Garmin Fleet 590 Manuel utilisateur

Garmin eet™ 590

Quick Start Manual

July 2013 190-01505-01_0F Printed in Taiwan

2 Garmineet590QuickStartManual

Fleet Subscription

Before you can use the eet

management features on the device,

your company must have an active

eet subscription.

Connecting the Device to

Vehicle Power



WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to extreme

heat, store it out of direct sunlight.

notice

In order for the device to receive eet

management information, do not

unplug the power cable.

Before you use your device on battery

power, you should charge it.

1. Plug the vehicle power cable

➊

into the USB port on the mount

➋

➊

➋

➌

➍

2. Snap the mount onto the suction

cup

➌

3. Press the suction cup to the

windshield.

4. While pressing, ip the lever

➍

back toward the windshield.

5. Fit the bottom of your device into

the mount.

6. Tilt your device back until it snaps

into place.

7. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

Garmineet590QuickStartManual 3

Turning Off the Device

1. Hold the Power key

➊

for four

seconds.

➊

2. Select Off.

Using the Main Menu

➊ ➋ ➌

➎

➍

• Select

➊

to enter the time

clock.

• Select

➋

to access messages

and stops.

• Select

➌

to view the map.

• Select

➍

to nd a destination.

• Select

➎

to open the menu of

tools and settings.

New Stops and

Messages

Your device displays notications

when you receive new stops or

messages.

• On the main menu, a

notication indicates when

you have new stops,

messages, or ( ) both.

• On the map, or appears

blue when you have new stops

or messages.

• On the tab or the tab,

indicates the number of

new stops or messages.

◦A blue notication

indicates that new stops

or messages have arrived

since the last time you

viewed the list of stops or

messages.

4 Garmineet590QuickStartManual

◦A gray notication

indicates that you have

unread messages or stops.

Navigating to a Stop

Before you can navigate to a stop,

your company must send a stop to

your device.

1. From the main menu, select

Dispatch > .

2. Select a stop.

3. Select Go!.

Viewing a Message

Before you can view a message, your

company must send a message to

your device.

1. From the main menu, select

Dispatch > .

2. Select a message.

Sending a Message

You can send a short message to your

company. Your device may include

quick messages, which are pre-written

messages loaded by your company.

1. From the main menu, select

Dispatch > .

2. Select an option:

• To send a custom message,

select New Message, and enter

a message.

• To send a quick message,

select Quick Message, and

select a message.

3. Select Send.

Garmineet590QuickStartManual 5

Adding a User to the

Time Clock

Before you can add a user to the

time clock, the user name must be

provisioned by your company. If your

company has enabled time clock PINs

for the device, you must know the

PIN for the user name you are adding.

You can add multiple time clock users

to the same device.

1. From the main menu, select Time

Clock.

2. Select Add User.

3. Enter the user name provided by

your company, select OK.

4. If necessary, enter the time clock

PIN for the user name.

The user name appears in the list in

“Validating” status. When the server

validates the user, the status changes

to “not set.”

Setting the Status of a User

Before you can set the status of users,

you must add one or more users to the

device, and your company must send

a list of statuses to the device.

You can set the status of one or more

time clock users.

1. From the main menu, select Time

Clock.

2. If time clock PINs are enabled on

the device, select your user name,

and enter your time clock PIN.

3. Select one or more users.

4. Select Set Status.

5. Select the status.

6 Garmineet590QuickStartManual

About Points of Interest

Finding Points of Interest

1. From the main menu, select

Search > Points of Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select a destination.

Searching Within a Category

To narrow your search results, you

can search within some categories.

1. Select Search > Points of

Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select .

5. Enter all or part of the name.

6. Select Done.

Your Route on the Map

notice

The speed limit icon feature is for

information only and does not replace

the driver’s responsibility to abide

by all posted speed limit signs and to

use safe driving judgment at all times.

Garmin will not be responsible for

any trafc nes or citations that you

may receive for failing to follow all

applicable trafc laws and signs.

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

Garmineet590QuickStartManual 7

Using the Map Functions

➊ ➋ ➌

➍

➎➏➐

• Select

➊

to view the next turn.

If a view of a junction exists,

the junction view appears.

• Select

➋

to view the turn list.

• Select

➌

to view stops.

• Select

➍

to view messages.

• Select

➎

to change the data

eld.

• Select

➏

to view the Where

Am I? page.

• Select

➐

to view trip

information.

About Sleep Mode

Sleep mode conserves battery power

when your device is not in use.

Using Sleep Mode

• While the device is on, select

the power key to put the device

into sleep mode.

• While the device is in sleep

mode, select the power key,

and double-tap to wake the

device, if necessary.

Garmin® and the Garmin logo are trademarks of Garmin Ltd.

or its subsidiaries, registered in the USA and other countries.

Garmin eet™ is a trademark of Garmin Ltd. or its subsidiaries.

These trademarks may not be used without the express

permission of Garmin.

Garmin International, Inc.

1200 East 151st Street,

Olathe, Kansas 66062, USA

Garmin (Europe) Ltd.

Liberty House, Hounsdown Business Park

Southampton, Hampshire, SO40 9LR UK

Garmin Corporation

No. 68, Zhangshu 2nd Road, Xizhi Dist.

New Taipei City, 221, Taiwan (R.O.C.)

www.garmin.com/eet

www.garmin.com

00 358 19 311 001

00 33 1 5517 81 89

0180 5 / 42 76 46 - 880

0180 5 / 42 76 46 - 550

00 39 02 3669 9699

0800-0233937

815 69 555

00800 4412 454

+44 2380 662 915

00 35 1214 447 460

00 46 7744 52020

00 902 00 70 97

43 (0) 3133 3181 0

00 32 2672 5254

1-866-429-9296

00 45 4810 5050

913-397-8200

1-800-800-1020

0808 2380000

+44 (0) 870.8501241
