Garmin Nuvi 3750 Manuel d'instructions

nüvi®3700 series

quick start manual

for use with these nüvi models:

3750, 3760, 3790

April 2010 190-01157-01 Rev. B Printed in Taiwan

2 nüvi 3700 Series Quick Start Manual

Getting Started

‹

WARNING

See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

When using your nüvi for the rst

time, complete the following tasks.

1. Power your device (page 2).

2. Mount your device (page 3).

3. Congure your device (page 4).

4. Acquire satellites (page 4).

5. Understand the Main menu

(page 5).

Powering the Device

Connect your device to the vehicle

power cable while it is plugged

into your vehicle.

Your nüvi charges as you drive.

Power Cables

Your device can be powered three

ways.

Vehicle power cable

USB cable (page 11)

AC adapter (optional accessory)

If you do not plan to use your device

while it is connected to a power

source, press the Power button to

lock the device. For more on locking

the device, see page 10.

•

nüvi 3700 Series Quick Start Manual 3

Mounting Your Device

‹

WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to

extreme heat, remove the device from

the vehicle when exiting or store it

out of direct sunlight.

Notice

Before mounting the device, see

the Important Safety and Product

Information guide for information

about laws pertaining to windshield

mounting.

1. Remove the clear plastic from the

suction cup.

2. Place the suction cup on the

windshield.

3. Flip the lever back toward the

windshield.

4. Snap the mount onto the suction

cup arm.

Suction cup mount

Vehicle power

cable

Mount

Speaker

5. Fit the bottom of your device into

the mount.

6. Tilt your device back until it

snaps into place.

Vehicle power

cable connector

4 nüvi 3700 Series Quick Start Manual

Conguring your Device

1. Plug the vehicle power cable into

the mount.

2. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

Your unit should turn on

automatically if it is plugged in

and the vehicle is running.

3. Follow the on-screen instructions.

4. If you are using a trafc receiver

in Europe, connect the external

antenna to the trafc receiver and

secure it to the windshield using

the suction cups.

Front Cover

Micro-B connector

Power button

Speaker

(on back cover)

Microphone

Acquiring Satellites

The bars indicate satellite

strength.

1. Go outdoors to an open area, away

from tall buildings and trees.

2. If necessary, turn on your device.

Acquiring satellite signals can take

a few minutes. When at least one of

the bars is green, your device has

acquired satellite signals.

nüvi 3700 Series Quick Start Manual 5

Main Menu

➊➋

➌ ➍

➐ ➑ ➒➎ ➏

➊

GPS satellite strength.

➋

Touch to select a transportation

mode.

➌

Touch to nd a destination.

➍

Touch to view the map.

➎

Touch to stop a route.

➏

Touch to detour a route.

➐

Touch to make a call when

connected to a compatible

mobile phone. See www.garmin

.com/bluetooth for information.

➑

Touch to adjust the volume.

➒

Touch to open the menu of tools

and settings.

Finding Points of Interest

1. From the Main menu, touch

Where To? > Points of Interest.

2. Select a category and a

subcategory, if necessary.

3. Select a destination.

4. Touch Go!.

Finding a Place by Spelling

the Name

1. From the Main menu, touch

Where To? > Points of Interest >

Spell Name.

2. Enter the name your destination.

3. Touch Done.

4. Select a destination.

5. Touch Go!.

Searching Near Another

Location

1. From the Main menu, touch

Where To? > > Near.

2. Select an option.

6 nüvi 3700 Series Quick Start Manual

Following Your Route

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

➍

➌

➐

➏

➎➑

➊➋

➊ 

Touch to view the Next Turn

page. If a view of the junctions

exists, the Junction View page

appears.

➋ 

Touch to view the Turn List

page.

➌

Touch to zoom in and out.



➍

Touch to return to the Main

menu.

➎

Touch to change the data eld.

➏

Touch to view the Where Am I?

page.

➐

Touch and drag the map to view

a different area of the map.

➑

Touch to view the Trip

Computer page.

Adding a Stop

Before you can add a stop, you must

be navigating a route.

1. Touch to return to the Main

menu.

2. Touch Where To?.

3. Search for the extra stop.

4. Select the stop from the search

results.

5. Touch Go!.

6. Touch Add to Current Route.

nüvi 3700 Series Quick Start Manual 7

Taking a Detour

Before you can take a detour, you

must be navigating a route.

1. Touch to return to the Main

menu.

2. Touch Detour.

If the route you are currently taking is

the only reasonable option, the device

might not calculate a detour.

Orienting the Screen

Rotate your device to view in

horizontal (landscape) or vertical

(portrait) mode.

Adjusting the Screen

Brightness

1. Touch Tools > Settings > Display

> Brightness.

2. Touch and move the scroll bar to

adjust screen brightness.

About the Transportation

Modes

Automobile

Pedestrian

Bicycle

Your device has different

transportation modes for navigation.

Routing is calculated differently based

on your transportation mode. For

example, in Pedestrian transportation

mode with cityXplorer™maps loaded,

your unit calculates a route that uses a

combination of public transit options,

such as riding a bus or subway, and

8 nüvi 3700 Series Quick Start Manual

walking. cityXplorer maps are not

included with your device.

Go to www.garmin.com to purchase

cityXplorer maps.

Changing Your Transportation

Mode

1. From the Main menu, touch the

transportation mode icon.

2. Select a mode, and touch Save.

About Trafc

The FM Trafc Message Channel

(TMC) trafc receiver is included in

some nüvi 3700 packages. It is built

into the vehicle power cable.

The trafc receiver and the nüvi must

be in data range of an FM station

transmitting TMC data to receive

trafc information. You do not need

to activate the subscription included

with your FM trafc receiver.

If a severe trafc delay occurs on

your route, the device automatically

recalculates the route. The trafc icon

( ) changes color to indicate the

severity of trafc conditions on your

route or on the road you are traveling.

Go to www.garmin.com/trafcfor

more information.

NOTE: Garmin is not responsible for

the accuracy of the information.

About Voice Command

NOTE: Voice Command is not

available for all languages or regions.

The Voice Command feature is

available on some nüvi models. Voice

Command allows you to use your

device by speaking the words you see

on the screen or by speaking certain

commands. The Voice Command

menu provides a list of available

commands to use.

nüvi 3700 Series Quick Start Manual 9

Activating Voice Command

1. Speak Voice Command.

The voice command menu

appears.

Tips for Using Voice

Command

Talk in a normal voice directed at

the device to speak a command

exactly as it appears on the screen.

Respond to voice prompts from

the device as needed.

Speak numbers to enter numbers.

Speak Exit to exit Voice

Command.

Navigating with Voice

Command

1. Speak your wakeup phrase.

The voice command menu

appears.

2. Speak Find by Name.

•

3. Listen for the voice prompt and

speak the name of the place.

The device repeats the name of the

place as it is searching.

A list of locations appears.

4. Speak the line number of the

location you want.

5. Speak Yes to navigate to the

location, or speak No to go back

to the list of found locations.

Hands-free Features

Hands-free calling is available on

some nüvi models.

Pairing Your Phone

Before you can pair, your phone and

the device must be turned on and near

each other.

1. Enable the Bluetooth®component

on your phone.

2. Touch Tools > Settings >

Bluetooth.

10 nüvi 3700 Series Quick Start Manual

3. Touch the button below Bluetooth

> Enabled >OK.

4. Touch the button below Phone.

5. Touch OK.

6. Select your phone, and touch OK.

7. Enter the Bluetooth PIN (1234)

for your device in your phone.

Placing and Ending Calls

1. Touch > Dial.

2. Enter the number.

3. Touch Dial.

4. Touch > End Call to end a

call.

Answering a Call

When you receive a call, the

Incoming Call window opens.

1. Touch Answer.

TIP: Touch Ignore to stop your

phone from ringing.

2. Speak normally.

The internal microphone is in

the front of the device. Speak

normally.

About Sleep Mode

You can use sleep mode to conserve

battery power when your device is

not in use. Sleep mode uses very little

power, and a battery charge lasts for

weeks when your device is in sleep

mode.

Press the Power button to put the

device in sleep mode.

Press and quickly release the

Power button and double-tap

to wake up the device.

Resetting the Device

You can reset your device if it stops

functioning.

Press and hold the power button

for 10 seconds.

•

Autres manuels pour nuvi 3750

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Garmin GPS

Garmin

Garmin G1000:Beechcraft Baron 58/G58 Manuel

Garmin

Garmin GPSMAP 185 Sounder Manuel utilisateur

Garmin

Garmin GPS 72 Manuel utilisateur

Garmin

Garmin ECHOMAP UHD Manuel utilisateur

Garmin

Garmin GPSMAP 431 Manuel utilisateur

Garmin

Garmin GPSMAP 441 Manuel utilisateur

Garmin

Garmin eTrex Touch 25 Manuel utilisateur

Garmin

Garmin 1620 Manuel utilisateur

Garmin

Garmin GPSMAP 550 Manuel utilisateur

Garmin

Garmin eTrex Legend Guide d'installation

Garmin

Garmin AQUAMAP 80 Series Manuel utilisateur

Garmin

Garmin GRN-010-02088-01 Manuel utilisateur

Garmin

Garmin GPS 165TSO Manuel

Garmin

Garmin zumo 350LM Mode d’emploi

Garmin

Garmin GTN 750 Manuel

Garmin

Garmin EDGE 1030 Manuel utilisateur

Garmin

Garmin Fishfinder 80 Caractéristiques techniques

Garmin

Garmin SOCATA TBM850 Manuel

Garmin

Garmin Etrex Manuel utilisateur

Garmin

Garmin nuvi 3750 Guide de référence

Garmin

Garmin GNC 420 Manuel du propriétaire

Garmin

Garmin Road Tech Zumo 665 Manuel utilisateur

Garmin

Garmin GTM 60 Manuel utilisateur

Garmin

Garmin GPSMAP 420 Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur

Kenwood

Kenwood DNN9330BT Manuel utilisateur

Safelet

Safelet Indra Manuel utilisateur

Bushnell

Bushnell 360100 Manuel utilisateur

Geneq

Geneq SXBlue Manuel utilisateur

ORIGO

ORIGO ED308 Manuel utilisateur

Garmin nuvi 3750 Manuel d'instructions

Manuels GPS populaires d'autres marques
