Sd (cm²) 829
451.8 g
Le
Xmax
1.2mH
40mm
Mms
86dB 1W/1M
14.6
Driver Vol.
Displacement 4.1 L
Bl
dB/SPL
829
468.2 g
3.14mH
40mm
85dB 1W/1M
22.2
4.1 L
PERFORMANCE
9
THIELE/SMALL PARAMETERS
Impedance 1+1 Ohm
1.8 Ohm
Fs
Qms
24.4Hz
6.01
Re
0.55
0.50
Vas 140.1 L
Qts
Qes
S1-18D1
Sd (cm²) 1194
578.5 g
Le
Xmax
1.19mH
40mm
Mms
88dB 1W/1M
16.4
Driver Vol.
Displacement 5.9 L
Bl
dB/SPL
