GARUDA ROBOTICS MyDroneFleets Manuel utilisateur
UAV Hardware Tracker
User’s Manual
Model: GRT-001
Version: 1.0
Manual version: 1.10
Manual revision: 2022-06-03
UAV Hardware Tracker | User’s Manual
Table of Contents
About This Manual 3
About Your Tracker 4
Compliance 5
Package Contents 6
Tracker Specifications 7
Mount Specifications 7
Identifying Parts and Controls 8
Warranty 10
Support 10
Setting Up the Tracker 11
Step 1: Initial Hardware Setup 11
Step 2: Initial Software Setup 12
Setting up MyDroneFleets 12
Setting up FlyItSafe 13
Step 3: Attaching the Velcro Strip 15
Step 4: Mounting the Tracker 18
Operating the Tracker 21
Charging the Tracker 21
In the Field 22
Flight Operations 22
Flight Operations (CAAS) 24
Monitoring Battery Status 26
Care and Maintenance 27
General Care 27
Operating Environment 27
Charging and Power 28
Frequently Asked Questions 29
Troubleshooting 30
Diagnosing Common Problems 30
Appendix 32
Suggested Mounting for Common UAVs 33
Acceptable Use Policy for CFMS UA Trackers 36
GARUDA ROBOTICS PAGE 2 / 36
UAV Hardware Tracker | User’s Manual
About This Manual
Thank you for purchasing a MyDroneFleets UAV Hardware Tracker.
This user’s manual contains the information you need to set up, operate and maintain your
tracker. For your safety, please read this manual before operating the tracker.
The information contained in this manual has been verified to be accurate at the time of
publishing. For the latest version, download it from mydronefleets.com
Some sections of this manual may be annotated with one or more of the following icons:
📝
NOTE: A NOTE Indicates important information that helps you make better use of
your tracker.
🔔
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
❗
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
Copyright 2022 Garuda Robotics Pte Ltd. All rights reserved.
GARUDA ROBOTICS PAGE 3 / 36
UAV Hardware Tracker | User’s Manual
About Your Tracker
Congratulations on your purchase of a MyDroneFleets UAV Hardware Tracker!
Once the Tracker has been mounted on your UAV, you will be able to transmit and monitor
its location via a 4G cellular network.
GARUDA ROBOTICS PAGE 4 / 36
UAV Hardware Tracker | User’s Manual
Compliance
Depending on where you purchased and use your tracker, you may need to comply with
one or more specific usage conditions described in the following table:
📝
Note: Garuda Robotics makes a reasonable effort to ensure the information
contained in this section is up to date at the time of publishing. The user of the
UAV Hardware Tracker bears final responsibility for ensuring compliance with all
applicable local regulations.
Retail Trackers
This tracker is linked to your Garuda Plex company account.
By using this tracker, you consent to Garuda Robotics
operating a location tracking service for your UAVs.
The location tracking service (MyDroneFleets) is located at
track.mydronefleets.com.
All your location data will be kept strictly private according to
our product Terms and Conditions at
https://garuda.io/terms and https://garuda.io/privacy
Centralised Flight
Management System
(CFMS) Trackers
by the
Civil Aviation Authority
of Singapore (CAAS)
The use of this tracker is mandatory for all commercial UAV
operators in Singapore. A tracker unit must be mounted on
your UAV(s) during commercial flight operations to allow
CAAS to monitor your flight activities.
You may only use this tracker while operating UAVs
commercially in Singapore. You may not use this tracker for
any other purposes. This tracker unit is linked to your operator
permit and cannot be used on another operator permit.
Additional details may be found in the Acceptable Use Policy
for CFMS UA Tracker.
For more information, see clause 19D in ANR 101 (wef 1 June
2022).
GARUDA ROBOTICS PAGE 5 / 36
UAV Hardware Tracker | User’s Manual
Package Contents
Your Tracker ships with the components shown below. Make sure that you have received all
the components. Contact Technical Support if something is missing.
📝
Note: Some items may be optional and may not ship with your tracker. Some
components may not be available in certain countries.
UAV Hardware Tracker
Mount
3M Dual Lock Reclosable
Fastener SJ3560 Velcro Strip
(x2)
USB charging cable
(Only included in selected
packages)
Additional tracker mounts may be purchased from Garuda Robotics. Additional velcro
strips, USB cables and other accessories may be purchased from Garuda Robotics or a
suitable electronics store.
GARUDA ROBOTICS PAGE 6 / 36
UAV Hardware Tracker | User’s Manual
Tracker Specifications
Dimensions
60.0 x 45.0 x 23.5mm (2.36 x 1.77 x 0.93 in)
Weight
60 g (2.12 oz)
Casing
High-strength engineering plastic
CPU
48MHz ARM Cortex-M0
GNSS
GPS/GLONASS/Beidou
Cellular Mobile Terminal
4G LTE
B3/B7/B8
Complies with IMDA standards – DA109033
SIM
Nano SIM
Sensors
Accelerometer
Gyroscope
Compass
Temperature
Battery
Non-removable Lithium Polymer 500mAh
Charger
Integrated two-stage USB charger with safety circuit
and intelligent cutoff
Charging time
60 min
Operating time
60 min
Operating temperature
0 to 55 °C (32 to 131 °F)
Mount Specifications
Base weight
9 g (0.32 oz)
Weight with velcro strip
12 g (0.42 oz)
Material
High-strength thermoplastic polyester
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT
TO ALTER DESIGN AND SPECIFICATIONS WITHOUT NOTICE.
GARUDA ROBOTICS PAGE 7 / 36
UAV Hardware Tracker | User’s Manual
Identifying Parts and Controls
Tracker Right View Tracker Left View
1
6
2
5 4 3
Label
Description
Use
1
Power button
Latching power button. Press fully and release to toggle
tracker on/off state.
2
Micro USB port
Connect a USB cable to the tracker and a USB power
source (5V) to charge the tracker.
3
Charging indicator
Lights up red when charging. Lights up blue when fully
charged.
4
Power indicator
Lights up green when powered on. Unlit when powered
off.
5
Status indicator
Lights up orange to indicate tracker status through a
combination of short and long flashes.
6
Tamper-proof label
Indicates if the tracker has been opened. Labels are single
use and can only be replaced at an Authorised Service
Centre.
GARUDA ROBOTICS PAGE 8 / 36
UAV Hardware Tracker | User’s Manual
Tracker Bottom View
Engraved or Sticker
Label
Description
Use
1
Serial number
Globally unique serial number of the tracker.
2
International Mobile
Equipment Identity
(IMEI)
Globally unique hardware address of the onboard 4G LTE
communications module.
3
Regulator logo (only
present in some
versions)
Trackers issued through a UAV-regulating authority bear
the official logo of said entity.
GARUDA ROBOTICS PAGE 9 / 36
UAV Hardware Tracker | User’s Manual
Mount Side View Mount Bottom View
1
2
Label
Description
Use
1
Mounting lock
Mates with corresponding cutout on the tracker body to
ensure secure hold.
2
Adhesive point
Designated surface for attaching velcro strips.
Warranty
The warranty policy that applies to your tracker depends on where it was purchased. These
policies are described in the following table:
Retail trackers
Trackers are covered by a warranty of three (3) months
against manufacturing defects.
This warranty does not cover wear and tear experienced in the
course of normal usage. It does not cover failure or damage
caused by improper usage.
CFMS Trackers
Trackers are covered by a warranty of up to three (3) years
against manufacturing defects. The warranty period depends
on the date of manufacture and collection.
This warranty does not cover wear and tear experienced in the
course of normal usage. It does not cover failure or damage
caused by improper usage.
Batteries are consumable items which degrade over time. The
battery in your tracker is covered for one (1) year after
purchase. If your battery needs to be replaced due to normal
wear and tear, the cost of parts and labour are not covered by
the warranty.
Support
For all technical support matters, please contact suppor[email protected].
GARUDA ROBOTICS PAGE 10 / 36
