Garmin Streetpilot C320 Manuel utilisateur
Step 1: Configure Your c320
Press and hold the
Power button to turn
on the unit.
Note: A “Low Battery”
warning may appear when
you turn on the unit. Charge
the unit for three hours.
1
2
Answer the configuration questions that appear. When you
see the screen that states “To use this unit, map data must be
installed,” you are ready to install software and map data.
Start Here
Open this setup guide and follow the instructions to set up your c320.
Complete all of the setup steps:
Step 1: Configure your c320
Step 2: Install software and map data
Step 3: Load maps
Do not connect the USB cable to your PC until you are instructed to do so.
StreetPilot® c320
This setup guide includes instructions to
configure your c320 and load maps.
To ensure a successful installation, follow
the steps outlined in this guide. Do not
connect the USB cable to your PC until you
are instructed to do so.
For information about using your c320, refer
to the
c320 Quick Reference Guide
located in
the box. Also see the
c320 Owner’s Manual
at www.garmin.com/products/sp320/.
setup guide
190-00435-02 Rev. C
Volume control
Power button
USB cable connector
Step 1: Configure Your c320
Press and hold the
Power button to turn
on the unit.
Note: A “Low Battery”
warning may appear when
you turn on the unit. Charge
the unit for three hours.
1
2
Answer the configuration questions that appear. When you
see the screen that states “To use this unit, map data must be
installed,” you are ready to install software and map data.
Start Here
Open this setup guide and follow the instructions to set up your c320.
Complete all of the setup steps:
Step 1: Configure your c320
Step 2: Install software and map data
Step 3: Load maps
Do not connect the USB cable to your PC until you are instructed to do so.
StreetPilot® c320
This setup guide includes instructions to
configure your c320 and load maps.
To ensure a successful installation, follow
the steps outlined in this guide. Do not
connect the USB cable to your PC until you
are instructed to do so.
For information about using your c320, refer
to the
c320 Quick Reference Guide
located in
the box. Also see the
c320 Owner’s Manual
at www.garmin.com/products/sp320/.
setup guide
190-00435-02 Rev. C
Volume control
Power button
USB cable connector
Step 3: Load MapsStep 2: Install Software and
Map Data
When you have completed
the registration process, click
Done to load maps to your
c320.
3
Follow the series of instructions that appear on your computer.
When prompted, connect your c320 to your computer using
the enclosed USB cable.
2
Remove the DVD-ROM from the case and insert it into your
computer’s DVD-ROM drive.
If the startup file does not run automatically, click the Windows
Start button and select Run…. Type your DVD-ROM’s drive
followed by “Setup” (for example, “E:\Setup”). Click OK.
1
To load maps on your c320, follow the instructions on the
Map Install Wizard shown on your computer screen.
Click the regions
on the map that
you want to load
into your c320.
Click Next.
After your maps
are loaded, click
OK. Disconnect
the USB cable
from your unit.
To load new maps, turn on your c320 and reconnect the USB cable
to your unit and PC. The Map Install Wizard automatically appears.
1
2
3
Move the slider to zoom in
and out of the map.
Click the arrows to move
the map.
Selected map region. Click Next to load the maps to your c320.
Step 3: Load MapsStep 2: Install Software and
Map Data
When you have completed
the registration process, click
Done to load maps to your
c320.
3
Follow the series of instructions that appear on your computer.
When prompted, connect your c320 to your computer using
the enclosed USB cable.
2
Remove the DVD-ROM from the case and insert it into your
computer’s DVD-ROM drive.
If the startup file does not run automatically, click the Windows
Start button and select Run…. Type your DVD-ROM’s drive
followed by “Setup” (for example, “E:\Setup”). Click OK.
1
To load maps on your c320, follow the instructions on the
Map Install Wizard shown on your computer screen.
Click the regions
on the map that
you want to load
into your c320.
Click Next.
After your maps
are loaded, click
OK. Disconnect
the USB cable
from your unit.
To load new maps, turn on your c320 and reconnect the USB cable
to your unit and PC. The Map Install Wizard automatically appears.
1
2
3
Move the slider to zoom in
and out of the map.
Click the arrows to move
the map.
Selected map region. Click Next to load the maps to your c320.
